SMATE Theatre Series Soundbar USER MANUAL MODEL NO.:SM2SB5.1TH150KINMA Note:Please read the instructions carefully before operating the set and retain it for further reference. -
Page 3: Table Of Contents
Content Safety Precautions ------------------------------------------------------------ 01 Important Safeguards -------------------------------------------------------- 02 Speci cation -------------------------------------------------------------------- 03 Power Switch ------------------------------------------------------------------- 04 Front Control Panel ------------------------------------------------------------ 04 Remote control ----------------------------------------------------------------- 05 Ampli ed board ---------------------------------------------------------------- 06 USB Operation ------------------------------------------------------------------ 06 Bluetooth Operation ---------------------------------------------------------- 07 Aux Operation ------------------------------------------------------------------ 08 Subwoofer Output Operation ---------------------------------------------- 09 5.1CH/AC-3 Operation ------------------------------------------------------- 10 Wired Mic Operation ---------------------------------------------------------- 11... -
Page 4: Safety Precautions
Safety Precautions A. Please do not open the back cover or the soundbar cover. The lighting flash symbol is to alert the user to the presence of uninsulated "dangerous voltage" within product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock. Please refer to qualified service personnel with any issues. -
Page 5: Important Safeguards
Important Safeguards 01. Read Instructions-All the safety and operating instructions should be read before the appliance is operated. 02. Read Instructions-All the safety and operating instructions should be retained for future reference. 03. Follow Instructions-All operating instructions should be followed. 04. -
Page 6: Speci Cation
Product size:1098x236x165mm The soundbar is designed with patented technology: With patented loudspeaker phase control technology, SMATE sound bar subwoofer is designed to operate at low-frequency which produces punchy bass. The centre and front loudspeaker are designed to operate on full-frequency range which produces the centre and front channel sounds. -
Page 7: Power Switch
Power Switch The soundbar power switch is located under the LED display panel as shown in the picture above. OFFON When turned on the display will light up automatically. Front Control Panel 1. LED display 7. Previous channel/ previous song 2. -
Page 8: Remote Control
Remote control 1. STANDBY 11. INPUT(change input signal sources) 2. CH.MODE(2.1ch/5.1ch mode) 12. NEXT CHANNEL+ 3. MASTER VOLUME+ 13. PLAY/PAUSE 4. PREVIOUS CHANNEL- 14. SURROUND VOLUME+ 5. MASTER VOLUME- 15. CENTER VOLUME+ 6. SURROUND VOLUME- 16. SUBWOOFER VOLUME+ 7. CENTER VOLUME- 17. -
Page 9: Ampli Ed Board
Amplified board 01. HDMI Output 07. Power Input 02. HDMI 2 Input 08. MIC 1 Input 03. HDMI 1 Input 09. MIC 2 Input 04. Active Subwoofer Ouput 10. OPTICAL Input 05. AUX Input 11. COAXIAL Input 06. AC-3/5.1CH Input USB Operation 1. -
Page 10: Bluetooth Operation
Bluetooth Operation Mobile Phone iPad 1. Select the input to "Bluetooth" mode 2. Enable bluetooth mode on your device and search for bluetooth device "KINMA9" and select for connection 3. No password is required for connection 4. A beep sound from the soundbar will confirm the device is connected successfully 5. -
Page 11: Aux Operation
Aux Operation 3.5mm/2 rca cable audio cable 2 RCA to 2 RCA cable audio cable 1. Connect your device with the soundbar via RCA cable as per any of the two methods shown above in the picture 2. Change "input" to "AUX" 3. -
Page 12: Subwoofer Output Operation
Subwoofer Output Operation 1. Connect active subwoofer input to the soundbar SW OUT port via RCA cable as per the connection diagram shown above... -
Page 13: 5.1Ch/Ac-3 Operation
5.1CH/AC-3 Operation 1. Connect your device with the soundbar by RCA cable as per the picture shown above 2. Change "input" to "5.1" 3. Adjust the volume for each channel separately... -
Page 14: Wired Mic Operation
Wired Mic Operation MIC input jack 6.5mm Wired Microphone Wireless Microphone receiver... -
Page 15: Optical Operation
Optical Operation Player device Optical audio signal cable 1. Connect your device with Optical cable to the ports marked OPTICAL as per above picture 2. Change "input" to "OPT" 3. Adjust the volume for each channel separately... -
Page 16: Coaxial Operation
Coaxial Operation Player device Coaxial audio signal cable 1. Connect your device with Coaxial cable to the ports marked COAXIAL as per above picture 2. Change "input" to "COAX" 3. Adjust the volume for each channel separately... -
Page 17: Hdmi Operation
HDMI Operation HD Player HDMI OUTPUT HDMI INPUT 1. Connect your device with HDMI cable as per above picture to external device or TV 2. Change "input" to "ARC” 3. Adjust the volume for each channel separately Please note: 1) Connect a suitable ARC enabled HDMI cable to ARC enable HDMI port on your TV. Please turn on/enable the ARC function on your TV 2) When connecting other HDMI devices to the soundbar input, please select relevant source HDMI from TV (which is connected to the soundbar) and change soundbar input to relevant... -
Page 18: Installation Steps
4. Mount the soundbar to the installed brackets on the wall Note: Please ensure its a two person lift to prevent any injury or harm to yourself or damage to the soundbar Please contact us at support@smate.com.au for professional installation of your soundbar ensuring best audio experience... -
Page 19: Accessories
Accessories 1. Manual x1 2. RCA cables x2 3. Optical cable x1 4. HDMI cable x1 5. Remote Control x1 6. Power Cord x1 7. Screws x1 set Trouble Shooting PROBLEM MODIFIED METHODS Check whether the power cord is loose or not NO POWER Check whether the socket is working or not No Sound... -
Page 20: Installing Batteries To The Remote Control
Installing Batteries to the Remote Control Please insert AAA batteries into the remote control. Make sure the (+) side and the (-) side are installed correctly. When you are installing the battery, the remote's backside should be facing up. After installing the batteries correctly, please re-attach the battery cover. Please note: * Only use AAA batteries. -
Page 21: Support
1.6 The product will be at the owner's risk whilst in transit to and from the Smate Authorised Service Centre, unless transported by Smate or its Authorised representatives. - Page 22 2.9 To the normal incidence of off-coloured or dark pixels in LCD and LED screens as described in the User Manual for the product. Smate will only repair or replace the product if there are (a) 8 or more dark pixels in the screen (unless 2 or more are adjoining dark pixels) or (b) 2 or more bright pixels in the screen.
-
Page 23: Dear Customer
WARRANTY CARD Dear customer Thank you for purchasing product, Your product is under warranty in accordance with terms and conditions stated herein. 1. Your units and components contained therein are warranted against defective material and workmanship for a period of 12 months from the date of purchase. 2. - Page 24 LIMITATIONS OF WARRANTY ● Damage resulting from accidents,misuse,abuse,alteration,tempering or failure of the purchase to follow the normal operating procedure outlined in user manual. ● Defect of damage due to spillage of liquids,due to insect or wrong use of electrical supply and voltage.
