XENO XLCDHDA21W User Manual

Tft lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER' S
TFT LCD MONITOR
MANUAL
MODEL: XCLD21HDAW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XLCDHDA21W and is the answer not in the manual?

Questions and answers

Related Manuals for XENO XLCDHDA21W

Summary of Contents for XENO XLCDHDA21W

  • Page 1 USER’ S TFT LCD MONITOR MANUAL MODEL: XCLD21HDAW...

  • Page 2: Table Of Contents

    Contents 1. Scope ..........................6 2.1 Power Supply ......................6 2.2 Video Characteristics ....................6 2.3 PC Input ........................6 2.4 Audio Input ......................... 6 2.5 Environmental ......................6 2.6 EDID ........................... 7 2.7 Connectors ......................... 7 3. Controls and indicators ....................8 3.1 PC menu ........................
  • Page 3 Before You Begin Read these instructions before installing or operating this product. Note: This installation should be made by a qualified service person and should conform to local codes. This manual provides installation and operation information. To use this document, you must have the following minimum qualifications: ...
  • Page 4 WARNINGS AND CAUTIONS To reduce the risk of fire or electric shock, do not insert any metallic objects through the ventilation grills or other openings on the equipment CAUTION IMPORTANT SAFEGUARDS 1. READ AND RETAIN INSTRUCTIONS Read the instruction manual before operating the equipment. Retain the manual for future reference.

  • Page 5: Ce Compliance Statement

    Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 12. SERVICING Do not attempt to service the video monitor or equipment yourself as opening or removing covers may expose you to dangerous voltage or other hazards.

  • Page 6: Scope

    1. Scope This specification is used to define the performance of XLCDHDA21W color TFT LCD monitor. This system also supports both SD/HD video input and PC input. In SD video input mode, the system can automatically detect the NTSC signal and PAL signal. In HD mode, it supports AHD 2.0 1080P, TVI 1080P, and CVBS 720H format, In PC mode, this system can support up to 1920 x 1080 VESA standards.

  • Page 7: Edid

    2.6 EDID This series of displays support EDID 2.7 Connectors A. AC IN: AC 100~240 Vac input (Socket IEC 320). B. CVBS IN: CVBS input (BNC Connector.) C. AUDIO IN: Stereo Audio input (3.5 mm Stereo Phone Jack) D. VGA IN: VGA input (15 pins D-SUB Connector). E.

  • Page 8: Controls And Indicators

    3. Controls and indicators A. “ ” Source button Press the button to show source menu. Select CVBS ,HDMI, D-SUB and AHD/TVI input signal B. “ ” UP buttons Press the buttons to scrolling the cursor to desired function. C. “ ”Down button Press the buttons to scrolling the cursor to desired function.

  • Page 9: Pc Menu

    3.1 PC menu The PC menu can set contrast, brightness, color temp and scale. Press ◄► button to adjust, press ▲▼ button to move, press menu button to exit. 3.2 Audio menu Audio menu can set bass, treble, balance, sound mode, equalizer, AVC and sound effect. Press ◄► button to adjust, press ▲▼button to move, press menu button to exit.

  • Page 10: Osd Menu

    3.3 OSD menu OSD menu can sleep timer, language, H-position, V-position, duration, halftone and reset defaults. Press ◄► button to adjust, press ▲▼button to move, press menu button to exit. 3.4 Geometry menu Geometry menu can set H-position, V-position, clock, phase and auto adjust. Press ◄► button to adjust, press ▲▼button to move, press menu button to exit.

  • Page 11: Channel Selection

    4. Channel selection “Source” menu can select channel, the options include VGA, HDMI, BNC (CVBS), and AHD/TVI and so on. Press ▲▼ button to select, press menu button to exit. The way of cleaning Please wipe dust and other particles with clean down less mull. If it is still not clean, please smear diluents neutral cleaner free from brightener on the clean down less mull and wipe with it.

  • Page 12: Mechanical

    7. Mechanical 7.1 Dimensions Model XLCDHDA21W (mm)
  • Page 13 Norbain SD 210 Wharfedale Road IQ Winnersh Wokingham Berkshire RG41 5TP XLCDHDA21W Manual V1.0...
