INSTALLATION INSTRUCTIONS
HB0132
CP55IQ, CP57IQT AND CP57E SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13
14.
AND
BEST; Hartford, Wisconsin www.BestRangeHoods.com 800-558-1711
BEST; Drummondville, QC, Canada www.BestRangeHoods.com 866-737-7770
To register your product online or for additional information visit www.BestRangeHoods.com
SV21422 rev. 06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP55IQ series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Best CP55IQ series

Summary of Contents for Best CP55IQ series

  • Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 13 BEST; Hartford, Wisconsin www.BestRangeHoods.com 800-558-1711 BEST; Drummondville, QC, Canada www.BestRangeHoods.com 866-737-7770 To register your product online or for additional information visit www.BestRangeHoods.com SV21422 rev. 06...

  • Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following

    8. To reduce the risk of fire, use only metal ductwork. 10. To reduce the risk of fire and electrical shock, the Best CP55IQ 9. This unit must be grounded.
  • Page 3 - CP55IQ AND CP57IQT POWER PACK SYSTEMS - ODEL ODEL ODEL ODEL (8” R (10’’ R OOF CAP OUND WALL CAP IGH CAPACITY ROOF CAP OUND WALL CAP 8” R ODEL OUND (10” R OUND ADJUSTABLE ELBOW ADJUSTABLE ELBOW 8” R OUND ODEL STANDARD DUCT...
  • Page 4 - CP57E POWER PACK SYSTEM - ODEL IGH CAPACITY ROOF CAP ILB9 (800 ODEL ILB11 (1100 EB12 (1200 ODEL LINE BLOWER EB15 (1500 EB6 (600 ODEL 8” 12” INCLUDES TWO EB9 (900 XTERIOR BLOWER 10’’ ROUND TRANSITIONS XTERIOR BLOWER ODEL (10”...

  • Page 5: Install Ductwork And Electrical Wiring

    Install proper-sized ductwork, elbows and roof or wall cap for the type of blower you are installing. If installing CP55IQ Series power pack, use 8” round ductwork and if installing CP57IQT or CP57E Series power pack, use 10” round ductwork. Use metal foil duct tape to seal duct joints.

  • Page 6: Prepare Installation

    2. PREPARE INSTALLATION WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. NOTE: Before proceeding to the installation, check the contents of the box. If items are missing or damaged, contact the manufacturer. Make sure that the following items are included: - Power Pack - Accessories •...
  • Page 7 4. MOUNT CUSTOM HOOD INTERNAL FRAMEWORK WARNING The wood hood must be positively secured to wall studs or other wooden framework behind the drywall. Make sure it is capable of supporting its own weight and the weight of the CP55IQ, CP57IQT or CP57E. Failure to do so may cause personal injury or damage to countertop or cooktop.
  • Page 8 7. REMOVE BOTTOM PANEL Using a Phillips screwdriver, remove both bottom panel retaining Disassemble bottom panel from power pack and set aside. screws and set aside. ETAINING SCREW LOCATIONS IDE VIEW HO0224 HO0120 8. REMOVE KNOCK-OUT OPENING (CP55IQ CP57IQT S ERIES ONLY From inside the power pack, remove the wiring box cover by removing 2 retaining screws and set aside.
  • Page 9 10. INSTALL THE 10” ADAPTER (CP57IQT S ERIES ONLY Using 2 no. 8 x 3/8” screws from parts bag, assemble the adapter on the top of the power pack. OUNTING SCREW LOCATIONS Seal all joints with metal foil duct tape to eliminate air leaks. HJ0026 11.

  • Page 10: Connect Wiring

    12. INSTALL THE ROUGH-IN PLATE FOR EXTERNAL BLOWER (CP57E S ERIES ONLY Refer to the instructions included with the selected blower/rough-in kit (sold separately) for details on installing the rough-in plate. Install the rough-in plate so that the wiring box is located on the right side when facing the hood, as specified on the blower housing label.

  • Page 11: Reinstall Bottom Panel

    15. PERFORM THE EXTERNAL BLOWER CONNECTIONS (CP57E S ERIES ONLY WARNING Do not plug the two cords together. To install the blower see instructions included with the blower. Plug the 3-prong plug cord from rough-in plate to the 3-prong male connector inside the power pack (A) and the 2-prong male connector cord from rough-in plate to the 2-prong plug inside the power pack (B).
  • Page 12 18. REINSTALL HYBRID BAFFLE FILTERS CAUTION Remove protective plastic film covering hybrid baffle filters before installing them. It is recommended to install side filters first and finish with center one(s). 1. Insert one end of hybrid baffle filter into the front channel of the power pack.
