McLelland Mix-Lite Owner's Manual

Usb audio interface

Advertisement

Quick Links

Mix-Lite
USB AUDIO INTERFACE
L
MIC/INST
OWNER'S MANUAL
Line
MIC
R
CPU
MIC/
PHANTOM
+48V
Min
Mix-Lite
USB Audio Interface
CLIP
CLIP
CLIP
SIGNAL
SIGNAL
SIGNAL
INST L
INST R
MIC/
Max
Min
Max
POWER
ON
OFF
RCA IN
Min
Max

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mix-Lite and is the answer not in the manual?

Questions and answers

Summary of Contents for McLelland Mix-Lite

  • Page 1 Mix-Lite USB AUDIO INTERFACE Mix-Lite USB Audio Interface Line CLIP CLIP CLIP POWER SIGNAL SIGNAL SIGNAL INST L INST R MIC/ MIC/ RCA IN PHANTOM +48V MIC/INST OWNER’S MANUAL...
  • Page 4 Please read and observe all safety instructions detailed on each page. INTRODUCTION The McLELLAND Mix-Lite USB audio interface is designed as an audio interface between analog and digital audio sources, recorders and a computer with USB 1.1 or 2.0 connection. It is suitable for use on stage and in the sound recording studio as well as for home recording and multi-media applications.
  • Page 5: Front Panel

    FRONT PANEL Mix-Lite USB Audio Interface Line CLIP CLIP CLIP POWER SIGNAL SIGNAL SIGNAL INST L INST R MIC/ MIC/ RCA IN PHANTOM +48V MIC/INST 1. Mic/instrument input: Balanced combo connectors(XLR/6.3mm jack) either for connecting microphones via XLR or 6.3mm jacks or for high-impedance music instruments such as electric guitars or electric bass guitars via 6.3mm jacks.
  • Page 6: Rear Panel

    1. USB port: Type B connector, for connecting a computer. The audio data, digitized in the interface, is sent to your computer via this USB port. It also acts as power supply for the Mix-Lite. 2. Mix control: Selects and fades the signal for the analog outputs of the audio interface: •...
  • Page 7 APPLICATION LEVEL MONITOR S/PDIF IN RCA IN OUTPUT PHANTOM +48V S/PDIF OUT PHANTOM 9V DC MIC/INST +48V CHANNEL A CHANNEL B POWER HPD 1500 Dual Channel Professional Power Amplifier...
  • Page 8 CONNECTIONS Both microphones and high-impedance music instruments such as electric guitars or electric bass guitars can be connected to the Mic/Instrument inputs: • Connect microphones(balanced or unbalanced) via XLR plugs or 6.3mm jacks. Balanced cables provide +6 dB more output and guarantee a better protection against interference in case of long cable runs.
  • Page 9: Operation

    OPERATION Switch on the audio interface with the POWER button. The button lights red. As soon as the audio interface is switched on it is recognized by the computer as USB audio device. With the button MIC/LINE adjust the Mic/Instrument inputs to the connected sources: •...
  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS Power supply: 9V AC/DC, 150mA via USB port, supplied power unit or battery Power consumption: Frequency range: 20 - 20,000 Hz, ±1 dB THD: <0.01% S/N ratio: 90 dB Input impedance: 1k Ohm(Mic), 40k Ohm(Line) Maximum gain: 48 dB Inputs: 2 x Mic/Instrument(combination XLR/6.3mm jack, bal.) 1 x line(stereo RCA)
