Healthy Climate HCWB3-17 Safety And Installation Instructions

SAFETY AND INSTALLATION INSTRUCTIONS FOR MANUAL HUMIDIFIER CONTROL FOR
HEALTHY CLIMATE HUMIDIFIER MODELS HCWB3-12, HCWB3-17 & HCWP3-18
ATTENTION INSTALLER: This product must be installed by a
qualified heating and air conditioning contractor. Failure to do
so could result in serious injury from electrical shock.
THESE INSTALLATION INSTRUCTIONS ARE FOR
THE MANUAL HUMIDIFIER CONTROL ONLY!
For humidifier installation, follow humidifier
installation instructions.
The Manual Humidifier Control is designed for low voltage service to
control humidification equipment. An increase in relative humidity (RH)
expands the nylon ribbon which opens the control switch to stop
operation of the humidifier. A decrease in RH reverses the process and
closes the control switch.
1. 120 volts may cause serious injury from electrical shock.
Disconnect electrical power to the furnace before starting
installation.
2. Sharp edges may cause serious injury from cuts. Use care
when cutting plenum openings and handling ductwork.
1. Do not set humidity higher than recommended. Condensation
damage may result.
2. Do not set humidity up to recommended levels if there is con-
densation on the inside of windows of any unheated living
space. Condensation damage may result.
3. Do not mount the Manual Humidifier Control on the supply
plenum or duct. The unit cannot withstand supply tempera-
tures and will malfunction.
4. Do not mount the Manual Humidifier Control downstream of
the bypass outlet. False humidity conditions will cause the
humidifier to operate incorrectly.
Read complete installation instructions and template before starting.
WARNING
WARNING
WARNING
HUMIDIFIER CONTROL
506407-01
9/2009
MANUAL HUMIDIFIER CONTROL
Location
Control can be mounted on wall in living space or on return duct.
For Wall Mount:
• Locate on an inside wall of living area approximately 5' above the
floor.
• Do not locate control in the direct path of drafts from open doors and
windows.
• Do not install where operation might be affected by lamps, sunlight,
fireplace, registers, radiators, concealed air ducts and pipes, or room
occupants.
• The basic rules for location of thermostats also apply to humidifier
controls.
For Duct Mount:
Locate on the furnace return air plenum or duct, at least 6" upstream
of the humidifier, humidifier bypass ductwork (if applicable) or fresh air
intake ductwork (if applicable).
General Instructions
• Do not mount the Humidifier Control on counter flow furnace.
Furnace malfunction will result in improper humidifier operation.
• Be sure the Humidifier Control is installed on a 24 VAC circuit only.
• Make sure no bare wires are exposed or insulation damaged.
• Make sure all splices are mechanically and electrically secure.
• To remove dirt or other foreign matter from the nylon ribbon and
control interior, dust lightly with a fine soft brush.
1
