ROCKWARE CORP
Industrial Bar Code Label Printing System


















Overview .............................................................................................................................. 2
A) Configuration ................................................................................................................... 3
B) Installation ....................................................................................................................... 6
C) Mission Control................................................................................................................ 7
D) Studio............................................................................................................................... 9
E) Print On Demand............................................................................................................ 12
F) View and Configure from a Remote Computer.............................................................. 13
G) System Backup and Restoration .................................................................................... 14
H) System Troubleshooting ................................................................................................ 15


TECHNICAL TRAINING GUIDE


Serial Print Server

ROCKBOX ™

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rockbox SPS-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rockware Corp Rockbox SPS-100

  • Page 1: Table Of Contents

    ROCKWARE CORP Industrial Bar Code Label Printing System            Serial Print Server    TECHNICAL TRAINING GUIDE                                  Overview ..........................2  A) Configuration ........................3  B) Installation ........................6  C) Mission Control........................ 7  D) Studio..........................9 ...
  • Page 2: Overview

    Technical Training Guide  Overview  The SPS‐100 Serial Print Server is a combination of industrial hardware and software to provide dynamic  bar code label printing that can be triggered by an in‐process PLC (Programmable Logic Controller).  This  guide is intended to aid in configuration, installation, label design, and troubleshooting of the Rockbox.   The SPS‐100 is powered by 110 VAC and is equipped to handle up to 4 independent industrial printers  via RS‐232 Serial interface.  This guide is intended to aid in the configuration, installation, label design,  and troubleshooting of the Rockbox.  Below lists terminology and definitions used throughout this guide.    Term  Definition  Rockbox  Refers to the SPS‐100 hardware and overall system.  PLC  Refers to the PLC providing the print trigger bit and label number register.  Network  Refers to the common Ethernet network the PLC and the Rockbox are connected  to.  Studio  Refers to the application intended for label and template creation and  modification.  The executable file for this application is SPS100_Studio and is stored  in the C:\Rockware directory of the Rockbox.  Mission Control  Refers to the application intended for reading values from PLC and for printing  labels automatically and manually.  The executable file for this application is  SerialPrint.exe and is stored in the C:\Rockware directory of the Rockbox.   Remote Computer  Refers to a desktop or laptop computer that is permanently or temporarily  connected to the Network and connects to Rockbox via Remote Desktop and the  Studio application.  Magic.Stick  USB Flash Drive used for system file backup  Database  MS SQL Server Express database used for storing configuration setting and label  formatting.  Back‐up Files (.bak) are used to backup and restore data.    See Network diagram below for general system layout.    USB to RS232 Converter (One Per Channel)     ...
  • Page 3: A) Configuration

    Technical Training Guide  A) Configuration  Rockbox SPS‐100s can be ordered completely preconfigured.  Below are instructions for manually  configuring.  1. Connect keyboard and mouse to available two available USB ports and connect a monitor to the  VGA port on back on the Rockbox.  2. Press Power Button on front of the Rockbox.  Figure 1 3. Set IP Address and subnet mask to a unique address compatible with the  triggering PLC.  o Double click Network Connections shortcut on the desktop. (See Figure 1)  o Right click on Local Area Connection and left click Properties. (See Figure 2)  o Left click on Internet Protocol (TCP/IP) and left click Properties. (See Figure 3)  o Manually set IP Address and Subnet Mask to allow Ethernet communication to PLC and  computers on the local network. (See Figure 4)    Figure 2  Figure 3 Figure 4                          4. Configure OPC Server software KepserverEx to allow reading of print trigger bit and  Figure 5 label number register from PLC. ...
  • Page 4 Technical Training Guide    Figure 6 Figure 7  Figure 8           Channel    Device                5. Configure SPS‐100 Comport Channels and Maintenance Functions.  o Left Click on Mission Control tab in task bar (See Figure 9).  Click on Settings Button in  Mission Control (See Figure 10).    Figure 10 Figure 9              o Enter Password (sps is default) (See Figure 11).  Make modifications where needed.  Click  SAVE DATA when finished with modifications (See Figure 12).    Figure 11     ...
  • Page 5 Technical Training Guide  Figure 12  Save Modifications   Click to modify PLC  Addresses for Trigger and  Label Number    Frequency of Auto  Backups  Backup File Location    and Name Number of Days to Store  Error Log Messages   Password used System  Wide.  Default is sps.  Comport Number.  If Channel not    used enter N/A.   Comport Setting.  Make sure  Printer dip switches match SPS‐100  settings for each Channel.    Channel ID that can be used to identify what  Channel was used to print each specific label    Normally COM8    Normally COM7       ...
  • Page 6: B) Installation

    Technical Training Guide  B) Installation   The Rockbox can be installed inside a well ventilated electrical cabinet or mounted externally (See  Figure 14c).  A 110 VAC power source is required.  Clean power and surge protection is  recommended to prevent device failures due to inconsistent power quality.  There are four USB to  RS‐232 Serial converters that are plugged into the back of the Rockbox.  Predefined USB ports have  corresponding COM number labels to identify which Comport each USB port connects to (See Figure  14a).  Connect serial cables from corresponding printers to applicable USB to RS‐232 Serial  converters (See Figure 14b).  Keyboard, mouse, and monitor are optional and do not need to be  connected for the Rockbox to be operational.  Remote Desktop can be set up on another computer  connected to the network to allow monitoring and troubleshooting of the system.  See Section F)  View and Configure from a Remote Computer for more detail on using Remote Desktop    Figure 14a  Figure 14b               Comport Labels    Figure 14c  Revision 1.0 ‐ 6 of 15 ...
  • Page 7: C) Mission Control

    Technical Training Guide  C) Mission Control  Mission Control is the application that monitors changes in print trigger and label numbers from the  PLC and sends applicable label strings to each printer when triggered.  This application must be  running at all times.  Anytime a configuration or PLC Address change is made, Mission Control will  need to be restarted.  If Mission Control is inadvertently or purposely shutdown it can be restarted  by double clicking the desktop icon shown in Figure 15.  Figure 15   Start and Stop OPC    Reading  and  Writing  Enable/Disable    Number of Times  Function Buttons  Windows Task  Last attempted Error  during  Ran and Successful      Status  Figure 16  Manager  Time Stamp  Execution  Executions                    Last Printed Label     ...
  • Page 8 Technical Training Guide  the Error text box there may be a configuration issue that will prevent automatic printing.  (See  Figure 16)    To view Actual PLC values for each Channel, left click the View Button.  If there is a network related  error, a Kepserver configuration error, or a PLC Address error, the Quality of the specific value will  display “BAD”.  If the value is being read properly then the Quality will display “GOOD”.  If displayed  values match actual values in the PLC, then all networking and OPC configuration has been  completed successfully.  (See Figure 17)    Figure 17        Maintenance – Database Backup and Deletion of Error Log  Maintenance functions include database backup and deletion of error log.  The number of Scans  (planned executions), the number of Executions (successful executions), and the Time Stamp of the  last Maintenance event occurrence is displayed in the Maintenance text boxes.  If there is an error  there will be a red “Error” message in the Error text box.  Errors usually are a result of database  backup locations being set to directories that don’t exist.  The Back‐up File Location can be changed  in Settings along with the frequency of Back‐up execution and the length of time to save Error Log  Messages.  (See Figure 16 and Figure 12)    Last Printed Label  The Last Printed Label for each Channel is displayed at the bottom of the Mission Control Page.  This  can be used as a troubleshooting tool to view exactly what gets sent to the printer including Time  Stamps and dynamic text that may change from one label to the next.  (See Figure 16)    Task Manager Enable/Disable  The Windows Task Manager is disabled on start up to prevent Mission Control from being shutdown  without knowledge of the password through Windows.  The Windows Task Manager can be enabled  by clicking the Task Manager Button and entering the correct system password.  The Windows Task  Manager can be disabled again by doing the same.  (See Figure 16)  Revision 1.0 ‐ 8 of 15 ...
  • Page 9: D) Studio

    Technical Training Guide  D) Studio  The Rockware SPS‐100 X4 Studio is a standalone application to provide an interface for creating labels  and label templates.  Left click the Studio Button (See Figure 16) to open or double click on the desktop  icon shown in Figure 18.  The system password is required to open this application.  SPS100_Studio.exe  is the executable file for the Studio application found in the C:\Rockware directory on the Rockbox.  This  file can run on any computer connected to the same network with a windows operating system and .NET  Framework 3.5 or higher.  See Section F) View and Configure from a Remote Computer for more detail.    Figure 18  Select Template  Click to SAVE DATA after    Export all  View, Delete  to use for label. View, Add,  creating a new label or  Click to start  label formats  Error Log  Modify,  modifying an existing  New Label to a text file  Delete  label    Delete Label Templates  Figure 19          Select Label to modify ,  delete, or view  ...
  • Page 10 Technical Training Guide  There are 12 reserved bracketed words that can be used to create dynamic labels.  The following 10  Dynamic Text reserved words are label specific and can only be used with Template labels.    [TEXT1]  [TEXT2]  [TEXT3]  [TEXT4]  [TEXT5]  [TEXT6]  [TEXT7]  [TEXT8]  [TEXT9]  [TEXT10]    Placing any of these reserved words in a label template will replace “[TEXT#]” with the text stored for  each Dynamic Text field for each label into the template when each label is printed.      The following two reserved bracketed words can be used for Template or Ad‐Hoc labels.     [ID]  [TIMESTAMP]    Placing [ID] into a Template or Ad‐Hoc label replaces “[ID]” with the Channel ID that is entered in  Settings for each Channel when the label is printed.  This word is intended to identify which Channel  printed each specific label in multi‐channel systems.  Placing [TIMESTAMP] replaces [TIMESTAMP] with  the current Time Stamp of the Rockbox when each label is printed.  The Rockbox Time can be modified  by double clicking the time displayed in the bottom right hand corner of the task bar and making the  required adjustments.  The Time Stamp is printed on the label and/or bar code in the following format:      ddmmyyhhnnss    d = day  m = month  y = year  h = hour  n = minutes  s = seconds    Labels and templates can be added or changed anytime and changes will immediately take place the  next time a print trigger event occurs.   ...
  • Page 11 Technical Training Guide   Template Creation and Modification  To add, modify, or delete templates, left click the Templates Button (See Figure 19).  See Figure 20 for  detail on Template Design Page.      Click to SAVE DATA after  Export all  creating a new template  template    or modifying an existing  formats to a  Click to start    template  text file  Figure 20  New Template       Select Template to    modify, delete, or  view  Delete  Label Name for  Template    Identification  Dynamic Text    insertion Template  Time Stamp  formatting    insertion including ...
  • Page 12: E) Print On Demand

    Technical Training Guide  E) Print On Demand  To manually print labels to test comport communications, to test a label format, or to batch print, left  click the Print On Demand Button (See Figure 16).  Any label format loaded into the SPS‐100 database  can be retrieved from PLC ID # ‐ Label Name pull‐downs.  Text can be typed or copy and pasted into the  white Label Editor and can be printed on any of the four available channels that are connected to a  printer.  This is a good way to test label formatting prior to running live.  It also is a good way to ensure  Channel/COM configuration is correct.  Batch printing can be performed by specifying the Quantity of  Labels and specifying the Time (Seconds) Between Labels prior to left clicking Print.  (See Figure 22)      Click to send Label  Editor String to    Figure 22  Click to pull in Label Printer  Select Label  Label Editor  can type  Used for Batch Printing copy or paste  inside editor  Revision 1.0 ‐ 12 of 15 ...
  • Page 13: F) View And Configure From A Remote Computer

    Technical Training Guide  F) View and Configure from a Remote Computer  F) View and Configure from a Remote Computer  Once configured and connected to the network, Windows Remote Desktop can be used on a stationary  Once configured and connected to the network, Windows Remote Desktop can be used on a stationary  or mobile computer connected to the network to log on to the Rockbox for troubleshooting or  or mobile computer connected to the network to log on to the Rockbox for troubleshooting or  configuration changes.  Enter the IP Address assigned to the Rockbox into the Computer Text Box and  configuration changes.  Enter the IP Address assigned to the Rockbox into the Computer Text Box and  left click Connect (See Figure 23).  Enter trtguest as User Name and leave the Password blank.  When  left click Connect (See Figure 23).  Enter trtguest as User Name and leave the Password blank.  When  finished working on Rockbox, DO NOT Log Off or Shutdown the Rockbox.  Left click Start and left click  finished working on Rockbox, DO NOT Log Off or Shutdown the Rockbox.  Left click Start and left click  Disconnect (See Figure 24).  Logging off or shutting down Rockbox will prevent SPS‐100 from functioning.  Disconnect (See Figure 24).  Logging off or shutting down Rockbox will prevent SPS‐100 from functioning.      Figure 23      User Name: trtguest  User Name: trtguest                          Password: [blank] Password: [blank]          ...
  • Page 14: G) System Backup And Restoration

    Technical Training Guide  G) System Backup and Restore  Backup  The SPS‐100 database is backed up automatically during Maintenance events.  See Section C) Mission  Control ‐ Maintenance – Database Backup and Deletion of Error Log for more detail.  The default  location for this backup is set to the D drive which is the Magic.Stick that comes with the Rockbox.  This  is done to preserve data in the event of a hard drive failure.  The file name and location of all backups  will be what is set in the Back‐Up File listed in Settings (See Figure 12).  The file should have a .bak  extension.  A backup file can be created manually be left clicking the Backup DB Button (See Figure 16).    Enter the directory and the file name of the backup file in the input box and click OK (See Figure 26).  The  default backup file will be the Back‐Up File listed in Settings.  Backing up to this file will overwrite the  existing backup file saving the most recent updates.    Figure 26                    Restoration  In the event a Rockbox needs to be replaced with another unit, a backup file can be restored on any unit  to restore all configurations and label formatting data.  Follow the below instructions to restore a  database.      1. Plug in Magic.Stick with database back‐up file into new Rockbox.  Only one Magic.Stick can be  entered into a Rockbox at any given time.  Remove any other Magic.Sticks prior to plugging in.  2. Left click the Restore DB Button (See Figure 16)  3. Enter system password which should be “sps” unless otherwise changed.  4. Select the back‐up file and left click Open.  Shutdown and restart Mission Control to complete.   (See Figure 27)  Figure 27  Revision 1.0 ‐ 14 of 15 ...
  • Page 15: H) System Troubleshooting

    Technical Training Guide  H) System Troubleshooting  Power Error  If the computer will not power up there could potentially be a power supply, motherboard, or hard drive  issue.  Try powering up from a different power source.  If it doesn’t start, remove the Magic.Stick and  plug into a spare Rockbox SPS100.  Follow instructions for restoring the system back‐up file in Section G)   System Backup and Restore – Restoration.  If the Rockbox is still under warranty, send to Rockware Corp  for repair.    Network Error  If there are issues reading PLC trigger and Label Number values there potentially could be a network  error.  Click settings Network errors will occur if the IP Address of the Rockbox does not match the IP  Address of the PLC or if the IP Address of the Rockbox is a duplicate IP with another device on the  network.  To determine if there is successful network communication:  1. Left click Start.  2. Left click Run.  3. Type “Ping “ and the IP Address of the PLC from the Rockbox.  If there is no communication than  there will either be a “Request Time Out” or another “Communication Related Error”.  4. Type “Ping “ and the IP Address of the Rockbox from a Remote Computer.  If there is no  communication than there will either be a “Request Time Out” or another “Communication  Related Error”.  5. Reset and recheck IP Addresses along with the functionality of any network switches across the  network if Ping checks are not successful.    Kepserver Channel or Device Configuration Error  If there are issues reading PLC Trigger and Label Number values there potentially could be a Kepserver  configuration error.  Make sure the Channel has the correct device driver assigned for the specific make  and model of the PLC type being used.  Make sure the Device has the correct IP Address and IP Address  configuration for the PLC type being used.  See Section A) Configuration – Item 4 for more detail.    Comport/Channel Error  If there are no issues reading the PLC Trigger and Label Number values and labels do not print there  could potentially be a comport configuration problem.  Make sure the correct COM# is entered for each  channel being used in Settings.  Also make sure that the Baud Rate, Parity, Data Bits, and Stop Bits match  how the printer is configured.  Printer settings are usually set via dip switches.  COM errors will show up ...
