Summary of Contents for Assistive Technology ATSFD1
- Page 1 ATSFD1 User Manual Touch N’ Talk FD1 2-Way Waterproof Voice Pendant Medical Alert System with Fall Detection...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Overview Page 3 Contents of the System Page 3 REQUIRED SETTING Installing the Backup batteries Page 4 Connecting the Base Unit Page 4 Switching the pendant ON/OFF Page 5 Pendant Charging Page 5 ... -
Page 3: Overview
Overview Contents of the System Pendant Base Unit AC Adapter Lanyard Phone Cord... -
Page 4: Required Setting
REQUIRED SETTINGS Installing the backup Batteries Reminder: You must use ONLY rechargeable batteries; never use regular non- rechargeable batteries in this system. Non-rechargeable batteries will permanently damage this unit. (Recommended 1.2v AAA 800MH or greater Ni- ZN or Ni-MH rechargeable batteries only.) Connecting the Base Unit Place the base station on a stable surface location near the telephone line jack... -
Page 5: Switching The Pendant On/Off
Switching the device ON/OFF 1. Press and hold key for 6 seconds on the front of the pendant to switch on. You can hear the system speak the phrase ‘Power On’ or ‘Power Off’. 2. If you put the pendant on the base for 6 seconds it will switch on automatically. You will hear ‘Power On”... -
Page 6: System Check
System Check Press the key at the same time for 1 second on the pendant to start the system check. You will hear “system check, please wait”. System check includes: 1. Pendant and Base connection 2. Out of range 3. Line availability If all items are OK, you will hear a voice prompt, ‘System Check OK’. -
Page 7: Setting/Storing Sos Numbers
Setting/Storing SOS Numbers Press Menu Press 1 time to select ‘SOS NUMBERS’ Press The screen will display ‘Pendant 1’ Choose Pendant # by pressing (If you have a second pendant) When you have chosen a pendant # press the screen will display ‘PLEASE WAIT’... -
Page 8: Manually Making An Sos Call
Manually Making an SOS Call OPTION # 1 Press and hold the key on the pendant for 3 seconds to activate the alert, the speaker phone will activate automatically and you will hear 'SOS is calling' Press key to cancel. OPTION # 2 Press key on base for 3 seconds to activate the alert... -
Page 9: Additional Settings
ADDITIONAL SETTINGS Navigating in the Menu PRESS When on the main Screen to get to System Menu Press To Scroll Through The Menu Press To take you back one Step, A 3 second press on this key will return you back to the main screen... -
Page 10: Setting Date/Time
Setting Date/Time Set Date Press the screen will display ‘DATE + TIME’ Press the screen will display ‘SET DATE’ Press Enter Date Year, Month then day Press to save Press for 3 seconds to return you back to the main screen Set Time Press the screen will display ‘DATE + TIME’... -
Page 11: Date/Time Format
Date Format Press the screen will display ‘DATE + TIME’ Press Press 2 times to get to the ‘DATE FORMAT’ option Press The screen will display ‘DD – MM (day-month)’ or Press Once for ‘MM-DD (month- day)’ Press To save Press key for 3 seconds To return to main screen... -
Page 12: Setting/Storing Sos Numbers
Setting/Storing SOS Numbers Storing SOS Numbers Press Menu Press 1 time to select ‘SOS NUMBERS’ Press The screen will display ‘Pendant 1’ Choose Pendant # by pressing (If you have a second pendant) When you have chosen a pendant # press the screen will display ‘PLEASE WAIT’... -
Page 13: Viewing Stored Sos Numbers
Viewing Stored SOS Numbers Press Press 1 time to ‘SOS NUMBERS’ Press The screen will display ‘Pendant 1’ Choose Pendant # by pressing (If you have a second pendant) When you have chosen a pendant # press the screen will display ‘PLEASE WAIT’... -
Page 14: Editing Sos Numbers
Editing SOS Numbers Press Menu Press 1 time to select ‘SOS NUMBERS’ Press The screen will display ‘Pendant 1’ Choose Pendant # by pressing (If you have a second pendant) When you have chosen a pendant # press the screen will display ‘PLEASE WAIT’ Press to select ‘EDIT’... -
Page 15: Erasing All Sos Numbers
Erasing All SOS Numbers Press Press 1 Time to ‘SOS NUMBERS’ Press The Screen will display ‘PLEASE WAIT’ Choose Pendant # (If you have a second pendant) When you have chosen a pendant number press (The screen will display ‘PLEASE WAIT’) The screen will display ‘LIST’... -
Page 16: Setting Sos Mode
Setting SOS Mode When the ‘REACH ONE’ option is selected, the SOS call will stop when any one of the 3 stored SOS numbers is successfully connected. This is the default setting. When the ‘REACH ALL’ option is selected, the SOS call will stop when ALL 3 of the saved SOS numbers are successfully connected. -
Page 17: Detect Ack Emergency Message
Detect ACK Emergency Message When an SOS call is made and the call is picked up, the receiving party will hear: “This is an SOS call, to continue the call, press hash key now (#)” the receiving party then must press the “#”... -
Page 18: Continuous Sos Call
Continuous SOS Call ON: During an ‘SOS MODE’ call, the calling cycle will continue until a call is successfully connected, regardless of the units ‘REACH ONE or REACH ALL’ settings. ** Helpful Hint: If ‘CONTINUE SOS CALL’ is set to ‘ON’ the system will dial the contact numbers over and over forever. -
Page 19: Answer Call
Answer Call: ON: When this option is selected, a ring tone will sound thru the pendant for an incoming call. The user can then press the ‘SOS HELP’ key to pick up any incoming call. OFF: When this option is selected, the pendant will NOT have an incoming ring tone. Press Press to 5 times ‘ANSWER CALL’... -
Page 20: Pill Alarm
Pill Alarm Setting Pill Alarms Press The screen will display ‘DATE and TIME’ Press 6 times to ‘PILL ALARM’ Press The screen will display ‘PLEASE WAIT’ Choose Pendant # by pressing (If you have a second pendant) When you have chosen a pendant press The screen will display ‘PLEASE WAIT’... -
Page 21: Cancel Pill Alarms
This is an alarm reminder for taking medication. For example, if you set “Start at 9am, Duration is 4 hours, 4times/day, Repeat is ON”, then you will hear the voice prompt “Please take medication now” at 9am, 1pm, 5pm, and 9pm. Since repeat in ON this alarm will repeat every day. -
Page 22: Alarm
Alarm: **If you have registered two pendants to the system, you can set pill alarms on one or both of the pendants. Setting An Alarm Press Press 7 times to ‘ALARM’ Press Choose Pendant # by pressing (If you have a second pendant) When you pick a pendant number press the screen will display ‘PLEASE WAIT’... -
Page 23: Cancel Alarms
Cancel Alarm Press Press 7 times to ‘ALARM’ Press Choose Pendant # by pressing (If you have a second pendant) When you pick a pendant number press The screen will display ‘PLEASE WAIT’ The screen will display ‘SET’ Press ‘CLEAR’ Press key to save Press... -
Page 24: Language
Language The Touch N’ Talk with Fall Detection is only available in English at this time. Default This function can restore factory settings, EXCLUDING date/time setting and SOS help numbers/Alarm/Pill Alarm. Press Press 9 times to get to ‘DEFAULT’ Press to select ‘DEFAULT’... -
Page 25: Registration
Registration: Register: Adding an additional pendant Press Press 10 times to ‘REGISTRATION’ Press The screen will display ‘REGISTER’ Press *** while on this step, the screen will display ‘PLEASE WAIT’ and a red light under the base station SOS key will flash Press and hold the and the red... -
Page 26: Deregister Removing Pendants From Systems
Deregister: Removing Pendants from Systems Press Press 10 times to ‘REGISTRATION’ Press Display will read ‘REGISTER’ Press ‘DEREGISTER’ Press *** while on this step, the screen will display ‘PLEASE WAIT’ and a red light under the base station SOS key will flash After a few seconds the screen will display ‘PLS REGISTER’... -
Page 27: Fall Detection/Man Down Function Settings
Fall Detection/Man Down Function Settings: How Does Fall Detection/Man Down Work? If the panic button is laying at a 30-degree angle or less, for more than 30 seconds the system will recognize that position as a ‘Man Down’ or ‘Fall’. When the system detects a fall, it will start beeping. -
Page 28: Features/Functionality
FEATURES/ FUNCTIONALITY How automatic cut-off operates The line-out modular jack on the base unit is for connecting your own telephone to a telephone line. When you press the SOS button to activate an SOS call, the SOS call will be prioritized to call out and any call currently being made using the line-out jack will be disconnected so the SOS call can get a dial tone to call out. -
Page 29: Paging
The battery icon will ‘cycle’ full and empty and totally disappear during normal charging. This is a normal process of charging and discharging. Parallel’ displayed on the base display means that a telephone on the same line has been picked up. Paging If you have misplaced the panic button you can press the Page key to locate it. -
Page 30: Making/Receiving A Normal Call
Answering/Making a Normal Call Making A Normal Call A normal telephone call can be made through the pendant by using the base keypad for dialing. Dial your desired number on the keypad then press Press to cancel or hang up the call and return to the main screen. -
Page 31: Troubleshooting
Troubleshooting Out of range options: If your pendant is indicating that it is out of range do the following Make sure the pendant is registered Make sure that the unit has power Move base station to higher location Turn the pendant off and then back on If these steps do not help, let the pendants power run completely out, when the pendant will no longer power on, place the pendant on the charger and charge for 48 hours. -
Page 32: Services
LISTEN... as our experts talk you through the problem. LIMITED WARRANTY AND SERVICE ASSISTIVE TECHNOLOGY SERVICES LLC Warrants this product to be free from defective materials or factory workmanship and will replace or repair this unit or any part thereof, except batteries, if it proves to be defective in normal use or service within 1 YEAR of original purchase date.
