AirMech 104 Owner's Manual

Flap asymmetry tester for gulfstream gii-giii-giv
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the 104 and is the answer not in the manual?

Questions and answers

Summary of Contents for AirMech 104

  • Page 2 DESCRIPTION The AMI Model 104 Flap Asymmetry Tester is an intelligent hand-held electronic tester that is designed to facilitate the testing and alignment of the left and right flap asymmetry switches on the Gulfstream GII, GIII, and GIV aircraft. Since it is powered from the aircraft and requires no additional power source, it also tests the integrity of the flaps electrical system.
  • Page 3 TO SWITCH TO AIRCRAFT AUTO SET/ MANUAL RUN POWER SWITCH SWITCH SWITCH POSITION INDICATORS FLAPS LOCKED PHASE ERROR INDICATOR INDICATOR...
  • Page 4 WARNING: ANY PERSON OPERATING THIS TEST EQUIPMENT MUST BE FAMILIAR WITH THE APPLICABLE AIRCRAFT FLAP ASYMMETRY & ELECTRICAL SYSTEMS. CURRENT AIRCRAFT MAINTENANCE MANUALS MUST BE AVAILABLE AS A GUIDE TO PROPER OPERATION OF THE FLAP SYSTEM. THE FLAP ASYMMETRY SYSTEM WILL NOT PREVENT MOVEMENT WHEN THIS TEST BOX IS CONNECTED TO THE SYSTEM.
  • Page 5 LEFT RIGHT POWER RIGHT POWER RIGHT SWITCH MANUAL RUN RIGHT SWITCH MANUAL RUN MODEL 104 MODEL 104 FLAP ASYMMETRY TESTER FLAP ASYMMETRY TESTER GII - GIII - GIV GII - GIII - GIV NOTE POWER NOTE POWER ASYMMETRY SWITCH POSITIONS...

  • Page 6: Check Operation

    SET ASYMMETRY SWITCHES Set the flaps to the full down position and set the flap handle to any other detent position. Press and Hold the AUTO SET switch until flaps come to a complete stop. The AIRCRAFT (Reference) ‘A’ Switch Position indicator should be illuminated (green) along with the previous position indicator.

  • Page 7: Troubleshooting

    TROUBLESHOOTING CONDITION ACTION All indicators on tester Illuminate momentarily when This is normal. The test box performs a self test POWER is first turned on. each time it is turned on. PHASE ERROR indicator flashes when the flaps Due to mechanical tolerances between the switches are moved, but the ASYMMETRY SWITCH POSITIONS and within the flap drive system it may not be possible indicators match.
  • Page 8 Warranty & General Disclaimer AirMech Innovations (AMI) warrants this product to be free from defects in materials and workmanship for a period of TWO (2) years. During the warranty period, AMI will repair or replace, at its option, free of charge, any unit returned to AMI, freight prepaid.
