- Page 1 2014 CP810 User Manual USER MANUAL CP810 Nanjing Corewise Smart Technology Inc. Support Hotline: 0086-13851413726, 13851629242 Skype: xiafan_max (software), cruise.xiao (hardware) E-mail: bi.chuanrong@corewise.cn http://www.corewise.cn...
- Page 2 2014 CP810 User Manual Profile Picture Pictorial Illustrations http://www.corewise.cn...
- Page 3 2014 CP810 User Manual http://www.corewise.cn...
- Page 4 2014 CP810 User Manual Operational Guide of Assembling Mobile Phone Into Base: 1) Press DOWN of the button until mobile phone inserted into its right place. 2) This is the right way of inserting mobile phone. 3) Release button and check if mobile phone is locked to the button. If not, repeat step 1) and 2).
- Page 5 2014 CP810 User Manual Operational Guide of Unplugging Mobile Phone Out of Base: 1) Press DOWN of the button until mobile phone is unplugged out of the base machine. 2) Unplugging the mobile phone out of the base machine.
- Page 6 2014 CP810 User Manual Operational Guide of Inserting Printing Paper: 1) Open cover of printer compartment, put paper roll inside. 2) Press F1 (paper rolling) button and check if paper goes smoothly. http://www.corewise.cn...
- Page 7 2014 CP810 User Manual Operational Guide of Testing RFID Function: 1) Ensure mobile phone is communicating fine with base machine, and then enter into DEMO software, select RFID button. 2) Put RFID smart card in the place as shown below.
- Page 8 2014 CP810 User Manual Operational Guide of Testing Fingerprint Function: 1) Ensure mobile phone is communicating fine with base machine, and then enter into DEMO software, select Fingerprint button. 2) Press your finger on the sensor, finger tip should touches the metal frame.
-
Page 9: Technical Specifications
2014 CP810 User Manual Technical Specifications Dimensions 220 x 92 x 49(mm) (8.7" x 3.7" x 1.9") Weight 0.5Kg (1.1lbs) with batteries WCDMA R99: maximum data rate of 384 kbps, 2100Mhz GSM R99: Supports CS SMS, 900/1800Mhz GPRS : CS schemes – CS1, CS2, CS3, and CS4 EDGE : Downlink coding schemes –... -
Page 10: Fingerprint Sensor
2014 CP810 User Manual Functionalities Fingerprint Sensor TCS2SS TCS1ST Picture AuthenTec Inc. (On 27 July AuthenTec Inc. (On 27 July 2012, Vendor 2012, AuthenTec was acquired AuthenTec was acquired by Apple Inc. by Apple Inc. Size 10.4*14.4mm array (imaging 12.8*18.0mm array (imaging... - Page 11 2014 CP810 User Manual Imaging Mode <=20mA @ 5.0V <=20mA @ 5.0V Standard IM 4.4V to 5.5V 4.4V to 5.5V Supply EIM Modes 4.5V to 4.6V 4.5V to 4.6V Supply Operating -30 ºC to +85 ºC -30 ºC to +85 ºC...
- Page 12 Best support will be provided by Corewise to help our buyers to code & program software on basis of our products. We offer free SDK to the purchasers for their purpose;...
- Page 13 2014 CP810 User Manual AsynPrinter printer; printer.setOnPrinterListener(new OnPrinterListener() { @Override public void onPrinterSuccess() { @Override public void onPrinterFail(int code) { (code == Printer.PRINT_NO_PAPER) { else if (code == Printer.PRINT_TIMEOUT) { public void Printf(String Buffer); Print the string * @param bold...
- Page 14 2014 CP810 User Manual Remove Installed Demo Press this icon to enter into main menu On the main menu page, gently press on “CP810_V2.9” Icon and drag to the screen up side to remove the pre-installed Demo Gently press on “CP810_V2.9”...
- Page 15 “Un-install”, drop the icon into it. Install a New Demo Step 1: Copy the new files (for instance “CP810-V2.9) into a "T-Flash/Mini SD Card"; Step 2: Unscrew rear cover of the mobile phone (A160); Step 3: Insert the "T-Flash/Mini SD Card" into the mobile phone and screw the rear cover up;...
- Page 16 2014 CP810 User Manual Step 5: In its file manager, find “external_sd” icon and click it In its file manager, find “external_sd” icon and click it Step 6: In external sd file, you can find “CP810_En.apk”, double click it to run it.
-
Page 17: Packaging And Transportation
2014 CP810 User Manual Upgrade for CP810 Barcode Printing 1. Please check the File and find the file named " CP810_Upgrade",copy those four files inside to 2G T-Flash card root directory(T-Flash Card must be 2G). 2. Insert the "T-Flash Card" to the base, then with battery loaded. - Page 18 2014 CP810 User Manual http://www.corewise.cn...
- Page 19 2014 CP810 User Manual One of the Typical Applications http://www.corewise.cn...
