- Page 1 Boombox with Radio, Cassette, Bluetooth , & SD/MMC/USB Ports ® MODEL NUMBER: 77020 USER GUIDE After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL: enquiries@quesh.co.uk...
-
Page 2: Table Of Contents
Contents Welcome Section 2-3. General Information & Safety Instructions Contents & Features Layout Connecting Power • Mains Lead • Batteries On/Off • Turning The Radio On • Turning The Radio Off Modes • Radio • Tape • /Music Radio Mode •... -
Page 3: Welcome Section
Welcome Section Congratulations! You have made an excellent choice with the purchase of this quality MAXTEK product. ® By doing so you now have the assurance and peace of mind which comes from purchasing a product that has been manufactured to the highest standards of performance and safety, supported by the high quality standards of Quesh Ltd. -
Page 4: General Information & Safety Instructions
General information & Safety Instructions This product uses 4 x ‘D’ 1.5V sized batteries (not included). Do not dispose of batteries in your household waste. Please contact your local authority for details on safe disposal. • Never throw batteries into a fire or expose to excessive heat sources. •... - Page 5 General information & Safety Instructions Please read the following safety information before use. C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN • To avoid risk of electric shock do not attempt to open this appliance. •...
-
Page 6: Contents & Features
Contents & Features Contents 1 x Boombox 1 x Mains Lead Features • Bluetooth V4.1 • FM Band (88MHz-108MHz) • MW Band (530KHz - 1600KHz) • SW Band (3.0MHz - 23.0MHz) • USB Port • SD/MMC Card Port • 3.5mm Headphone Port •... -
Page 7: Layout
Layout Cassette Controls Fast Forward Rewind Bass Dial Stop / Eject Play Aerial Volume Dial Pause Record Tuning Dial Function Band Selection USB Port Switch Switch SD/MMC Skip Back Card Port Play/Pause Skip Forward Digital Controls Mains Input Battery Bay Headphone Port After Sales Support... -
Page 8: Connecting Power
Connecting Power Mains Lead This radio uses a 13A, 2 pin mains power lead (supplied). Plug the mains lead into a suitable mains socket and connect the lead to the mains input on the back of the radio. Batteries This radio uses 4 x 1.5V ‘D’ cell type batteries (not supplied). Do not keep batteries in the radio for long term storage. -
Page 9: On/Off
On/Off Turning The Radio On Once the radio has power either supplied by the mains or batteries, the radio is constantly on. Turning The Radio Off The only way to turn the radio off completely is to turn it off at the mains and unplug it or remove the batteries out of the back. -
Page 10: Radio Mode
Radio Mode Using The Radio The radio is able to receive FM, MW and SW band radio signals. The band selector switch will allow you to choose from the following: SW2 - 13.0MHz - 23.0MHz (Short Wave) SW1 - 3.0MHz - 13.0MHz (Short Wave) MW - 530KHz - 1600KHz (Medium Wave) FM - 88MHz - 108MHz (Frequency Modulation) Tuning The Radio... -
Page 11: Tape Mode
Tape Mode Using The Cassette Tape Deck Press the ‘STOP/EJ.’ button to open the cassette tape tray. Insert the cassette tape upside down and with the letter facing outwards of the side you wish to play. This is normally indicated with an ‘A’... -
Page 12: Cassette Tape Deck Controls
Tape Mode Cassette Tape Deck Controls PAUSE Pause the cassette tape while playing or recording. STOP/EJ. Stops the current action / Eject the cassette tape. F.FWD Fast Forwards the inserted cassette tape. REW. Rewinds the inserted cassette tape. PLAY Plays the inserted cassette tape. Records on the inserted cassette tape. -
Page 13: Recording From The Radio
Tape Mode Recording From The Radio Once the cassette tape is ready and inserted you will need to setup the radio. Make sure the function switch is set to ‘RADIO’ and fully extend the telescopic aerial. Tune the radio into the station you want to record and make sure the signal is as clear as you can get it. -
Page 14: Recording From Bluetooth
Tape Mode Recording From A Bluetooth Source Once the cassette tape is ready and inserted you will need to setup the radio. Make sure the function switch is set to ‘ /MUSIC. In this mode you will be able to record from a bluetooth connected device like a smart phone or tablet. -
Page 15: Music Mode
/Music Mode In this mode you can play music from a SD/MMC card, a USB stick or a compatible bluetooth device. In this mode the LED light will quickly until it is paired with a device or a SD/MMC/USB storage device has been connected. -
Page 16: Pairing A Bluetooth Source
Pairing A Bluetooth Source When the radio is this mode, the bluetooth function is automatically in pairing mode. Search for “MAXTEK” on the available device list and select it on your device that you want to pair to the radio. There is no security code and the unit will pair up straight away. -
Page 17: Specifications
Specification Boombox with Radio, Cassette, Bluetooth, SD/MMC/USB Ports General Chipset/Solution: CSSI 2002S Approx Weight: 1.2Kg Approx Dimentions: 310mm x 85mm x 110mm Mains Adaptor: 240V/13A Bluetooth Bluetooth Ver: Frequency Range: 2.4GHz Bluetooth Protocol: A2DP, AVRCP, HFP Bluetooth Range: Battery Battery Type: 4 x ‘D’... - Page 18 Warranty Certificate Warranty This product is warranted to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour.
- Page 19 Warranty Card Boombox with Radio, Cassette, Bluetooth , & SD/MMC/USB Ports ® Model Number: 77020 Please keep your purchase receipt together with your warranty card Name: Address: Date of purchase: Location of purchase: Fault Description: We recommend that you attach a photocopy of your receipt, showing the date of purchase, to this warranty card and keep it for your reference.
