Summary of Contents for Lincoln COOL ARC 47
- Page 1 IM3050 05/2016 REV07 ® COOL ARC OPERATOR’S MANUAL ENGLISH THE LINCOLN ELECTRIC COMPANY 22801 St. Clair Avenue Cleveland, OH 44117-1199 U.S.A. Phone: +1.216.481.8100 www.lincolnelectric.com...
-
Page 2: Table Of Contents
English English 12/05 THANKS! For having chosen the QUALITY of Lincoln Electric products. Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified • immediately to the dealer. For future reference record in the table below your equipment identification information. Model Name, Code & Serial •... - Page 3 IN A LARGE ROOM OR OUTDOORS, natural SAFETY DEPENDS ON YOU ventilation may be adequate if you keep your head out of Lincoln arc welding and cutting equipment is designed the fumes (See below). and built with safety in mind. However, your overall USE NATURAL DRAFTS or fans to keep the fumes safety can be increased by proper installation ...
-
Page 4: Safety
CSA Standard W117.2-1974. A Free copy of MAY BE DANGEROUS "Arc Welding Safety" booklet E205 is available from the Lincoln Electric Company, 22801 St. Clair Avenue, 2.a. Electric current flowing through any conductor Cleveland, Ohio 44117-1199. causes localized Electric and Magnetic Fields (EMF). - Page 5 English English 4.b. Use suitable clothing made from durable flame- ELECTRIC SHOCK resistant material to protect your skin and that of CAN KILL. your helpers from the arc rays. 4.c. Protect other nearby personnel with suitable, non- 3.a. The electrode and work (or ground) circuits are flammable screening and/or warn them not to watch electrically “hot”...
- Page 6 English English WELDING AND CUTTING CYLINDER MAY EXPLODE IF SPARKS CAN CAUSE DAMAGED. FIRE OR EXPLOSION. 7.a. Use only compressed gas cylinders containing the correct shielding gas for 6.a. Remove fire hazards from the welding area. If this is the process used and properly operating not possible, cover them to prevent the welding regulators designed for the gas and sparks from starting a fire.
-
Page 7: Introduction
The packaging of the Cooler is designed to withstand shipping abuse, and contains a cardboard liner that surrounds the unit. If any shipping damage has occurred, contact your certified Lincoln distributor or service center. When unpacking the unit, avoid thrusting sharp objects through the carton liner, which may puncture the plastic reservoir. -
Page 8: Installation And Operator Instructions
English English Installation and Operator Instructions Read this entire section before installation or operation Controls and Operational Features of the machine. This machine will operate in harsh environments. However, it is important that simple preventative measures are followed to assure long life and reliable operation: Do not place or operate this machine on a surface SENSOR... - Page 9 English English WARNING Avoid kinking or putting sharp bends in any water lines. WARNING Never operate the cooler with case off. Coolant and Filling the Reservoir WARNING Before filling the coolant reservoir, disconnect cooler’s power lead to the power source. Figure 3 WARNING Avoid contact with coolant.
- Page 10 English English Priming Pump (only for first time use) Connecting the Cooling System Hoses and Bleeding the Cooling System The power source has to be turned off. • Connect the "inlet" hose of torch/gun • (colored or tagged blue on most hoses) into the outlet quick connect coupling [4] located on the front panel of the cooler.
- Page 11 WARNING it is recommended to contact the nearest Technical Mains supply network must be disconnected from the Service Center or Lincoln Electric. Repairs and machine before each maintenance and service. After modifications performed by unauthorized service or each repair, perform proper tests to ensure safety.
-
Page 12: Troubleshooting
WARNING If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact the nearest authorized Technical Service Center or Lincoln Electric for technical troubleshooting assistance before you proceed. PROBLEMS... -
Page 13: Electromagnetic Compatibility (Emc)
Lincoln Electric. Before installing the machine, the operator must check the work area for any devices that may malfunction because of electromagnetic disturbances. -
Page 14: Technical Specifications
English English Technical Specifications NAME INDEX ® COOL ARC K3950-1 INPUT Input Voltage U Input Amperes I 1max ® COOL ARC 115 V ± 10% 5,3 A Frequency EMC Class ® COOL ARC 60 Hz PARAMETERS RATING The cooling power of flow 1liter per minute at Maximum pressure rate temperature of 77°... -
Page 15: Weee
Spare Parts 12/05 Part list reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service • Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular •... -
Page 16: Electrical Schematic
English English Electrical Schematic ® COOL ARC... - Page 17 IM3050 05/2016 REV07 ® COOL ARC Spare Parts ..................................1 Figure A: Machine Assembly ............................1 Miscellaneous Items (not shown in figure A) ........................2 THE LINCOLN ELECTRIC COMPANY 22801 St. Clair Avenue Cleveland, OH 44117-1199 U.S.A. Phone: +1.216.481.8100 www.lincolnelectric.com...
- Page 18 IM3050 - Spare Parts IM3050 - Spare Parts Spare Parts Do Not use this Parts List for a machine if its code number is not listed. Contact the Service Department for any code numbers not listed. Use only the parts marked " " in the column under the heading number called for in the assembly page (# indicate a change in this printing).
- Page 19 IM3050 - Spare Parts IM3050 - Spare Parts BRACKET R-1019-331-1/02R BRACKET R-1019-325-1/08R CLAMP R-3019-289-1/08R RADIATOR COVER R-3020-002-1/08R RESERVOIR ASSEMBLY R-8040-242-4R RESERVOIR’S CAP 0653-321-006R PUMP R-8040-374-1R 0873-100-094R RADIATOR 3R 0871-100-022R MALE STUD FITTING 0744-320-057R FLOW SENSOR S1 R-8040-371-1R BRACKET R-1019-472-1R QUICK CONNECT COUPLING 0744-320-058R MALE STUD FITTING 0744-320-057R...
