Page 4: Introduction
1 Introduction 1.1 Atlas The Atlas 2D analysis system is the ultimate 2D imaging CCD combined Spectrometer choices with a spectrometer. The Atlas combines two fundamentally different Spectral engine (380nm-780nm) devices in one solution giving it unprecedented capabilities and flexibility. -
Page 5: Interfaces
GUI software supplied on USB connector the USB stick Camera ethernet connector 2.2 Power connections Atlas has a single power supply. Always make sure to use the one supplied by Admesy. Others are not guaranteed to work and may even damage the Atlas. -
Page 6: Atlas Communication
You can install our standard GUI or you can make you own GUI. The engine software is the heart of the Atlas, it takes care of everything. It controls the Atlas, it takes care of the calculation necessary for 2D analysis (mura, uniformity…etc). -
Page 7: Gui
4.4 Atlas controlled remotely The graphical user interface sends commands trough TCP/IP from a different PC to the Atlas engine which on its turn takes care of the received command and sends back data to the GUI if applicable. Each software packages is on a different PC. -
Page 8: Device Drivers
5 Device drivers 5.1 Atlas engine In order to run the Atlas both the GigE driver and the NI-VISA are necessary. Atlas is only supported under 64 bit systems. NI-VISA GigE Windows 7 (64 bit) · · Windows 8 (64 bit) Not tested¹... -
Page 9: Command Set Structure
6.2 Command structure Every command starts with a colon “ : ”, which identifies the root of the The functions of the Atlas can be best described via the following categories. command tree. Each further keyword is also separated a colon. In case parameters need to be specified, the last keyword and parameters are ... -
Page 10: Data Communication
6.3 Data communication Write and read for 2D data commands Every command starts with a colon “ : ”, which identifies the root of the command tree. Each further keyword is also separated by a colon. In case parameters need to be specified, the first parameters is separated by a Send ASCII command terminated with CRLF. -
Page 11: Command Set Description
7.2 System commands In below chapters an overview is given for every command. After that a The following commands can be used to control the Atlas or read back detailed description is given in combination with an example. Termination information. System commands are general commands. -
Page 12: Idn
The result can be seen in table below: 7.2.2 :*RST? Device Description The settings of the Atlas engine are reset to the original settings of the 8MP RGB + spectrometer selected project. Example: 8MP RGB + spectrometer + flicker unit Write... -
Page 13: System:wait
7.2.9 :SYSTem:WAIT 7.2.12 :SYSTem:CONFig? A wait time in ms can be added in the flow. Example: Returns hardware configuration. Example: Write :SYSTem:WAIT ASCII CRLF Write : SYSTem:CONFig? ASCII CRLF Read Pass ASCII CRLF Read ASCII CRLF The return is always a pass. The result can be seen in table below: 7.2.10 :SYSTem:PROJect:OPEN Project settings can be loaded/opened. -
Page 14: Display Settings Commands
:SENSe:WD 1: height Set height(working distance) of atlas to display in mm 7.3.1 :SENSe:FREQ Set frequency of the Device Under Test. Many samples which need to be tested have their own refresh frequency (display 60Hz for example) or a PWM frequency (LED panels, 1kHz). -
Page 15: Device Configuration Commands
7.4 Device configuration commands Integration time of the 2D imager is set to 10.000 us (10ms). Configuration commands are used to set parameters of the Atlas that are used by the measurement functions. The settings are used globally by Device Description Min. -
Page 16: Sense:autorange
Write :SENSe:ADJMin 1,40 ASCII CRLF Spectrometer Read Not Applicable Luminance meter Note: not all Atlas configurations have the luminance/flicker unit incorporated. Target adjustment level of the spectrometer is set to 40%. 7.4.4 :SENSe:MAXInt Device Description Min. level Max. level Recommended level Set maximum allowable integration time when in auto-range mode. -
Page 17: Sense:shutter
7.4.6 :SENSe:SHUTter Close or open the shutter. Example: Write :SENSe:SHUTter 0,1 ASCII CRLF Read Not Applicable Close the shutter of the 2D CCD imager, 1 is close shutter and 0 is open shutter. Device Description 2D imager Not Applicable, will be added in future Not Applicable, will be added in future... -
Page 18: Measurement And Calculate Commands
Capture raw image, this function :MEAS:Y None Returns luminance measure is used for calibration. Image data name can be RED, GREEN or Note: not all Atlas configurations have the luminance/flicker unit incorporated. BLUE :CAMEra:CALIbrate None Calculates the calibration matrix for the display :CAPTure:XYZImag... -
Page 19: Capture:display
AR ratio. As a check the AR will be send back. In case the operating the atlas. In this function the camera detects where the display is Aspect ratio does not match the AR +/- the tolerance a fail will be send and automatically straightens it out to a nice square on which all back. -
Page 20: Camera:calibrate
7.5.4 :CAPTure:XYZImage BLUE After finding the display and calibrating the Atlas 2D imager the real CAPIMG measuring can start. When this command is given the imager takes a image, transforms it to XYZ automatically and stores it in the engine. The XYZ image is stored under the name CAPIMG, which stands for CAPtured IMaGE. -
Page 21: Calculate:mura
Description Second byte of SGL DFF mura Third byte of SGL CSF mura Fourth byte of SGL Admesy mura First byte of SGL … … Second byte of SGL Third byte of SGL The third parameter is the surrounding used. In the DFF this is also called Fourth byte of SGL the NLE divided by 2. -
Page 22: Calculate:uniformtity
7.5.7 :CALCulate:UNIFormtity 7.5.8 :GET:2DData The calculate uniformity command calculates the uniformity of the selected With this command it is possible to get all 2D mura or uniformity data, this XYZ image with the defined method and its set surrounding. Example: enables the user to use its owns algorithms on the 2D Mura or Uniformity image. -
Page 23: Measure:xyz
7.5.9 :MEASure:XYZ In this example we have set the virtual resolution to 5 and 4 giving 20 This command returns the XYZ result of the spectrometer and the clip and display pixels. The first read command will then send us the size of the noise. -
Page 24: Measure:yuv
7.5.11 :MEASure:YUV 7.5.13 :MEASure:FLICker This command returns the Yu’v’ (luminance and chromaticity) result of the This command returns the flicker value. Example: spectrometer and the clip and noise. Example: Write :MEASure:FLICker 4000,0,3,0 ASCII CRLF Read -60.23 ASCII CRLF Write :MEASure:YUV ASCII CRLF Read... -
Page 25: Calibration Commands
7.6 Calibration commands When installing the camera for the first time it is necessary to calibrate the Atlas 2D CCD imager for hot-pixels and for dark. Periodically it can happen due to large temperatures change or due to aging that recalibration needs to be done again. -
Page 26: Measurement Flow
8 Measurement flow capture display with white image The measurement sequence is represented in the flow below. capture red image intitialisation capture green image display configuration capture blue image device configuration calibrate command measurement capture XYZ image of test picture exit calculate mura of test picture The measurement part is red because this part needs to be done for every... -
Page 27: Simple Measurement Example
Set display size in mm :SENSe:AUTOrange 2,1 Set flicker unit to auto-range :SENSe:DR 800,400 Set display resolution in pixels :SENSe:VR 1000,500 Set virtual resolution in pixels :SENSe:AR 1.88 Set aspect ratio of display :SENSe:WD 800 Set working distance atlas to display... - Page 28 Display red image Wat 100ms CAPTure:IMAGE RED Capture red values for calibration Display green image Wat 100ms CAPTure:IMAGE Atlas and engine initialisation GREEN Display blue image Wat 100ms :CAPTure:IMAGE BLUE Atlas and engine initialisation :CAMEra:CALIbrate Calibrate camera for display Display grey image...
