Dreamsky TSF 40 User Manual

Digital satellite & terrestial finder

Advertisement

Dreamsky
R
TSF 40
DIGITAL SATELLITE & TERRESTIAL FINDER
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSF 40 and is the answer not in the manual?

Questions and answers

Jackie Smith
January 29, 2025

How do I make my weather station stay on all the time?

User image 679a1e9ecc796
1 comments:
Mr. Anderson
February 10, 2025

The Dreamsky TSF 40 is equipped with a rechargeable Li-ion battery (12.6V, 2,200 mAh) that provides up to 4 hours of operation. To keep it powered continuously, you can:

1. Use the Adaptor/Charger – Keep the device plugged into the provided adaptor/charger to maintain power.
2. Use the Car Charger Cable – If using the device in a vehicle, connect it to the car charger cable.
3. Ensure Proper Charging – Before first use, charge the battery for at least three hours to maximize battery life.

By keeping it connected to a power source, you can operate the device continuously without relying solely on the battery.

This answer is automatically generated

Summary of Contents for Dreamsky TSF 40

  • Page 1 Dreamsky TSF 40 DIGITAL SATELLITE & TERRESTIAL FINDER USER'S MANUAL...
  • Page 2 Thank you for purchasing this product and therefore trusting our company. To obtain the best performance from this product, please read the manual carefully before using for first time. The technical specifications and operating methods included in this manual are subject to changes without notice. In case of any inquires after a period of usage, please contact the manufacturer to the latest news and updates.
  • Page 3: Table Of Contents

    Table of Contents Chapter I.Introduction............4 Chapter II.Function........…………….5 A.Front Panel............5 B.Remote Control..........7 C.Quick Operation..........8 1.Language setting………………………………8 2.DVB-S Signal Finding…………………………9 3.DVB-T Signal Finding....…………..12 D.Detailed operation Guide........14 1.Power On ……………......... 14 2.Installation... ………....…………..14 3.System Setting..........16 4.Spectrum............17 5.Angle Calculation.........17 6.Channel Information........18 7.Channel list...........18 Chapter III.
  • Page 4: Chapter I.introduction

    Chapter I Introduction Digital satellite finder ASF200SF is professional instruments dedicated to aligning and setting satellite dishes quickly, easily and accurately. Designed for field measurement, all instruments are compact (0.9kg with the battery), autonomous (packed with battery and fast charger), rainproof designed and are equipped with a 3.5 Inch High Definition TFT LCD Screen for better readability.
  • Page 5: Chapter Ii.function

    Chapter II Function A.Front Panel <Figure2-1> 1.LNB INPUT: Satellite signal input port, connects directly to satellite antenna with coaxial cable 2.ANT INPUT: Terrestrial signal input female port. 3.LCD Screen: Shows menus and programs clearly.
  • Page 6 4.POWER LIGHT: Light up while power is on. 5.LOCK LIGHT: This will be lighted when signal is locked 6.22K/13V/18V LIGHT: Indicates the mode of 22K/13V/18V. 7.FUNCTION KEY: Consist of 2 keys, F1 – F2. F1: Changes the signal bar on SIGNAL FINDING menu. F2: Actives DiSEqC1.2 function on the SIGNAL FINDING menu.
  • Page 7: B.remote Control

    18.Charge port: Allows the external power supply as well as the charging of the battery. 19.USB Port: Used to connect to PC for upgrade. 20.R/L/VIDEO: Output audio and video signa.l 21.AV IN: Input audio and video signal to LCD screen. B.Remote Control (1) 0/22K:...
  • Page 8: C.quick Operation

    (9)TV/RADIO: Selects and plays TV/Radio channel in playing mode. (10)MENU Key: Display the main menu or return to the previous one. (11) EXIT Key: Cancel the selection and exit from the present menu. (12) 0-9 Numerical Key: Enter numerical settings directly. (13) ANGLE Key:...
  • Page 9: Dvb-S Signal Finding

    DVB-S SIGNAL FINDING: 1.The DVB-S finding menu shown as <Figure2-4>. <Figure2-4> The modifiable parameters are the following:  SATELLITE NAME: Use [◄][►] button to scroll through the stored memory and select required satellite. LNB SETTING: Select the item needs editing, and set its parameters as desired.
  • Page 10 (b) TP NIT: Scan the transponders in one certain network. SAT SCAN: Scan all the transponders in one satellite (these transponders have been set in advance). (d.) Blind 8MHz: Blind scan the frequency from 950-2150 by step 8MHz; see<Figure2-6>. <Figure2-6> (e.) Blind 12MHz: Blind scan the frequency from 950-2150 by step 12 MHz.
  • Page 11 S/N : reflects the signal to noise in dB S/N : reflects the signal to noise in dB S/N : reflects the signal to noise in dB S/N : reflects the signal to noise in dB Outdoor mode <Figure2-8> 3.MOTOR SETTING: Press F2 to activate the DiSEqC1.2 control menu , see<Figure2-9>...
  • Page 12: Dvb-T Signal Finding

    <Figure2-10> Choose your desired satellite at the Satellite Name option. Give l Latitude. your location value to the Local Longitude and Loca Enter the position of your selected satellite to the Satellite Longitude if it is not correct. Press OK to select USAL POSITION, then the motor will turn toward your selected satellite as calculating its position DVB-T SIGNAL FINDING: 1.
  • Page 13 (a)TP Scan: Use [◄][►] button to change the SCAN CHANNEL item to the option TP SCAN, then press OK to scan. see<Figure2-12>, <Figure2-12> (b)Scan All: Use [◄][►] button to change the SCAN CHANNEL item to the option SCAN ALL, then press OK to scan. see<Figure2-13> <Figure2-13>...
  • Page 14: D.detailed Operation Guide

    Zoom mode: <Figure2-14> S/N : reflects the signal to noise in dB Q: reflects the signal quality (%) S: reflects the signal level (%) Press [◄][►] key to adjust the volume of beep. Multi-Channel mode: 3.FAV Channel setting: Press F2 to show the setting menu D.
  • Page 15 see <Figure2-15> <Figure2-15> 1. SATELLITE NAME: Use [◄][►]button to browse stored satellites or press OK to show the satellite list for selection. 2. LNB TYPE: Use [◄][►]button to browse all options. 3.22K SWITCH: Use [◄][►]button to shift AUTO/ON/OFF 4.LBN POWER: Use [◄][►]button to choose OFF /ON 5.DISEQC1.0: allows switching among DISEQC port A/B/C/D 6.DISEQC1.1: allows switching among DISEQC switch from port 1 to port 16,...
  • Page 16: System Setting

    DELETE CHANNEL: Deletes the current channel. Press 3 to DELETE CHANNEL, and the DELETE CHANNEL on the help information will be highlighted. Use [▲] [▼] key to select a channel press OK to delete. NAME EDIT: Press 4 to NAME EDIT, and NAME EDIT on the help information will be highlighted.
  • Page 17: Spectrum

    2.OSD TRANSPARENT: Adjust OSD transparent mode. 3.SLEEP TIMER: Set up the sleep timer mode for auto shut off timer 4.PROFILE : Shift between the normal mode and outdoor mode 5.LOCK BEEP: Switch on/off the beep function while signal locked 6.FACTORY DEFAULT: Remove all the user data, press OK to confirm on the item.
  • Page 18 5.Freq: to show the value of current focus frequency 6.Green axis indicates focused frequency, can be moved by up & down Key for faster movement or by left & right keys for slower movement. 7.Top maker will be shown on the high level position of spectrum. 8.The user can move the green column to the peak,and press OK to scan out the channels.
  • Page 19 <Figure2-18> 10.F2 key to change the scan step 11.F1: to switch ZOOM mode and NORMAL can mode 12.Green axis indicates focused frequency, can be moved by up & down Key for faster movement or by left & right keys for slower movement.
  • Page 20: Angle Calculation

    6)ANGLE CACULATION 1.Press ANGLE button to display the Calculation menu, see <Figure2-19> <Figure2-19> 2. SATELLITE NAME: Use [◄][►]button to browse stored satellites or press OK to show the satellite list for selection. 3.Give your location value to the Local Longitude and Local Latitude. 4.Move cursor to ANGLE CACULATION and press OK to calculate Move cursor to ANGLE CACULATION and press OK to calculate the dish.
  • Page 21: Channel List

    7)CHANNEL LIST Press OK in the playing mode to get TV list displayed, see < Figure2-21> < Figure2-21> 1.Scroll the cursor to choose a new channel and for play it by OK key. 2.EXIT key for returning back to playing mode. 8)TV/RADIO MODE CHANGE Press TV/RADIO key in the playing mode to shift alternatively.
  • Page 22 QPSK Front end Demodulator 2Mbps~45Mbps Symbol rate For DVB-S SCPC and MCPC Capable Spectral inversion Auto conversion Type IEC 169- Frequency Range VHF and UHF Tuner&Channel Bandwidth 8MHz or 7MHz or 6MHz For DVB-T Input impedance 75 ohm unbalanced 75 ohm unbalanced -78 ~ -20dBmV Modulation COFDM...
  • Page 23 MPEG 1 layer 1&2 Type MPEG Audio Mono 32,44.1 and 48KHz Sampling rates USB type Serial data interface Connector 2200 mA Li-oN Battery Power supply 13.3Volt Supply voltage charger 90-240V Panel connectors Digital tuner input Digital tuner input Size 102x34x180 (mm) Physical Specification Weight(Net) 0.9 Kg...
