RFL Electronics Inc.
RFL 3000 4K-16 Ethernet Switch
Installation and User Guide
B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFL 3000 4K24F and is the answer not in the manual?

Questions and answers

Related Manuals for RFL Electronics RFL 3000 4K24F

Summary of Contents for RFL Electronics RFL 3000 4K24F

  • Page 1 RFL Electronics Inc. RFL 3000 4K-16 Ethernet Switch Installation and User Guide B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t , we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
  • Page 2 April 27, 2006 ™ RFL 3000 4K-Series 4K24 Switches Installation and User Guide Trademarks Ethernet is a trademark of Xerox Corporation NEBS is a trademark of Telcordia Technologies UL is a registered trademark of Underwriters Laboratories Important: The RFL 3000 4K24 Switches contains no user serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void.
  • Page 3 Contacting RFL Please use the mailing address, phone and fax numbers and email address listed below: RFL Electronics Inc. 353 Powerville Road Boonton TWP, NJ 07005-9151 Phone (973) 334-3100 Fax (973) 334-3863 Website: http://www.rflelect.com email support@rflelect.com Federal Communications Commission Radio Frequency Interference Statement Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 4: Table Of Contents

    Inspecting the Package and Product................... 8 Product Description - RFL 3000 4K24 Switches................ 9 2.2.1 RFL 3000 4K24F and 4K24C Switch chassis ..............9 2.2.2: RFL 3000 4K24FR “Reverse” model, front LEDs and connections in rear......10 2.2.3 Up-link, port 1X for Cascading ..................11 2.2.4 Fiber-port options for 4K24F Model, 100Mb fiber .............

  • Page 5: Specifications

    SPECIFICATIONS Technical Specifications Performance Aggregate Filtering Rate: 4.8Gb/sec for 24 100Mbps ports (all ports are wire speed) Aggregate Forwarding Rate: (for RFL 3000 4K-Series Fast Ethernet ports) (all ports are wire speed) 14.4M frames per second, 24-port units Data Rate: 10 Mbps and 100Mbps Address Table Capacity: 2K node addresses, self-learning with address aging Packet buffer size :...
  • Page 6 Fiber Single-mode connector types: Fiber Port, SC-type: Fiber optic single-mode, 100BASE-FX Fiber Port, SC-type: Fiber optic "long-reach” single-mode, 100BASE-FX Manual switch-selections and jumpers Fiber default: Full-duplex (Manual DIP switch settings inside of the chassis can select each of fiber ports to HDX mode. DIP switch SW4 controls fiber port # 2, whereas DIP switch SW6 controls fiber port #4.
  • Page 7 DC Power Supply (Options) -48VDC Power Input Voltage : 36 to 72 VDC 24VDC Power Input Voltage : 20 to 36VDC 125VDC Power Input Voltage : 120 to 160VDC Std. Terminal Block : “ -, GND, + ” Power Consumption: same as for AC models, see above For Dual Source and Redundant DC for –48VDC, 24VDC &...

  • Page 8: Ordering Information

    LEDs are in the front. RFL 3000 4K24C Same as RFL 3000 4K24F, but with all 24 RJ-45 ports “Copper”. RFL 3000 4K24CR “Reverse” model, Same as Model 4K24C Switch except user ports and the power input connectors are in the rear.

  • Page 9: Product Description - Rfl 3000 4K24 Switches

    -port modules . Optional fiber ports are normally configured and tested with the RFL 3000 4K24F unit in the factory, but may be configured in the field. The 22 copper RJ-45 ports are dual speed 10/100 Mb auto- negotiating.

  • Page 10: 2: Rfl 3000 4K24Fr "Reverse" Model, Front Leds And Connections In Rear

    Power 100M 100M Figure 2.2.1a: Front view, 24-port RFL 3000 4K24F and 4K24C Switches The LED status indicators and the manual switches are located on the front panel of RFL 3000 4K24F and 4K24C Switches. There are Full-duplex/Collision (FDX/COL), Link/Activity (LINK/ACT) and (100/10) LED indicators for each 10Mbps and 100Mbps domain, for visual indication of the operating status of each domain.

  • Page 11: Up-Link, Port 1X For Cascading

    On the RFL 3000 4K24F, the user may select full- or half-duplex mode per-port with an internal jumper setting (See Section 3.4) for the flexibility to adapt to any type of Fast Ethernet devices.

  • Page 12: 4K24C, 10/100 F/H Dual-Speed Switched Ports, Rj-45 (Copper Only)

    100M 2.2.6 Frame Buffering and Latency The RFL 3000 4K24F or 4K24C are store-and-forward switches. Each frame (or packet) is loaded into the Switch’s memory and inspected before forwarding can occur. This technique ensures that all forwarded frames are of a valid length and have the correct CRC, i.e., are good packets.

  • Page 13: Features And Benefits

    To minimize the possibility of dropping frames on congested ports, each RFL 3000 4K24 Switch dynamically allocates buffer space from a 1MB memory pool, ensuring that heavily used ports receive very large buffer space for packet storage. (Many other switches have their packet buffer storage space divided evenly across all ports, resulting in a small, fixed number of packets to be stored per port.

  • Page 14: Applications

    RJ-45 ports provide twisted pair segment connections, with N-way auto- negotiation and switching capability per port. Full-duplex or Half-duplex operation, auto-sensing All fiber and RJ-45 (copper) ports are capable of half- or full-duplex, individually selected. All RJ-45 ports support 10/100 auto-negotiation. Standard (ports in front) or Reverse (ports in rear) rack mounting The 4K24 is offered with ports and LEDs in the front, or in a “reverse”...
  • Page 15 But the RFL 3000 4K24F . . . with the optional two switched fiber ports at 100Mb speed, with full-duplex mode as a default setting on fiber ports, and with a large batch of RJ-45 N- way 10/100Mb ports as well.

  • Page 16: Installation

    The RFL 3000 4K24 Switch fits nicely in this environment, and offers future backbone expansion. The 24 switched copper ports are provfided by a RFL 3000 4K24. Should the number of servers expand, more than one server can be accessed at full speed from any switched 4K24 port by any of the users simultaneously.

  • Page 17: Connecting Ethernet Media

    The location of a RFL 3000 4K-Series Switch is dependent on the physical layout of the network. Typically the Switch is placed in a central wiring location where groups of network devices need to be connected in order to communicate with each other. These Switches are typically rack mounted in a wiring closet (see Section 3.3.2 below), but they have rubber feet and can also be installed on a shelf or table top.

  • Page 18: Connecting Fiber Optic Sc-Type And Mtrj, "Snap-In

    1. Before connecting the fiber optic cable, remove the protective dust caps from the tips of the connectors on the FKM. Save these dust caps for future use. 2. Wipe clean the ends of the dual connectors with a soft cloth or lint-free lens tissue dampened in alcohol.

  • Page 19: Connecting Twisted Pair (Rj-45,Cat3, Cat5, Unshielded Or Shielded)

    3.2.4 Connecting Twisted Pair (RJ-45,CAT3, CAT5, Unshielded or Shielded) The RJ-45 ports of the RFL 3000 4K-Series can be connected to the following two media types: 100BASE-TX and 10BASE-T. CAT 5 cables should be used when making 100BASE-TX connections. When the ports are used as 10BASE-T ports, CAT 3 may be used.

  • Page 20: Installing And Removing Fkm Fiber Port Modules

    The 23” brackets and ETSI brackets are also available (optional) for Rack-mounting of RFL 3000 4K Series Switches. The 23” brackets are popular in the Telco industry where they are a standard for Central Office rack-mounting purposes. The 23” brackets are mainly used for larger equipment assemblies in rack-mounting frames, and are frequently accessed in operation from both sides.

  • Page 21: Preparation For Changing Fkm Fiber Port Modules

    Changing FKM modules in a RFL 3000 4K24F Switch is a complex procedure that requires great care. Please read the Port Module Insertion Guide and this 4K24 Manual thoroughly before doing any field changes of FKM modules. If you are installing an FKM, make sure the FKM Module package has all necessary accessories to install it properly.

  • Page 22: Installing Fkm Modules In Rfl 3000 4K24F Switches

    FKM module removal is covered in Sect.3.4.3, installation in Section 3.4.2. 3.4.2 Installing FKM Modules in RFL 3000 4K24F Switches Up to two front-mounted fiber ports may be installed in one RFL 3000 4K24F Switch unit via an FKM. Follow these steps to install a FKM.

  • Page 23: Removing Fkm Modules From Rfl 3000 4K24F Switches

    Power 100M Figure 3.4.2b: Inserting PM Modules into a RFL 3000 4K24F NOTE: The optional FKM slots need not be filled in order for the RFL 3000 4K24F unit to be operational. When leaving FKM slots empty, always use a face plate (RFL 3000 FKM-BLNK) to cover the slot opening in the front panel.

  • Page 24: Manual Settings For Fiber Ports (Hdx Or Fdx)

    Screw on top of FKM Module (Retaining Screw) Magnum 4024F Switch Col/FDX Col/FDX Link/Act Link/Act 100M Power 100M Figure 3.4.3a: Front View - Remove FKM Module Retaining Screw Step 3. Remove FKM Module Gently pull the FKM module up and out of the connector socket (see Figure 3.4.3b). Magnum 4024C Switch 14 16 Col/FDX...

  • Page 25: Powering The Rfl 3000 4K24 Switch

    If a user toggles switch 4 to the DOWN position, then fiber port # 2 will be set to half- duplex. The factory default settings for fiber ports will be always UP position for full- duplex. DIPSwitch S ettings for Fiber Half Duplex Full-duplex Factory Settings Port...

  • Page 26: Status Leds

    on the same port segment will be filtered, constraining them to that one port and relieving the rest of the network from processing them. A packet whose destination address is on another port segment will be forwarded to the appropriate port, and will not be sent to the other ports where it is not needed.

  • Page 27: Auto-Negotiation For Rj-45 (Copper) Ports

    Use port #1 (or ports 2 thru 24) for straight-through twisted pair cabling from the 4K24 switched port to a user device, or the “1X” port for cross-over or up-link segment connections from the first 4K24 port to a repeater or hub or switch. Verify proper port connection by noting the port’s LINK/ACT status, which is illuminated when a proper link is made, and is blinking when there is activity.

  • Page 28: Auto-Negotiation, Full-Duplex Mode

    Auto-negotiation, full-duplex mode Full-duplex Ethernet provides separate Transmit and Receive data paths, enabling simultaneous bi-directional collision-free data movements on a port. The network topology must be a “star” type, not a “bus” type. With full-duplex mode, the cable distance is only limited by the physical layer line driver and cable attenuation. There are no collision-domain restrictions or limitations.

  • Page 29: Power Budget Calculations For 4K-Series With Fiber Media

    Power Budget Calculations for 4K-Series with Fiber Media Receiver Sensitivity and Transmitter Power are the parameters necessary to compute the power budget. To calculate the power budget of different fiber media installations using RFL 3000 products, the following equations should be used: OPB (Optical Power Budget) = P (min) - P (min)

  • Page 30: Inspecting The Package And Product (Optional)

    Inspecting the Package and Product (Optional) This section applies only to FKMs shipped as separate items, i.e., FKMs not factory installed in a RFL 3000 4K-Series FKM slot. Examine the shipping container for obvious damage prior to installing a FKM; notify the carrier of any damage which you believe occurred during shipment or delivery.

  • Page 31: Fkm-Msc 100Mbps Multi-Mode Fx-Sc-Type, "Snap-In" Connector

    5.2.2 FKM-MSC 100Mbps multi-mode FX-SC-type, “snap-in” connector The RFL 3000 FKM-MSC is also a multi-mode 100Mbps fiber optic transceiver module, similar to the FKM-MST. While the functionality of the these two modules is the same, the FKM-MSC is equipped with an SC-type "snap-in" connector instead of an ST-type. 100BASE-FX, FKM-2SC Connectors 5.2.3 FKM-SSC and –SSCL 100Mbps single-mode FX-SC-type, “snap-in”...

  • Page 32: Fkm-Blank

    5.2.5 FKM-Blank The FKM-Blank is a blank face plate that must be installed in any empty FKM slot. When the RFL 3000 4K24 chassis contains less than two front-mounted FKMs, the empty front slots must be covered with the FKM-Blank face plate in order to maintain proper cooling air flow, and for safety, etc Note: The FKM-Blank...

  • Page 33: When Calling For Assistance

    good device. Verify whether or not the problem is corrected. If not, go to Step 5 below. If the problem is corrected, the RFL 3000 4K24 Series Switches and its associated cables are functioning properly. If the problem continues after completing Step 4 above, contact your supplier of the RFL 3000 4K24 unit or if unknown, contact RFLby fax, phone or email (support@rflelect.com) for assistance.

  • Page 34: Shipping And Packaging Information

    Product name Serial Number (or Invoice Number) Packing List Number (or Sales Order Number) Date of installation Failure symptoms, including a full description of the problem. RFL will carefully test and evaluate all returned products, will repair products that are under warranty at no charge, and will return the warranty-repaired units to the sender with shipping charges prepaid (see Warranty Information, Appendix A, for complete details).

  • Page 35: Appendix A: Warranty Information

    APPENDIX A: WARRANTY INFORMATION RFL warrants the RFL 3000 products to be free from defects in materials and workmanship for a period of three (3) years from the date of shipment by RFL. During this warranty period, RFL will repair or, at its option, replace components in the products that prove to be defective at no charge other than shipping and handling, provided that the product is returned pre-paid to RFL.

  • Page 36: Appendix B : Internal Dc Power Supply Options

    APPENDIX B : Internal DC Power Supply Options B1.0 SPECIFICATIONS - FOR RFL 3000 4K8 DC-POWERED SWITCHES Power Supply (Internal -48VDC Option) DC Power Connector: 3 terminals: “-“, “GND”, “+” Input Voltage: 36 - 70 VDC Power Consumption: Model 4K24: 21 watt typical, 30 watts max. Power Supply (Internal 24 VDC Option) Industrial Application DC Power Connector: 3 terminals: “-“, “GND”, “+”...
  • Page 37 B3.0 APPLICATIONS FOR DC POWERED SWITCHES RFL 3000 4K-Series Fiber Switches are easily installed in a variety of applications where -48VDC, 24VDC & 125VDC power is used as the primary power source. The- 48VDC, 24VDC & 125VDC power configuration provides an Ethernet networking solution utilizing a special power supply in hubs with a proven track record.
  • Page 38 The actual connection procedure is straightforward. Simply connect the leads to the RFL 3000 unit, beginning with ground. Ensure that each lead is securely tightened. Note: The GND should be hooked up first. The 4K unit has a floating ground, so the user may elect to Ground either + or = terminal to suit the customer’s use.

  • Page 39: Appendix C: Internal Dc Dual-Source Power Option

    APPENDIX C: Internal DC Dual-Source Power Option C1.0 SPECIFICATIONS - FOR RFL 3000 4K-SERIES FIBER SWITCH Power Supply (Internal, -48VDC Dual-Source, model # Dual-Src-48V) DC Power Connector: First Source: “A+”, “A-“, 2nd Source “B-“, “B+” GND: Terminal for “earth” or ground wire connection to the hub chassis Input: Two separate sources, each at 36 - 70 VDC Power Consumption:...
  • Page 40 SUPPLY FUSE CHASSIS C4.0 FEATURES AND BENEFITS OF THE DUAL-SOURCE DESIGN a) The Switch unit can receive power from either input, “A” or “B”. The hub will normally draw its power from the DC source with the highest voltage at a given time. b) The Switch unit will not allow power to flow from a higher voltage input to a lower voltage input, i.e.
  • Page 41 A+ A- B- B+ 36-70VDC 36-70VDC Figure C5.0: -48VDC Dual-Source, wiring connections to the External Terminal Block on a RFL 3000 48VDC with Dual-Source option Note: The GND should be hooked up first. The 4K unit has a floating ground, so the user may elect to Ground either + or = terminal to suit the customer’s use.
  • Page 42 Or Dual-Src48V-SWITCH for model with ON-OFF switch Similarly, order “Dual-Src24V” or “Dual-Src125V” as a separate line item following the product model. Example: RFL 3000 4K24-24VDC or RFL 3000 4K24-125VDC Dual-Src24V for regular model with no ON-OFF switch Dual-Src24V-SWITCH for model with ON-OFF switch C7.0 OPERATION Operation of the Dual-Source RFL 3000 4K-Series-48VDC, 24VDC &...
