GUIDE
IRONMAN 4X4 LIGHTING
GAMMA
VEGA
SUPERNOVA
7" / 175mm 100W Halogen
9" / 220mm 100W Halogen
9" / 220mm 35W HID
Driving Light / Spot Light
Spot Lights
Spot Light
H3 Bulb
H1 Bulb
H11, 6000k Bulb
IMPORTANT: Please read and fully understand these fitting
instructions prior to installing your Ironman 4x4 Driving Lights
Advertisement
Table of Contents
Summary of Contents for Ironman4x4 GAMMA
- Page 1 INSTALLATION GUIDE IRONMAN 4X4 LIGHTING GAMMA VEGA SUPERNOVA 7” / 175mm 100W Halogen 9” / 220mm 100W Halogen 9” / 220mm 35W HID Driving Light / Spot Light Spot Lights Spot Light H3 Bulb H1 Bulb H11, 6000k Bulb IMPORTANT: Please read and fully understand these fitting...
- Page 2 Mounting Consult your local and state regulations regarding minimum and maximum mounting height above the ground, or specific requirements. Mount both of the lamps at the same height. Nudge bars, light bars and bull bars make excellent mounting platforms. Position the lamps at an equal distance from the centre of the vehicle.
- Page 3 Negative Switching Find a sheltered location in engine bay to mount relay away from extreme heat sources and moving parts. Relay must always be mounted in an upright position. Connect 4mm wire from terminal 86 on relay to the negative high beam wire on headlight. Connect 5mm wire from terminal 87 to positive wire on driving lights.
