ancnoble 1MS1V-Solar User Manual

1 moisture 1 valve wireless field irrigation controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REV：1.03
1 Moisture 1 Valve Wireless Field Irrigation
Controller
1MS1V-Solar
User Manual
© 2014 ANC Technology
www.anctech.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1MS1V-Solar and is the answer not in the manual?

Questions and answers

Summary of Contents for ancnoble 1MS1V-Solar

  • Page 1 REV：1.03 1 Moisture 1 Valve Wireless Field Irrigation Controller 1MS1V-Solar User Manual © 2014 ANC Technology www.anctech.com...

  • Page 2: Table Of Contents

    ANC Technology Content 1.DESCRIPTION..........................3 2. SPECIFICATIONS.........................3 2.1 H ......................5 OW TO INSTALL BATTERY 3. POWER ON........................... 6 4. HOW TO ESTABLISH WIRELESS MESH NETWORK COMMUNICATION......7 5. POWER OFF..........................8 6. SYSTEM SLEEP..........................8 7. MANUALLY OPEN/CLOSE VALVES..................9 8. MANUALLY OPEN/CLOSE VALVES..................9 9.

  • Page 3: Description

    ANC Technology 1.Description This wireless field controller works with ANC Intelligent Controllers of GG-002C-WIFI/3G. Is powered by solar with rechargeable battery, control one moisture sensor, one magnetic valve and one pressure meter/switch for monitoring and reporting valve status. Also function as a relay in the mesh network. 2.
  • Page 4 ANC Technology 3. Extention cable is up to 20 meters. Pressure switch： 1, Pressure range：0.06Mpa-0.6Mpa; 0.1Mpa-1.3Mpa 2, Threads：Optional 1/4 NPT or 1/4G 3. Extension cable is up to 50 meters Pressure Meter: 1, Range: 0.1-1.0 Mpa 2, Accuracy: +/- 1% 3, Outport: 4-20mA 4, Supply power: 9-15VDC 5, Thread: Optional 1/4NPT, or 1/4G...

  • Page 5: How To Install Battery

    ANC Technology 2.1 How to install battery 1). Battery specification: Rechargeable Ni-MH AA battery 1.2v*10 2) Suggest to use rechargeable battery with more than 2300mAh. Battery box cover 3). Take out battery box, put Ni-MH AA rechargeable battery 1.2v*10 in, pay attention to +/- sign.

  • Page 6: Power On

    ANC Technology Battery 4). Put the battery box into the original place, put box cover back, screw up the cover. 3. Power on Push the red power switch, followed by two beeps, show ANC logo, then into operation. After power on, the controller will start to do the following check: 1.

  • Page 7: How To Establish Wireless Mesh Network Communication

    ANC Technology moisture sensor is been registered, the controller will control valve only. If not setup Dry/Wet control yet, or the setup is not right, there will be a reminder of failure. The system will not working until this setup is been fixed. Push 【Menu】 key into adjusting Dry/Wet control, adjusting them until right.

  • Page 8: Power Off

    ANC Technology Note A: For speed up establishment of wireless mesh network, please follow steps as below: 1. Register all the field controllers first. Then turn off all the field controllers. 2. During search time, the main controller must be in normal work status, not in any programmable menu, ready to pick all field wireless signals.

  • Page 9: Manually Open/Close Valves

    ANC Technology from sleep status to total turn off. After been total turn off, the solar panel will still charge the battery as long as there is sun. System will do auto-restart after the battery is recharged back. 7. Manually open/close valves Can manually on/off valves from main controller.

  • Page 10: System Setup

    9.1 How to install Pressure Switch/Pressure Meter 1. If install water pressure switch/meter for the valve, pull out the related pressure switch/meter connector from 1MS1V-Solar. Unscrew the screws. 2. Connect the wire from the pressure switch/meter to the connector, tight up the screw.
  • Page 11 ANC Technology the connection from water. 3. There is pressure switch/meter input beside valve connector for 1MS1V-Solar. Each only work for this valve to check if open/close is normal for this valve. Install one three way connector to the water out pipe as shown at following picture, install the pressure switch/meter to the 3 way connector, so the water pressure switch/meter can detect the water pressure from the valve.
  • Page 12 ANC Technology e, If the valve opens to irrigate normally, but shows “On FAILURE” on controller. Make sure the pressure switch is installed correctly first. Then open the black protective cover on switch, turn and adjustment screw anticlockwise to make the screw comes out some.

  • Page 13: Enable Pressure Switch/Meter

    ANC Technology 9.2 Enable pressure switch/meter Using [Browse/Menu] key into main menu, choose 【Set up valve】 , 【Enter/Save】 key to confirm, push up/down key or 【Browse/Menu】 browse into 【Valve on/off check】, and 【Enter/Save】to confirm. Push 【Browse/Menu】key will show choice between 【Enable】 and 【Disable】, choose one and push 【Enter/Save】...

  • Page 14: Adjust Dry/Wet Control Level

    ANC Technology 9.5 Adjust Dry/Wet control level Under 【Set up Sensor】 menu, push 【Browse/Menu】key to choose 【Adjust Control Level】and push 【Enter/Save】key into this setup. Push 【Browse/Menu】 key to choose setup dry control level or wet control level, through 【+ -】keys to adjust dry/wet control level, push 【Enter/Save】key to save.

  • Page 15: Register Moisture Sensor With Main Controller

    ANC Technology 2. The suggested registration distance between main controller and field controller is 2m≤X≤500m. 9.6.1 Register Moisture Sensor with Main Controller Under system main menu, choose 【Set up Sensor】, push 【Enter/Save】 key into this setup. Choose 【 Register/Remove】 , push【Enter/Save】 key into register/Remove menu.

  • Page 16: Register/Remove Valve

    ANC Technology Register/Removing status. 3. After registration, this field controller will only receive command from this main controller. If you need to move this field controller to another system, needs to remove all the registration information from this original main controller first. 9.6.2 Register/Remove Valve Details see 9.6.1 10.

  • Page 17: Frequently Ask Questions

    ANC Technology Figure 2.3 Figure 2.4 4. The upgrading interface will show the upgrading progress. The upgrade procedure takes a few minutes. Make sure the distance of two units are at effective communication distance of 2m≤X≤500m, to grantee good wireless communication. 5.
  • Page 18 ANC Technology If no sound is heard from the valve, check if the cable from the valve controller has been cut or broken. Check the connector in the extension tube, make sure it is clean, dry and the retaining nut is tightened. 1.
  • Page 19 ANC Technology A: Push [Browse/Menu] key to begin set up sensor, push [Enter/Save] key into set up sensor, then into [Adjust Control Level]. Then push “Enter/Save” key to begin setup, when Dry or Wet is flashing, push “Enter” again, then the LCD will show the current moisture level.
  • Page 20 ANC Technology controller shows failure. A：After long time without sun, the battery starts to discharge. The controller first goes to sleep, saving power, in this condition it will beep if a key is pushed, but not operate. If discharge continues, the controller will turn off to save power for automatic recharge.

  • Page 21: Packing List

    The failure cause maybe: Water pipe burst, valve broken. When the failures are removed, the alarm will stop too. 12.Packing list 1. One Wireless solar controller 1MS1V-Solar 2. One magnetic valve 3. One moisture sensor 4. One pressure meter...
  • Page 22 ANC Technology ANC Technology Limited Warranty card Dear Customer： Thank you very much for choosing ANC products. 1. This product has FCC verification and BV certification. 2. Warranty period is one year. Beginning on day of receipt. 3. Please keep your receipt and this warranty card. 4.
