Summary of Contents for AAMP of America 044131
- Page 1 (Australia) or (09) 257 2419 New Zealand 2.5kg/3.0kg 3.0kg Part Number: 044131 2.5kg Part Number: 041133 © 2016 V2.1...
- Page 2 (09) 257 2419 Camec NZ 44 Montgomerie Road, Mangere, Auckland, 2022 Wash Times & Water Usage Error Codes & Functions...
-
Page 3: Error Code
ERROR CODES & FUNCTIONS ERROR CODES & SUGGESTED SOUTIONS ERROR CODE FAULT SYMPTOM SUGGESTED SOLUTION - Check that the water tap is on - Check mains pressure or water pump operation LCD displays flashing - Check the water inlet filter No water fill alert "E1"... - Page 4 Rated wash & spin load Rated Power Input 2.5kg - 041133 410 x 420 x 640mm 16kg 2.5kg (dry clothes) 235W max 3.0kg - 044131 410 x 420 x 740mm 18kg 3.0kg (dry clothes) 1035W max 2.5 & 3kg models 240V~...
-
Page 5: Installation Notes
Installation Notes water supply and drainage, with low moisture and no direct sunlight, and is not subject to freezing Base cover (position) Packaging... -
Page 6: Installation
INSTALLATION Preparation and Operation Installation Notes (cont’d) 1. Check that the drain hose is correctly installed (and has not fallen out of its inlet) 2. Connect the water inlet hose and turn on the tap. 3. Insert the power plug in the socket and turn on. 4. - Page 7 WASH TIMES & WATER Wash Cycle Chart 2.5kg Model 3.0kg Model HOT WASH 62(heating)+8(wash) Suggested Water Settings and Usage 2.5kg Model Weight of load. Suggested Water Level Water Usage 1.0~2.5kg High Approx 20L <1.0kg Approx 15L 3kg Model Weight of load Suggested Water Level Water Usage 2.0~3.0kg...
- Page 8 3kg Model 2.5kg Model Hot Wash Power Power Indicates Hot Wash Heating LED will flash. Start/Pause Start/Pause Water level Water level HOT WASH...
