Wireless Modem Assembly
Part Number 1815-740

IMPORTANT!

Wireless modems are configured for DoorKing systems. Do not change the switches on the
modems. Doing so will change their programming and the modems will not function with DoorKing
products.

Parts List for P/N 1815-740

1. P/N 1815-726 - RF Modem USB Configured includes:
Quick Start Guide
X-CTU software CD
Antenna 1/2 Wave Dipole
USB Cable, 6-Ft.
Power adapter, 9V 1A
2. P/N 1815-725 - RF Modem RS 232 Configured includes:
Antenna 1/2 Wave Dipole
Serial Loop Back Adapter
Null Modem Adapter
Power adapter, 9V 1A
3. P/N 1818-040 - RS 232 Cable 6-Ft.
4. P/N 1815-721 – CD MaxStream 2060 Files
5. P/N 1815-760 – Manual

Notes:

You must install USB driver on your PC using the X-CTU CD.
The X-CTU software, the MaxStream CD and the RED serial loop back adapter are
used for trouble shooting only.
You may cut and splice the wires for the power adapters if necessary. However,
you must observe the polarity! I.E., striped wire to striped wire. Permanent
damage will occur to the modem if polarity is incorrect! For wire runs up to 100
feet, use 22 AWG wire. For wire runs up to 200 feet, use 18 AWG wire.
If installed outdoors, the modem and power supply must be installed in a rain-tight
enclosure.
P/N 1815-760 REV A 10/07
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1815-740 and is the answer not in the manual?

Questions and answers

Summary of Contents for DoorKing 1815-740

  • Page 1 Part Number 1815-740 IMPORTANT! Wireless modems are configured for DoorKing systems. Do not change the switches on the modems. Doing so will change their programming and the modems will not function with DoorKing products. Parts List for P/N 1815-740 1. P/N 1815-726 - RF Modem USB Configured includes: •...
  • Page 2 Serial Loop Back Adapter MaxStream 2060 Files Wireless Modem Assembly P/N 1815-740 You must install the USB driver on your PC using the X-CTU CD RS232 Cable P/N 1818-040 Used for trouble shooting only RF Modem Ass’y RS 232 Configured P/N 1815-725 Dipole Antenna Power wires may be cut and spliced if necessary.
  • Page 3 For any given cable, the longer the cable, the greater the loss becomes. Often, a longer serial cable to the DoorKing system or a longer USB cable to the PC can be used to minimize the length of the coax cable.
