TX-600N Specifications-----------------------------------1

Instrument descriptions ----------------------------------2

Display descriptions --------------------------------------3

Key descriptions ------------------------------------------4

Instructions -----------------------------------------------6

RS-232 transfer protocol --------------------------------11

Precautions----------------------------------------------14

※ Please make sure to read the operation manual before using.

※ Please use the device correctly on the basis of complete

understanding.

CONTENTS

Need help?

Do you have a question about the TX-600N and is the answer not in the manual?

Questions and answers

Summary of Contents for Rixen TX-600N

Page 1: Table Of Contents
CONTENTS TX-600N Specifications-----------------------------------1 Instrument descriptions ----------------------------------2 Display descriptions --------------------------------------3 Key descriptions ------------------------------------------4 Instructions -----------------------------------------------6 RS-232 transfer protocol --------------------------------11 Precautions----------------------------------------------14 ※ Please make sure to read the operation manual before using. ※ Please use the device correctly on the basis of complete...
Page 2: Tx-600N Specifications
■TX-600N Specifications Input Types K, J, E, T, B, R, N, S, C thermocouple types; With Dual-channel input Measurement Range K: -200.0 ~ +1370.0℃(-328.0~+2498.0℉) J:-200.0 ~ +1200.0℃(-328.0~+2192.0℉) E:-210.0 ~ +1000.0℃(-346.0~+1832.0℉) T:-220.0 ~ +400.0℃(-364.0~+752.0℉) B:+320.0 ~ +1800.0℃(+608.0~+3272.0℉) R:-20.0 ~ +1700.0℃(-4.0~+3092.0℉) N:-200.0 ~ +1300.0℃(-328.0~+2372.0℉) S:-20.0 ~ +1750.0℃(-4.0~+3182.0℉)
Page 3: Instrument Descriptions
Instrument descriptions 部名稱 ○ ○ 1 Multi-Function LCD display Battery cover ○ ○ 2 Function key and setting key AC Adaptor input ○ ○ 3 Record key and thermocouple switch key 1 0 USB Output port ○ ○ 4 Movement key 1 1 RS-232 Output connector ○...
Page 4: Display Descriptions
Display descriptions Display Descriptions Battery power symbol Manual shut down Buzzer on Under calibrating HOLD Data hold Data-logging Maximum value Minimum value Average value T1 probe T2 probe Hi.A High point alarm Lo.A Low point alarm English words zone thermocouple types A.B.C.
Page 5: Key Descriptions
Key descriptions Function Descriptions LCD display Press one second (Be-) can turn on the power. Press one second (Be---) can turn off the power. On/Off If the instrument is left without any operation for five minutes, it will turn off automatically. When the device is on off state, hold ,then press to turn on.
Page 6 Under testing mode, and there is no recording data, Recode press to enter RCD record mode. mode will flashes when record. Press to stop recording. Under testing mode, press to into the data reading hold mode. Use to switch the displayed record value;...
Page 7: Instructions
■Instructions A. Testing Mode: Press to switch display conditions. T1 Real-time temperature display T2 Real-time temperature display T1 and T2 Real-time temperature display Time and Date display In the testing mode, the display content as below: Status Display contents Probe condition, Probe type, warning data condition, Normal conditions Power indication Area A: T1 Measuring data value...
Page 8 B.RCD Record mode: ※Please use the AC Adaptor when you need to record for a long time Under testing mode, press into the record mode, It will show the sampling rate before starting record. Under the record mode press can switch the display, the will flashed when recording.
Page 9 D.Hold Mode: Under testing mode, press to enter the reading hold mode, Use to switch the T1 and T2 values, press again to return to the testing mode. If there are data log in internal, the record will show the maximum, minimum, average.
Page 10 F. RCD Clear Mode: Under the RCD reading mode or the hold mode, press and hold to enter the RCD clear mode. Then will be displayed. Press select and use to confirm. The twinkled means not to clear the data, and the twinkled means to clear the data.
Page 11 Setting mode instructions 1. Alarm setting mode This mode is for setting the Hi.A and Lo.A, press to change the digit you want to change, and press to select the circulation figures from 0 to 9. It’s thousands of bits can be switched to the negative sign. Press confirm the setting.
Page 12: Rs-232 Transfer Protocol
■ RS-232 Transmission Agreements ※Please connect the AC Adaptor if it required a long time to transfer the data. RS-232 is for one-way data transfer, receive and input the signal by three grounded wires. Recommending using the transmission line which is manufacture by OE factory or shorter than 10 meters of cable to connect the computer and the instrument.
Page 13 C. Request Data Frame Ex: Read the data from address 02h (Read 5-byte of data from address 0002H) Slave Function Starting Starting No. of No. of address address address Word Word Response Data Frame Ex. response data =10-byte Slave Function Byte Data(1) Data(1)
Page 14 【Example】Set mode: K Type thermocouple Temperature unit=℃ T1 no ERROR T2 no ERROR Power74~50% MOD setting mode 0= K Type thermocouple, 1= J Type thermocouple, 2= E Type thermocouple, 3= T Type thermocouple, 4= B Type thermocouple, 5=R Type thermocouple, 6=N Type thermocouple, 7= S Type thermocouple, 8= C Type thermocouple.
Page 15: Precautions
D. Cable illustrated ■ Precautions 1. This instrument has a waterproof function; please do not use it in a high temperature environment or with corrosive materials to avoid leakage or damage. 2. Proposed to use the company's original signal cable (sold separately) to avoid the instrument inability to communicate to computer.
Page 16 MEMO ------------------------------------------------------------------ ------------------------------------------------------------------- ------------------------------------------------------------------- ------------------------------------------------------------------- ------------------------------------------------------------------- ------------------------------------------------------------------- ------------------------------------------------------------------- ------------------------------------------------------------------- ------------------------------------------------------------------- ------------------------------------------------------------------- ------------------------------------------------------------------- -------------------------------------------------------------------...
