Summary of Contents for Mintforbers Bar 9
- Page 1 COB LED Bar Light User Manual Bar 9 Please keep this manual for further use...
-
Page 2: Product Introduction
Bar 9 COB LED Wash Light Product Introduction Thank you using our LED series products. This fixture is the latest new LED product. It has aluminum die-cast housing with nice design, international advanced electronic control technology and excellent industrial design. Product effect more rich, colorful, and color is gorgeous because of installed high output light source. -
Page 3: Safety Instructions
Bar 9 COB LED Wash Light 1.Safety Instructions Please open and check whether break or not for transport once receipt this fixture, if yes, not use it and contact dealer or manufacture as soon as possible. The Max Ambient temperature for the light is 40°C. Do not use the light when the ambient ℃... - Page 4 Bar 9 COB LED Wash Light 4. LED display instruction A．Function button （MENU） B．UP button（UP） C．DOWN button（DOWN） D. Enter button（ENTER） E．LED display 5. LED display instruction chart UP/DOWN Default data Function MENU 001-512 A001 Address setting A001 9CH/14CH/36CH 14CH 14CH Mode 1...
- Page 5 Bar 9 COB LED Wash Light 6. DMX512 chart 9CH Mode 1 ）））））） Dimming 1 0----255 Linear dimming from dim to bright Strobe The whole bright 1----255 Strobe Built-in 0----25 No function program 3 26---35 No function 36---45 Colorful hopping...
- Page 6 Bar 9 COB LED Wash Light 0----255 R, G ,B . W dimming 2 CH 8 0----255 R, G ,B . W dimming 3 0----255 R, G ,B . W dimming 4 ..............CH14 0---255 R, G ,B . W...
-
Page 7: Dmx Address Setting
Bar 9 COB LED Wash Light 7. DMX-512 controller connection 3pins XLR signal output connector 3pins XLR signal input connector (female) (male) 1: earth 2 : signal - 3 : signal + 8. DMX address setting Set an address for each light, and accept the DMX signal from DMX controller, as per the demand, user can set the same address for all lights, or different address for different light. - Page 8 Bar 9 COB LED Wash Light 9. Rigging and installation 1. Hook clamp 2. Handle ℃, 1. The light can work properly when the ambient temperature is -25~40 ℃ or ℃. the ambient temperature is over 40 under -25 2. The installation has to be built and constructed in a proper way that the rigging can hold 10 times of the light weight .
-
Page 9: Cleaning And Maintenance
Bar 9 COB LED Wash Light 10.Cleaning and maintenance Maintenance should be performed every 15-day period, by using a sponge which is dipped with alcohol, rather than wet cloth or other chemical liquid, to clean the mirror. Always disconnect from the mains when the device is not in use or before cleaning it. - Page 10 Bar 9 COB LED Wash Light - - 9 - -...
