Level 3 Repair
※ After setting 8960 ( EGSM / DCS )
1. After setting, prepare the call setup Display
2. Using an Originate Call, make a call.
3. Confirm the display "connected"
4. start the measuring
※ 8960 & spectrum analyzer (down & up at picture)
- spectrum analyzer : testing method = the way using an Osciliscope
- 8960 : connect using RF Cable between 8960 & RF Connector in board.
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
