8-3-6. T-Flash Card Working
Insert & Operate
microSD card
NG
CD300
break down ?
NO
R303 = 1.8V ?
NO
C335 = 3.0V ?
YES
Change Main PBA
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
YES
Change CD300
YES
Change CD300
NO
Check PM300(PMIC)
8-23
Level 3 Repair
