Snell Advanced Media IQMIX25 User Manual

3g/hd/sd-sdi multi-channel 10/25/40gbe ip transceiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
IQMIX25/26
3G/HD/SD-SDI Multi-channel 10/25GbE IP Transceiver
IQMIX40/41
3G/HD/SD-SDI Multi-channel 10/40GbE IP Transceiver
www.s-a-m.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQMIX25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Snell Advanced Media IQMIX25

  • Page 1 User Manual IQMIX25/26 3G/HD/SD-SDI Multi-channel 10/25GbE IP Transceiver IQMIX40/41 3G/HD/SD-SDI Multi-channel 10/40GbE IP Transceiver www.s-a-m.com...

  • Page 2: Information And Notices

    IQMIX25/26/40/41 Information and Notices Information and Notices Copyright and Disclaimer Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks etc.

  • Page 3: Safety Information

    IQMIX25/26/40/41 Safety Information Safety Information Explanation of Safety Symbols Erklärung der Sicherheitssymbole This symbol refers the user to important information contained in Dieses Symbol weist den Benutzer auf wichtige Informationen the accompanying literature. Refer to manual. hin, die in der begleitenden Dokumentation enthalten sind.
  • Page 4 IQMIX25/26/40/41 Safety Information Simboli di sicurezza: Forklaring på sikkerhedssymboler Questo simbolo indica l'informazione importante contenuta nei Dette symbol gør brugeren opmærksom på vigtig information manuali appartenenti all'apparecchiatura. Consultare il manuale. i den medfølgende manual. Questo simbolo indica che all'interno dell'apparato sono presenti Dette symbol indikerer farlig spænding inden i apparatet.

  • Page 5: Safety Standards

    IQMIX25/26/40/41 Safety Information Símbolos de Segurança O símbolo triangular adverte para a necessidade de consultar o manual antes de utilizar o equipamento ou efectuar qualquer ajuste. Este símbolo indica a presença de voltagens perigosas no interior do equipamento. As peças ou partes existentes no interior do equipamento não necessitam de intervenção, manutenção ou manuseamento por parte...
  • Page 6 IQMIX25/26/40/41 Safety Information EMC Standards This equipment conforms to the following standards: EN 55032:2012 (Class A) Electromagnetic Compatibility of Multimedia Equipment - Emission Requirements. EN 61000-3-2:2014 (Class A) Limits for Harmonic Current Emissions. EN 61000-3-3:2013 Limitation of Voltage Changes, Voltage Fluctuations and Flicker in Public Low-Voltage Supply Systems.

  • Page 7: Table Of Contents

    1.2.1 IQMIX25/26 ........
  • Page 8 IQMIX25/26/40/41 Contents 5.17.3 RollTrack Source ..........49 5.17.4 RollTrack Address .

  • Page 9: Introduction

    SAM's IP expansion cards for the Sirius S800 router, allowing easy integration of video over IP networking with existing SDI base band operations. 1.2 Block Diagrams 1.2.1 IQMIX25/26 Issue 1 Rev 4 Page 9 © 2017 SAM...

  • Page 10: Iqmix40/41

    IQMIX25/26/40/41 Introduction 1.2.2 IQMIX40/41 1.3 Order Codes Modules with "B" order codes (for example, IQFDA3100-1B3) can be fitted only into B-type Note: enclosures. Modules with "A" order codes (for example, IQFDA3100-1A3) can be fitted into either A- or B-type enclosures.

  • Page 11: Rear Panel View

    IQMIX25/26/40/41 Introduction IQMIX4101-3B3 16 channel SDI to IP transceiver using DensiShield connectors with 40GbE interface. Up to 8 SDI inputs and 8 SDI outputs, 2 x 40GbE ports. Includes IQFAN rear panel for additional cooling in IQH3B frame. IQMIX4110-2B3 16 channel SDI to IP transceiver using DensiShield connectors with 10GbE interface.
  • Page 12 IQMIX25/26/40/41 Introduction Figure 3 IQMIX4010-2B3 Figure 4 IQMIX4011-3B3 Figure 5 IQMIX4100-2B3 Issue 1 Rev 4 Page 12 © 2017 SAM...
  • Page 13 IQMIX25/26/40/41 Introduction Figure 6 IQMIX4101-3B3 Figure 7 IQMIX4110-2B3 Figure 8 IQMIX4111-3B3 Issue 1 Rev 4 Page 13 © 2017 SAM...
  • Page 14 IQMIX25/26/40/41 Introduction Figure 9 IQMIX2500-2B3 Figure 10 IQMIX2501-3B3 Figure 11 IQMIX2600-2B3 Issue 1 Rev 4 Page 14 © 2017 SAM...
  • Page 15 IQMIX25/26/40/41 Introduction Figure 12 IQMIX2601-3B3 Issue 1 Rev 4 Page 15 © 2017 SAM...

  • Page 16: Feature Summary

    IQMIX25/26/40/41 Introduction 1.5 Feature Summary 1.5.1 IQMIX25 3G/HD/SD-SDI Multi-channel IP Transceiver • Handles up to 16 SDI signals over dual 10GbE or25GbE IP links (dependent on SDI signal format and compressed/uncompressed transport mode). • Supports configuration of Ethernet links for maximum signal transport using both SFPs, or for dual link mode to provide link redundancy as per SMPTE 2022-7.

  • Page 17: Enclosures

    IQMIX25/26/40/41 Introduction • HD-SDI to SMPTE292M/274M/296M. • SD-SDI to SMPTE259M-C. • 10G Ethernet to IEEE 802.3. • Rollcall control and monitoring compatible, with standard logging and reporting features. 1.6 Enclosures The IQMIX fits the enclosure shown. Ensure that the supplied cooling fan module is also fitted as described in section 1.6.2.

  • Page 18: Iqfan00 Cooling Fan Module

    IQMIX25/26/40/41 Introduction 1.6.2 IQFAN00 Cooling Fan Module IQMIX25/26/40/41 cards are supplied with IQFAN00 cooling modules. Ensure these are fitted according to the instructions below. Front View Rear View IQFAN00 Cooling Module Do not run IQMIX cards without the fan modules. This can cause severe damage to the equipment.

  • Page 19: Technical Specification

    IQMIX25/26/40/41 Technical Specification Technical Specification Inputs/Outputs Signal Inputs Inputs Up to 16 (0/4/8/12/16) Connector/Format BNC/75R Conforms to 3G-SDI to SMPTE 424M/425M level A compatible HD-SDI to SMPTE292M/274M/296M SD-SDI to SMPTE259M-C Input cable length Belden 1694A @ 3 Gbit/s - TBC Belden 1694A @ 1.5 Gbit/s - TBC...
  • Page 20 Specifications Electrical Transport Stream Connector/Format HD-BNC Standard SAM screw terminal Start-up Time Power Consumption Module Power IQMIX25/26 34.5 PR Max (B frame only) Consumption IQMIX40/41 37.5 PR Max (B frame only) Issue 1 Rev 4 Page 20 © 2017 SAM...

  • Page 21: Connections

    IQMIX25/26/40/41 Connections Connections This section describes the physical input and output connections provided by the IQMIX modules. 3.1 SDI BNC Input/Outputs 16 x 3G/HD/SD-SDI interfaces provided with HD-BNC. 3.2 10/25G Ethernet SFP SFP+ supporting 10/25G Ethernet. 3.3 40G Ethernet QSFP QSFP+ supporting 40G Ethernet.

  • Page 22: Card Edge Leds

    IQMIX25/26/40/41 Card Edge LEDs Card Edge LEDs The LEDs on the edge of the module indicate its operating status. Front Panel Description STATUS  STATUS PB=IDENT Green = PTP-LOCK OK Off = PTP-LOCK Fail BOARD   BOARD Green flashing= PTP-SYNC OK Off = PTP-SYNC Fail ...

  • Page 23: Rollcall Control Panel

    IQMIX25/26/40/41 RollCall Control Panel RollCall Control Panel This section contains information on using the IQMIX modules with RollCall. For help with general use of the RollCall application, open the user manual by clicking the button on the main RollCall toolbar.

  • Page 24: Setting Values

    IQMIX25/26/40/41 RollCall Control Panel • Logging Misc - see section 5.13. • Logging SFP - see section 5.14. • Logging FPGA- see section 5.15. • Logging Spigot 1-x - see section 5.16. • Rolltrack - see section 5.17. • Loopback Router - see section 5.18 •...

  • Page 25: Configuration

    IQMIX25/26/40/41 RollCall Control Panel 5.4 Configuration The Configuration page allows basic module parameters to be set. Figure 15 Configuration Page The following facilities are available from this page: Option Operation SDI IO Displays how input and output spigots are currently configured.
  • Page 26 IQMIX25/26/40/41 RollCall Control Panel Option Operation Domain RollCall+ uses domains to partition a network; only nodes on the same domain can communicate with one another. A domain is uniquely identified with a number and a friendly name/alias. Set an ID as required, then press Take to confirm the change.

  • Page 27: Time Sync Configuration

    IQMIX25/26/40/41 RollCall Control Panel 5.5 Time Sync Configuration The Time Sync Configuration page allows selection of the source to be used for synchronizing flows, and configuration of any properties associated with the relevant source. Figure 16 Time Sync Configuration Page...

  • Page 28: Status

    IQMIX25/26/40/41 RollCall Control Panel 5.5.1 Status Displays important system status information on a single convenient panel. Figure 17 Time Sync Status 5.5.2 Histogram Located to the right of the Status panel, the Histogram provides a graphical representation of the distribution of differences between the card's clock and the PTP grandmaster clock. Every time the clock difference is recalculated, the relevant bar is incremented.

  • Page 29: Link Control

    IQMIX25/26/40/41 RollCall Control Panel 5.6 Link Control The Link Control page allows quad-link 4K inputs to be synchronized by the IQMIX module. Figure 19 Link Control Page To have the IQMIX synchronize quad-link inputs, enable the check box next to the set of inputs to synchronize.

  • Page 30: Tpg (Test Pattern Generator)

    IQMIX25/26/40/41 RollCall Control Panel 5.7 TPG (Test Pattern Generator) The TPG page allows test patterns to be applied on a spigot-by-spigot basis. Figure 20 TPG Page The following options are available for each spigot: Option Operation Select the test pattern to apply to the spigot from the drop-down list.

  • Page 31: Fec

    RollCall Control Panel 5.8 FEC The FEC page allows FEC Clause 74 to be selected and FEC logging to be activated, if required. FEC stats are also available. This page is available for IQMIX25 modules only. Note: Figure 21 FEC Page...
  • Page 32 IQMIX25/26/40/41 RollCall Control Panel Log Field Description FEC_N_CORRECTED_ Number of corrected errors for FEC N. ERRORS= FEC_N_UNCORRECTED_ Number of uncorrected errors for FEC N. ERRORS= Where N is the SFP number Issue 1 Rev 4 Page 32 © 2017 SAM...

  • Page 33: Ethernet Pages 1 And 2

    IQMIX25/26/40/41 RollCall Control Panel 5.9 Ethernet Pages 1 and 2 Ethernet pages 1 & 2 refer to the rear-panel Ethernet connectors only. See section 5.20 for Note: information on managing the on-module Ethernet connector. The Ethernet pages show details and status for each network interface. The IQMIX defaults to use of DHCP, but this can be overridden and a static IP address defined if required.

  • Page 34: Ethernet 1 And 2 Rtp Sender

    IQMIX25/26/40/41 RollCall Control Panel 5.10 Ethernet 1 and 2 RTP Sender The RTP Sender page displays the amount of data transmitted, on a spigot-by-spigot basis. Units are megabits per second. Click Enable Stats to display values. Figure 23 Ethernet 1 & 2 RTP Sender Page...

  • Page 35: Ethernet 1 And 2 Rtp Receiver

    IQMIX25/26/40/41 RollCall Control Panel 5.11 Ethernet 1 and 2 RTP Receiver The RTP Receiver page displays the amount of data received, plus details of packet loss, on a spigot-by-spigot basis. Units are megabits per second. Click Enable Stats to display the values.

  • Page 36: Spigot

    IQMIX25/26/40/41 RollCall Control Panel 5.12 Spigot Pages A separate page is provided for each of the active spigots. These pages are dynamically configured by the product, based on the capabilities of the software version/firmware selected. The pages shown here may differ from those seen on your particular system, depending on Note: the model and configuration of your IQMIX module.
  • Page 37 IQMIX25/26/40/41 RollCall Control Panel Audio Channels Allows the number of audio channels in use to be restricted. Select from the list the highest connector number to be used. Streaming Select the Ethernet connectors to use for this spigot. This will also determine the bandwidth to be used.

  • Page 38: Output Spigots

    IQMIX25/26/40/41 RollCall Control Panel 5.12.2 Output Spigots Output spigots are defined by selecting the appropriate firmware version on the Configuration page. See section 5.4 for more information. Figure 28 Typical Output Spigot Page 5.12.2.1 Spigot Pane The Spigot pane provides basic monitoring for the selected Spigot. Click Take to apply any changes made.
  • Page 39 IQMIX25/26/40/41 RollCall Control Panel Streaming Select the Ethernet connectors to use for this spigot. This will also determine the bandwidth to be used. Options are: • Dual - use both Ethernet connectors, and so all available bandwidth. • Single - use either Ethernet connector, and so half of the available bandwidth.

  • Page 40: Logging - Misc

    IQMIX25/26/40/41 RollCall Control Panel 5.13 Logging - Misc Information on several parameters can be made available to a logging device connected to the RollCall network. Each logging page comprises three columns: • Log Enable - Select the check boxes that correspond to the parameters for which log information should be collected.
  • Page 41 IQMIX25/26/40/41 RollCall Control Panel The following options are available. Enable check boxes to activate log fields as required. Log Field Description Reports the module serial number, which consists of an S followed by eight digits. Note: this cannot be deselected.
  • Page 42 IQMIX25/26/40/41 RollCall Control Panel Log Field Description TIMESYNC_N_NETWORK= Network port currently being used for synchronization for IQMIX modules, dependant on the choice of interfaces made on the Time Configuration page. If PTP and multiple interfaces are enabled, the PTP synchronization will switch ports if it doesn't see regular sync messages on the port.
  • Page 43 IQMIX25/26/40/41 RollCall Control Panel Log Field Description LAN_PORT_N_SPEED= Ethernet connection speed. Valid values are: • 10 Mbit/s Full Duplex • 10 Mbit/s Half Duplex • 100 Mbit/s Full Duplex • 100 Mbit/s Half Duplex • 1 Gbit/s Full Duplex •...

  • Page 44: Logging - Sfp

    IQMIX25/26/40/41 RollCall Control Panel 5.14 Logging - SFP Information on several parameters can be made available to a logging device connected to the RollCall network. Each logging page comprises three columns: • Log Enable - Select the check boxes that correspond to the parameters for which log information should be collected.
  • Page 45 IQMIX25/26/40/41 RollCall Control Panel Log Field Description SFP_N_CONNECTOR= Displays connector type. TEMP_N_NAME= Displays temperature sensor name. TEMP_N_CELSIUS= Displays current temperature sensor reading. TEMP_N_STATE= Displays temperature sensor state. Valid values are: • WARN: Disabled - Temperature sensor disabled. • WARN: Low - Low, but in tolerance.

  • Page 46: Logging - Fpga

    IQMIX25/26/40/41 RollCall Control Panel 5.15 Logging - FPGA Information on several parameters can be made available to a logging device connected to the RollCall network. Each logging page comprises three columns: • Log Enable - Select the check boxes that correspond to the parameters for which log information should be collected.

  • Page 47: Logging - Spigot

    IQMIX25/26/40/41 RollCall Control Panel 5.16 Logging - Spigot The Logging - Spigot pages are used to select the fields to be enabled for each available spigot. Depending on whether the spigot is an input or an output, the appropriate log fields are shown.
  • Page 48 IQMIX25/26/40/41 RollCall Control Panel The following options are available. Enable check boxes to activate log fields as required. Log Field Description INPUT_N_IDENT= System-defined identifier for the input, based on the rear INPUT_N_NAME= Name of the input, as defined by the user on the Setup page.

  • Page 49: Rolltrack

    IQMIX25/26/40/41 RollCall Control Panel 5.17 RollTrack The RollTrack page allows information to be sent, via the RollCall network, to other compatible units connected on the same network. The Source window lists the RollTrack sources: Figure 36 Source Pane 5.17.1 Disable All When checked, all RollTrack items are disabled.

  • Page 50: Rolltrack Address

    IQMIX25/26/40/41 RollCall Control Panel 5.17.4 RollTrack Address This item enables the address of the selected destination unit to be set. The address may be changed by typing the new destination into the text field, then clicking S to save the selection. Clicking P returns to the default preset destination.

  • Page 51: Loopback Router

    IQMIX25/26/40/41 RollCall Control Panel 5.18 Loopback Router The Loopback Router page provides a basic SDI router as a redundant backup in case of Ethernet failure. Figure 37 Loopback Router Page If an Ethernet failure is encountered: Use the matrix radio buttons to specify which inputs should be routed to which outputs.

  • Page 52: Setup

    IQMIX25/26/40/41 RollCall Control Panel 5.19 Setup The Setup page displays basic information about the module, such as the serial number and software version. Use the functions on the page to restart the module or to return all settings to their factory or default settings.

  • Page 53: Defaults

    IQMIX25/26/40/41 RollCall Control Panel 5.19.2 Defaults Provides options to reset the module to its defaults. Option Operation Default settings All controls are reset to their default values, except for network configuration and IP addresses. Factory defaults All controls are reset to their default values, including network configuration and IP addresses.

  • Page 54: Interop Page

    IQMIX25/26/40/41 RollCall Control Panel 5.22 Interop Page Not currently used. Figure 41 Interop Page Issue 1 Rev 4 Page 54 © 2017 SAM...

  • Page 55: Sfp Configuration Page

    IQMIX25/26/40/41 RollCall Control Panel 5.23 SFP Configuration Page The SFP Configuration page allows various SFP parameters to be adjusted, if required. This page is available for IQMIX25 and IQMIX40 modules only. Note: Figure 42 SFP Configuration Page The majority of SFPs will operate correctly with IQMIX modules without any need for adjustment.
