HA-009 PKE
HA - 280 PRO
User / Installer Manual
INSTALLERʼS MANUAL
Manufacturer:
COMMERCIAL ELECTRONICS C O L T D
264 HAYDONS ROAD, WIMBLEDON, LONDON SW19 8TT. UK
TEL: +44 020 8404 7105 FAX: +44 020 8404 7104
http://www.hawkcaralarm.com e-mail: info@hawkcaralarm.com
Manufactured by Commercial Electronics Co Ltd. Great Britain. © Commercial Electronics 2015.
6
Advertisement
Summary of Contents for Hawk HA-009 PKE
- Page 1 HA-009 PKE HA - 280 PRO User / Installer Manual INSTALLERʼS MANUAL Manufacturer: COMMERCIAL ELECTRONICS C O L T D 264 HAYDONS ROAD, WIMBLEDON, LONDON SW19 8TT. UK TEL: +44 020 8404 7105 FAX: +44 020 8404 7104 http://www.hawkcaralarm.com e-mail: info@hawkcaralarm.com...
-
Page 2: Table Of Contents
Unlock Doors HAWK Car Finder Congratulations on the purchase of your state of the art HAWK universal upgrade remote control locking kit. This system has been designed to provide years of trouble-free operation. This owner’s guide should help you to get the most out of your system. Please take the time to read it prior to using the system. -
Page 3: Introduction
Car Finder Car Finder Congratulations on the purchase of your state of the art HAWK universal upgrade Lock Doors Lock Doors remote control locking kit. This system has been designed to provide years of... -
Page 4: Locations For The Control Box
HA-009 PKE universal upgrade remote HA-009 PKE universal upgrade remote 5. Dual Lock and unlock To have dual locking and unlocking feature enable change JP 2 – to pin number 2-3 control locking kit install guide control locking kit install guide on the main PCB (factory default pin number 1-2). -
Page 5: (Central Door Locking)
Locations for the status LED Locations for the status LED Things to remember when positioning the status LED: Things to remember when positioning the status LED: • It should be visible from both sides and the rear of the vehicle, if possible. •... -
Page 6: Primary Harness Wire Connection Guide
This system was designed with the ultimate in flexibility and security in mind. Please read the instructions carefully to ensure a thorough understanding and how it operates; also see wiring diagram of HA-009 PKE. BLACK WIRE: Ground Input (-). -
Page 7: Wiring Diagram
PINK WIRE: PINK WIRE: PINK WIRE: Negative output (-) 250mA Window Closer. 17 second negative output. Negative output (-) 250mA Window Closer. 17 second negative output. Negative output (-) 250mA Window Closer. 17 second negative output. NOTE: MUST USE window closer module HA-64U (optional extra). NOTE: MUST USE window closer module HA-64U (optional extra). -
Page 8: Central Locking Technical Diagrams
Central locking technical diagrams Diagram A Diagram A Negative locking Negative locking PRIOR TO MAKING THE CONNECTION ENSURE PRIOR TO MAKING THE CONNECTION ENSURE THE ALARM IS PROGRAMMED FOR THE THE ALARM IS PROGRAMMED FOR THE APPROPRIATE LOCKING PULSE APPROPRIATE LOCKING PULSE INTERNAL ALARM INTERNAL ALARM RELAYS... - Page 9 Central locking technical diagrams Diagram C Diagram C Single point locking Single point locking PRIOR TO MAKING THE CONNECTION ENSURE PRIOR TO MAKING THE CONNECTION ENSURE THE ALARM IS PROGRAMMED FOR THE THE ALARM IS PROGRAMMED FOR THE APPROPRIATE LOCKING PULSE APPROPRIATE LOCKING PULSE POSITIVE POSITIVE...
- Page 10 Central locking technical diagrams Diagram E Actuator interrupt (negative at rest) PRIOR TO MAKING THE CONNECTION ENSURE THE ALARM IS PROGRAMMED FOR THE APPROPRIATE LOCKING PULSE POSITIVE VEHICLE (+12v) CENTRAL LOCKING RELAY INTERNAL ALARM RELAYS ORANGE WHITE YELLOW LOCK ORANGE / BLACK WHITE / BLACK YELLOW / BLACK UNLOCK...
- Page 11 Central locking technical diagrams Diagram C Diagram C Single point locking Single point locking PRIOR TO MAKING THE CONNECTION ENSURE PRIOR TO MAKING THE CONNECTION ENSURE THE ALARM IS PROGRAMMED FOR THE THE ALARM IS PROGRAMMED FOR THE APPROPRIATE LOCKING PULSE APPROPRIATE LOCKING PULSE POSITIVE POSITIVE...
- Page 12 Manufactured by Commercial Electronics Co Ltd. Great Britain. © Commercial Electronics 2016.
