- Page 1 12 Volt Dual Cylinder Air Inflator Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #52491 SAVE THESE INSTRUCTIONS...
- Page 2 ® Thank you very much for choosing a Klutch product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 5 Before Each Use ............................ 6 Operating Instructions .......................... 6 After Each Use ............................7 Troubleshooting ............................ 7 Parts Diagram ............................8 Parts List .............................. -
Page 4: Intended Use
Intended Use The Klutch 12 Volt Dual Cylinder Air Inflator is ideal for owners of trucks, SUVs, or off-road vehicles with tires 35 inches and larger. Technical Specifications Property Specification Motor Maximum working pressure 150 PSI Maximum re-start pressure 90 PSI... -
Page 5: Specific Operation Warnings
⚠WARNING PERSONAL SAFETY Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool may result in serious personal injury. -
Page 6: Before Each Use
Do not exceed the tire's rated pressure. Always wear gloves. Some exposed parts may become hot during use. Use extreme caution when connecting the unit to a power source, as batteries can vent explosive gasses. Do not use the unit for pumping, compressing, or transferring any gas or liquid other than air. The unit is not designed for the sourcing of breathable air. -
Page 7: After Each Use
4. Connect the RED power clip to a POSITIVE 12 volt source, BLACK power clip to a NEGATIVE ground point. 5. Test the connections by switching the inflator to “on”. Air will begin to flow. 6. Connect the air hose by screwing the brass inflator onto the tire valve stem. Only finger tighten the inflator. -
Page 8: Parts Diagram
Parts Diagram Page 8 of 12... -
Page 9: Parts List
Parts List Part Part Part Description Part Description Number Number Handle Plate assembly Cover of handle Rotor Round head screw Motor cover Handle assembly Stator Back cover assembly of Inner hex screw motor Accessory box Clamp Cylinder head cover Wool felt Inner hex screw Air inlet plate Cylinder head assembly... -
Page 10: Replacement Parts
Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ... -
Page 11: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Klutch product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 12 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 12 of 12...
