Bannon 57937 Owner's Manual

100in. high volume ceiling fan
Hide thumbs
Table of Contents

Advertisement

Quick Links

100In. High Volume Ceiling Fan
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #57937
READ & SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 57937 and is the answer not in the manual?

Questions and answers

Michael Landry
June 26, 2025

Looking for control parts for a 100” Bannion high volume fan

0

Related Manuals for Bannon 57937

Summary of Contents for Bannon 57937

  • Page 1 100In. High Volume Ceiling Fan Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #57937 READ & SAVE THESE INSTRUCTIONS...
  • Page 2 Thank you very much for choosing a Bannon™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Table Of Contents

    Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Assembly and Installation Instructions ....................7 Before Each Use ..........................14 Operating Instructions ........................14 After Each Use .............................

  • Page 4: Intended Use

    Intended Use The Bannon 100In. High Volume Ceiling Fan is designed for large, high ceiling areas such as factories, barns, ranches, gyms, and warehouses. The low electric usage is perfect for continuous use. Packaging Contents    Motor (1)
  • Page 5 WORK AREA SAFETY  Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. ...

  • Page 6: Specific Operation Warnings

     Disconnect the power/air supply from the product and place the switch in the locked or off position before making any adjustments, changing accessories, or storing the tool. Such preventive safety measures reduce the risk of starting the tool accidentally. ...

  • Page 7: Assembly And Installation Instructions

    outlet box.  When cutting or drilling in the ceiling or wall, do not damage electrical wiring and other hidden utilities.  To reduce the risk of injury, do not bend blade holders during installation to motor, balancing or during cleaning. Do not insert foreign object between rotating blades. ...
  • Page 8  All set screws must be checked and re-lightened where necessary before installation. PREPARING FOR INSTALLATION  Unpack and inspect fan carefully to be certain all contents are included. Turn off power at fuse box to avoid possible electrical shock. DOWNROD INSTALLATION VAULTED CEILING INSTALLATION May require a longer downrod for high vaulted ceilings (sold separately).
  • Page 9 MOUNTING BRACKET INSTALLATION  Remove the screws from the two matching holes (1) on canopy. Loosen (do not remove) the screws in the matching slots (2) on the canopy. Rotate the mounting bracket and remove from the canopy.  Install mounting bracket to the outlet box in the ceiling using the screws and the washers provided with your outlet box.
  • Page 10 DOWNROD ASSEMBLY (included)  Remove clamp pin (1) and cross pin (2) from down rod (3).  Feed motor lead wires through downrod and canopy assembly and insert downrod into downrod yoke.  Make sure to align holes in downrod with the hole in the yoke. ...
  • Page 11 DOWNROD PREPARATION  Re-install pin into downrod.  Slide the downrod ball up to the top of the downrod.  Re-install the screw to secure ball to downrod. Note: Some extended downrods have a pre-drilled set-screw hole. If a pre-drilled hole is present in the extended downrod, tighten the set screw into the pre-drilled hole in the extended downrod.
  • Page 12 WIRING DIAGRAM  Make wiring connection from the housing and the motor to the remote receiver as shown above.  Connect using wire nuts (provided).  Once the wiring step has been completed, slide the wired remote receiver (1) in between the mounting bracket (2) and the top of the down rod ball (3) for the down rod fans.
  • Page 13 ATTACHING BLADES TO FAN  Insert the blades (5) through the slots on the motor housing as shown.  Use the provided screws (1), washers (2), and bolts (3) to tighten the blades to the pre-attached blade brackets (4).  Mount the transmitter holder onto the wall using screws provided.

  • Page 14: Before Each Use

    Before Each Use ⚠WARNING  Be sure obstructions are not in the fan’s path of operation.  Check that batteries are in good condition in the remote control transmitter. Operating Instructions ⚠WARNING  To reduce the risk of electric shock, or personal injury, mount to outlet box marked “acceptable for fan support of 22.7 Kg (50 lb.) or less”...
  • Page 15 SETTING FAN AIR FLOW Note: Be sure the slide switch is pushed firmly to one side or the other. The fan will not operate with the slide switch in the middle.  To reverse the direction of the blades, slide the reverse switch (located on the top of the motor housing) to the opposite side.

  • Page 16: After Each Use

    NOTE: Turn off and wait for fan to come to a stop before changing the setting of the downward/upward slide switch. CONTROLLING MORE THAN ONE FAN WITH REMOTE CONTROL  The remote control transmitter and receiver are matched at the factory. With the matching process, the same remote control transmitter can control another identical model ceiling fan.

  • Page 17: Troubleshooting

    Troubleshooting ⚠WARNING TURN OFF FAN AND BREAKER AT ELECTRICAL SUPPLY BEFORE ATTEMPING TO DO ANY ADJUSTMENTS TO THE FAN. Failure Possible Cause Corrective Action UNPLUG from power source. 1a. Check and re-secure screws that connect the blades to the motor. 1.

  • Page 18: Parts Diagram

    Parts Diagram Parts List Reference Part Description Quantity MOUNTING BRACKET BLADES CANOPY DOWNROD FAN MOTOR HARDWARE PACK MOUNTING SCREW AND NUT BLADE SCREWS AND NUTS SCREW WIRE NUTS BLADE SCREW WASHERS REMOTE CONTROL WITH WALL BRACKET Page 18 of 21...

  • Page 19: Replacement Parts

    Replacement Parts  For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.  Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ...

  • Page 20: Limited Warranty

    Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only ("You" or ''Your'') that the Bannon product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of two years from date of purchase.
  • Page 21 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 21 of 21...
