WiPath PDT3000 Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
PDT3000
Service Manual
June 2008
www.wipath.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the PDT3000 and is the answer not in the manual?

Questions and answers

Summary of Contents for WiPath PDT3000

  • Page 1 PDT3000 Service Manual June 2008 www.wipath.com...
  • Page 2 Contents Section 1. Product Description Section 2. User Instructions Section 3. Programming using PDT3P Section 4. Technical Service...
  • Page 3 RCM3000 relay board for multiple relay control. The ruggedized case of the PDT3000 is constructed of glass reinforced ABS that gives it a strength similar to aluminium for operation in harsh environments such as mounting on forklifts for in-plant messaging. Depending on the connector configuration it can also be made weathertight to a rating of IP65.
  • Page 5 Once the message has been read the symbol will change to an opened envelope . The PDT3000 will hold up to 40 messages in its standard message stack and up to 10 locked messages. Locked messages appear at the bottom left of the display thus .
  • Page 6 Backlight Time Set how long backlight is to remain on after a key 5s/10s/30s/1m/5m/ press or message received (see next option) Permanent Backlight on Msg Turns the backlight on when message received. Y or N Display Instantly Display message automatically when received Y or N Display For Sets how long the message will remain on display...
  • Page 7 Standard Connectors 25 pin DB25 (P1) - Standard centronics parallel printer output. 9 pin DB9 (S1) - Standard RS232 serial port for programming and data I/O (pinout below.) BNC connector is for connecting the external antenna. DC Socket - Power in 11-32v AC or DC (recommended 12v DC). Optional Connectors An RJ11 4 pin socket (S2) provides a second serial port for multi I/O requirements.
  • Page 8 Section 3. Programming the PDT3000 using PDT3P Contents User Instructions For PDT3P Contents Introduction PDT3P Version Information Installing the software Connecting the PDT3000  Required Items: The Main PDT3P Window  Title Bar  Upload To Pager Button  Download From Pager Button ...
  • Page 9 Enable Over The Air Programming Capcode Option  OTAP Pager ID  Capcodes Levels The PDT UI Settings Window  Use the following settings  Settings PDT3000 Peripherals Port Pin-out Serial Port2 to PC Cable Alarm Inputs PDT3000 ROM Limitation...
  • Page 10 PDT3P Version Information PDT3P version 6.0 or over can only be used for the PDT3000 with the M16/62PE(M30626FHPFP) type of the processor and does not support the M16/62P(M30624FGPFP) and M16/62A(M30624FGAFP) processor types used on the PDT3000.
  • Page 11 4. Plug the PDT3000 into a 12-volt supply and plug in the DB9 plug into the back of the PDT3000. {PDT3P does not read or write to the PDT3000 unless instructed to do so. It is recommended that, unless you need to change the basic template of the PDT3000, you download the program in the unit first.
  • Page 12 The blue Title Bar at the top shows the current Template selected. Upload To Pager Button This button is used to upload new settings to the PDT3000. This will overwrite any settings currently in the PDT3000. Download From Pager Button This button is used to download the current settings from the PDT3000.

  • Page 13: Menu Options

    ES - Upgrade Use this option to upgrade the Flash ROM in the PDT3000. Only use this option if instructed to do so by a service representative. The latest rom file will always have the same version number as the PDT3P version currently loaded.
  • Page 14 Upload the configuration in the SES file to ES without changing anything in the file. ES - Get OTAP Capcodes Read Over The Air Programming Capcodes from the PDT3000. The OTAP capcodes which the unit had can be displayed on the OTAP option window if this reading operation was successful.
  • Page 15 Output Options Serial 1 The message received on this address/cap code will output on serial 1 - Set serial options (global) in the Serial Options window. For some serial formats, such as: "Control Input", "GPS Input", "IPage Input", "TNPP Output", "TNPP Input", "Output to Relay Board", "Message Direct to Relay Board"...
  • Page 16 Capcode Control Relay Board Settings Window Click any number of relays at the relay list table in this Window, then select the action in the "Relay Action" and "Momentary Close Time" box. After finishing all settings, click the "OK" Button to save the settings and return to the last window.
  • Page 17 Capcode Alarm Settings Window Input a certain time period in the "Alarm goes off time(ms)" text-box. After this period time(ms), if the unit does not receive the capcode, it will trigger alarms. Click the "Use audible alert" check-box, the unit will trigger the buzzer alarm. Sets the action that will occur on each of the 4 on board relays when any message on that capcode is not received within above setting time.
  • Page 18 The Printer Options Window Output Options Output to Printer Turns printing on (global option). (Note printing still needs to be set for each individual capcode in the Capcodes window. Output Time & Date Outputs Time & Date to Printer. Output Capcode Outputs Capcode to Printer.
  • Page 19 The Serial Options Window Serial Set up serial output or input options Serial Format Contains a number of standard settings for serial options to commonly used equipment and software applications. For some serial formats, such as: "Control Input", "GPS Input", "IPage Input", "TNPP Output", "TNPP Input", "Output to Relay Board", "Message Direct to Relay Board"...
  • Page 20 Header & Footer String Standard Settings Some standard settings for header and footer strings are: \r\n ----- new line %n or %N ----- name of address %a ----- address in decimal %c ----- address in 7-digit decimal(If address is larger than 7-digit, it will be cut to 7-digit. If it is less than 7 digits, zero will be padded) %A ----- address in hexadecimal %p ----- protocol...
  • Page 21 Transmitter Select and set up a transmitter Type Salcom 11-72 transmitter connected to serial port one Tait 800 connected to the DB25 port(TTL) Maxon SD-125 radio connected to the DB25 port(TTL) Apollo TX-125 transceiver connected to the DB25 port(TTL) Retransmit all capcodes Output all capcodes and messages to the transmitter Invert Transmitting Data Output inverted bit stream data to the transmitter...
  • Page 22 Response Input Options Window This window is used to set the messages and transmit them with the specific capcodes. Response Serial Input Options: Set the input messages which correspond to the output messages with the specific capcodes. A finished sign for input messages should be a line feed, or a carry return.
  • Page 23 Response for Logical Level Input Options: Set output messages for input pin states. The messages will be transmitted or output on serial when the input pin state changes. Input Pins: set pins whose states will be monitored. Capcode: a different capcode can be assigned per input. Debounce Time: time that contact must be triggered for before the alarm signal is generated.
  • Page 24 Message Relay Options Window This window is used to set global relay control actions according to the text contained in a message received on the selected capcodes. Up to 128 actions may be set for the PDR and PSR and 80 for the PDT. Sets the action that will occur on each of the 4 on board relays and the relays contained on the RCM2000 module (if connected) on receipt of matched text in the message on a specified capcode.
  • Page 25 Output to Control Relay Board Options This sets the actions of any one or more of the relays contained on the RCM2000 module. Each RCM2000 adds 32 additional relays and may be daisy chained. (Note: The RCM2000 connects to a serial port and the serial output format must be set to "Output to Relay Board").
  • Page 26 Allow Flex Paging Network to set the unit time by air (Flex only). Receiver type Unless otherwise advise use only the RCM option. The RCM receiver is almost exclusively used on the PDT3000. Allow decoding errors Selects the number of character errors that the receiver will accept before it discards (ignores) the message.
  • Page 27 OTAP Pager ID Set the PDT3000 to have a unique 7-digit number id to decode the OTAP message. The pager only processes the OTAP message when it contains its id or broadcast id or its group id. The 1200000 is broadcast id which can program all units.
  • Page 28 The PDT UI Settings Window This window is used to set standard User Interface settings that are normally set by the user via the PDT3000 display. Use the following settings If this box is checked the settings will be settable only from PDT3P and not from the PDT3000 user interface.
  • Page 29 Function Description Settings How long beeper sounds on initial receipt of Initial Alert Time 1s/5s/10s/30s/1m/ 5m message Warning Initial Alert How long beeper sounds on initial receipt of a 0,1s,2s,3s,4s,5s,10s,30s,60s,300s Time message on a Warning capcode. Watch Initial Alert How long beeper sounds on initial receipt of a 0,1s,2s,3s,4s,5s,10s,30s,60s,300s Time message on a Watch capcode.
  • Page 30 PDT3000 Peripherals This part describes how to connect a PDT3000 to supported peripherals. Port Pin-out The usable ports on the PDT3000 are as follows: DB25: parallel/printer output. DB9: PC/serial output 1, and various other peripherals. RJ11: PC/serial output 2. RJ45: These two ports have 4 relays (2 each), they are wired for normally open, and normally closed outputs.
  • Page 31 Serial Port2 to PC Cable Serial output 2 RJ11 to PC DB9 cable...
  • Page 32 Alarm Inputs The parallel port (DB25) may be used for monitoring alarm inputs, use the following configuration. PDT3000 DB25 ------ Input Pins in PDT3P Pin25(Ground) ------ Signal Ground Pin2(Input1) -------- Logic Input 1 Pin3(Input2) -------- Logic Input 2 Pin4(Input3) -------- Logic Input 3...

  • Page 33: Technical Service

    1: First Time Programming First Time Programming (FTP) is carried out at the factory. In rare instances, however, such as when a PDT3000 has been misprogrammed with an incompatible version of PDTP an FTP may be required to recover the unit.
  • Page 34 Tuning method - RCM Receiver. 1. Connect the paging device directly to the signal generator and set the output to -50dBm 2. Set the oscilloscope to 500mv/division and 1ms 3. Connect the scope lead to any ground point and use the probe on TP1 on the PDT PCB (picture 1) 4.
  • Page 35 Picture 2 – Example of desired signal at -50 dBm Picture 3 – Example of output at -115dBm after tuning at -50 dBm...
  • Page 36 When testing the paging device after tuning, it should receive at -120dBm (pocsag - different levels will be indicated on Flex (talk to WiPath)), however, if the device is set to a frequency that is used locally (i.e. a local...
  • Page 37 3. The PDT3000 Mainboard Schematic Insert schematic here Circuit Diagram Insert Cct diagram here Board Layout Insert board layout here...

  • Page 38: Troubleshooting
