MOTA MT-S6-01 User Manual

Battery Case for Galaxy S6
3500mAh
Product specifications:
ITEMS SPECIFICATION REMARK
Input DC 5.0V =1.5A(Max) Charge
Output DC 5.0±0.25V =1.6A(Max)
Nominal Capacity 3500mAh
Cell Type Li-polymer
Adaptable for Galaxy S6
Color Black & White
Dimensions 16.4 X 74.9X 155.2mm
Weight 90g
Features:
Galaxy S6
Full Accessibility
to Buttons & Camera
Changeable
Frame
Micro USB
Micro USB
Charging Port
Hole for voice out
LED
Place to pull the frame up Indicator
Power Button
Installation:
①
②
③ ④
Installing:
To install: Slide you Galaxy S6 into the back cover of our battery case,
then install the top frane from the bottom to the top.
To uninstall: Gently pull the bottom frame up using your fingermail.
Notes:
When your Galaxy S6 battery is completely drained, the charging icon will revert
to itself normal state.
The battery case includes a USB cable to be used when charging your case.
Charging your Battery Case and Galaxy S6:
Connect your battery case ( Galaxy S6 already installed) to the USB
power cable.
Connect the USB power cable to any USB power source (such as computer)
to start charging.
Charge until the LED indicators read full.
Charging your Galaxy S6 with Battery Case:
-Press the power button (approximately 3s) to start charging.
-Press the power button again (approximately 3s) to turn off the battery
case when Galaxy S6 is fully charged. which can signiflcantly save the capacity
of built-in battery so as to charge the S6 next time.
LED indicators:
75-100% 50-75% 25-50% 1-25%
Package Contents:
Power Pack
USB power cable
User Manual
Warning:
Galaxy
2015
