Icel Manaus MG-3010 Operating Manual

Digital insulation resistance tester
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
MG-3010
Digital Insulation Resistance Tester
Operating Manual
1. Summary
Contents

Advertisement

loading

Related Manuals for Icel Manaus MG-3010

Summary of Contents for Icel Manaus MG-3010

  • Page 1: Table Of Contents

    MG-3010 Digital Insulation Resistance Tester Operating Manual Contents 1. Summary 2. Safety notice 3. Feature 4. Technique specification 5. Panel map 6. Operating 7. Maintenance 8. Accessories...

  • Page 2: Safety Notice

    1. Summary The newly style of Digital Insulation Resistance Tester is MG- 3010. It has fashionable design and improved electronic circuit, so that has more fully function, higher precision, easier operation. The output testing voltage can be selected in 250V/500V/1000V for deferent measurement.

  • Page 3: Feature

    3 Feature (1)Low power consumed CMOS double integral A/D convertor IC, auto zero. (2)3? digits LCD display, the max reading is 1999. (3)Data holding with symbol. (4)LED indicating shows high voltage is generated. (5)Voltage below AC600V can be tested. (6)Low battery indicated. (7)Output short current is over 1.5mA.
  • Page 4 MG-3010 200M Ω ~ 2000M Ω ±(5% readings + 5 digits)

  • Page 5: Panel Map

    5 Panel map GΩ INSULATION RESISTANCE TESTER 1000 MAX 700V Ω Ω 2000M 2000M Test V Sel Test V Sel (1) High voltage indicator light (2) High voltage button: TEST/STOP (3) Data holding button: Hold (4) Rotary switch (5) E (EARTH) socket (6) G socket (leakage current for insulation/input for ACV)

  • Page 6: Operating

    Operating Safety notices a.There is a possibility of causing an accident of electric shock after the measurement of insulation resistance is completed, Be sure to discharge the high voltage charged in the measuring object. b.There is a risk of electric shock during the measurement. Be careful not to touch the measuring terminal and measuring object during the measurement.
  • Page 7 Insulation resistance testing a .Connection of measuring lead Insert the plug of lead with big probe to “L” socket. Insert the plug of lead with big clip to “E” socket The lead with the big measuring clip is connected with the earth.

  • Page 8: Maintenance

    7. Maintenance This is a precise instrument and needs careful maintenance. a.Don't open the back lid . Don't use it if the back lid not fixed. b.Take out the test lead and turn off the power before replace battery. Please open the lid and fit the new battery. c.Take out battery and put it in the place where dry and airiness if the meter will be unused for long-term.
