  • Page 1 USER MANUAL User manual Wheelchair with stand-up function...
  • Page 3 Where to find LifeStand Contact us if you have any questions regarding servicing or sales in the area where you live. LifeStand France SAS 5 Rue Clément Ader 69740 Genas France Tel. : (+33) (0)4 37 26 27 28 Fax : (+33) (0)4 37 26 27 29...
  • Page 4 Wheelchair with stand-up function Produced and published by Permobil AB, Sweden Version: 6, 2015-10 Art. no.: 205259-UK-0...

  • Page 5: Table Of Contents

    User Manual LSR Contents Indications and Contraindications for the Use of Stand-up Wheelchairs ........6 Important information about the user manual ................. 8 General information ......................... 9 Technical support ........................9 Spare parts & accessories ....................... 9 Scrapping ..........................9 Warranty ..........................

  • Page 6: Indications And Contraindications For The Use Of Stand-Up Wheelchairs

    Only a doctor or therapist can decide which method and safe standing training can be achieved with the Lifestand wheelchair. Indications Lifestand wheelchairs were specifically developed for people who have lost their ability to stand (e.g. paraplegia, multiple sclerosis, cerebral palsy etc.). Standing is used for therapy and prophylaxis of:...
  • Page 7 Contraindications m WARNING! A Lifestand wheelchair can only be used upon prescription by a doctor. Here are the most common contraindications for the use of a Lifestand wheelchair. Reduced bone density Should the bones already be very weak it is not recommended to stand. This could lead to fractures.

  • Page 8: Important Information About The User Manual

    Important information Important information about the user manual Congratulations on choosing a LifeStand stand-up wheelchair. Our aim is your continued satisfaction with your choice of supplier and wheelchair. Before you start using your wheelchair, it is important to read and understand this user manual and in particular the section on Safety.

  • Page 9: General Information

    User Manual LSR Technical support, warranty, etc. Technical support In the event of technical problems, you should contact Permobil LifeStand. Always state the wheelchairs serial number when contacting Permobil to ensure that the correct information is provided. Spare part & accessories Spare parts and accessories must be ordered through Permobil.

  • Page 10: Safety Rules And Regulations

    User Manual LSR Safety rules and regulations Safety rules and regulations A stand-up wheelchair is a complicated product. Therefore, you need to be very careful when you use and handle it. It is important to read and follow the instructions and safety rules given in this user manual before starting to use your wheelchair, as incorrect use could lead to injury to the user or damage to the wheelchair.
  • Page 11 User Manual LSR Safety rules and regulations Safety rules and regulations Your wheelchair may have been adjusted precisely to your needs on delivery, so you should always ask the advice of the person who provided the seat for you before making changes or adjustments to the wheelchair. Certain adjustments may impair the wheelchair's safety/functions or its suitability for your needs.
  • Page 12 In case of doubt, always contact a qualified service engineer or Permobil LifeStand. Weight limits The maximum user weight for your wheelchair is specified in the specifications section of this user manual.
  • Page 13 User Manual LSR Safety rules and regulations Safety rules and regulations m WARNING! Driving on sloping surfaces When you drive up a slope, ensure that you drive the wheelchair straight up the slope (vertically). If you drive at an angle, there is an increased risk of tipping over or falling.
  • Page 14 User Manual LSR Safety rules and regulations Safety rules and regulations m WARNING! Passengers The wheelchair is not designed to transport passengers, whatever their age. Nor is it designed for taking heavy items other than the user's personal belong- ings. The maximum user weight specified in the user manual for the seat in question must not be exceeded.
  • Page 15 User Manual LSR Safety rules and regulations Safety rules and regulations m WARNING! Seat belt The seat belt is only designed to hold the user in place and not as protection in the case of collision/accident. Check the condition of the belts regularly in case any damage or worn places have developed.
  • Page 16 LifeStand recommends that the wheelchair be equipped with a headrest and that this is used during transportation. During transportation it is essential that you are secured with a three-point safety belt that is attached to the floor and a side of the vehicle.
  • Page 17 User Manual LSR Safety rules and regulations Safety rules and regulations m WARNING! Flame resistance The material components have been tested against flammability. Seat cush- ions, back cushions and casing have been tested according to European flam- mability testing. (EN 1021-1:2006 and EN 1021-2:2006) Plastic parts fulfil the requirements according to UL94.
  • Page 18 Permobil LifeStand for information. It is extremely important that Permobil LifeStand is informed if the wheelchair or its accessories have been damaged during transport, during driving or for any other reason as soon as possible after the damage has occurred.
  • Page 19 User Manual LSR Safety rules and regulations WARNING! Clamping points In the following positions of the wheelchair there is an increased risk of entrap- ment. Please exercise particular caution here. Pay attention to the marked areas on the gap between moving and stationary parts. Danger that lose items...

  • Page 20: Design & Function

    Design & function General LSR is a manual wheelchair for outdoor and indoor use. It is intended for people with physical disabilities. Its raising function allows the user greater freedom of movement. We recommend gradual training in standing up under the guidance of a physiotherapist before you use "LSR"...

  • Page 21: Standing Function

    User Manual LSR Design & function Design & function Standing function The electric standing function makes it possible for the user to stand up in their wheelchair. This function is accessed from a control panel located on one arm rest.

  • Page 22: Relax Function

    User Manual LSR Design & function Design & function Relax function The LifeStand LSR has a Relax function. This function moves the legrests upwards and the backrest backwards, for a relaxing position for the user. Relax Function.

  • Page 23: Control Panel

    User Manual LSR Design & function Design & function Control panel The control panel has two buttons to control the seat's functions. The control panel is secured by means of Velcro and can be fitted to either arm rest in the position that best suits the user.

  • Page 24: Operation

    Operation General LSR is designed for use both indoors and outdoors. For use indoors, attention must be paid when driving in narrow corridors, when passing through doors and entrances and when traveling on elevators and ramps, etc. Remember that there is a risk of crushing when using the electrical functions.
  • Page 25 User Manual LSR Operation Operation Control panel General The wheelchair functions are operated via its control panel. The control panel has two buttons. Before using the raising function, it is extremely important that all the seat's settings are adapted to the current user.

  • Page 26: Standing And Relax Function

    User Manual LSR Operation Operation Standing and relax functions m WARNING! Make sure that the wheelchair is on a flat, horizontal surface, free of obstacles or ground depressions. Make sure the brakes are activated! If this is not the case, the wheelchair may roll away, with the risk of personal injury.
  • Page 27 User Manual LSR Operation Knee supports Before standing may commence, the knee supports must be secured in the right position. The knee supports place pressure on the upper section of the shin when the wheelchair mechanisms work together to raise the body to the standing position.
  • Page 28 User Manual LSR Operation Arm rest Before standing may commence, the arm rests must be secured in the right posi- tion. The arm rests then provide support for the upper body during the standing process and in the standing position.

  • Page 29: Driving Rules

    User Manual LSR Operation Driving Rules m WARNING! To prevent tipping with personal injury and property damage as a result, it is advisable to reduce the speed when turning, cornering and such manuevers. Never drive rapidly or at full speed along narrow passages, on narrow sidewalks, etc. where an incorrect maneuver or incorrect steering can cause an increased risk of accidents.
  • Page 30 User Manual LSR Operation Driving Rules Driving on Sideways Slopes Driving on a sideways slope must always be performed with great care. Avoid abrupt avoidance maneuvers and never maintain a speed higher than that at which you can maneuver the wheelchair in a safe and secure manner.
  • Page 31 User Manual LSR Operation Driving Rules Driving downhill You should always drive downhill at low speed and with great caution. Avoid braking suddenly and sudden evasive maneuvers and never drive so fast that you are unable to control the wheelchair safely without risks.
  • Page 32 User Manual LSR Operation Driving Rules Driving uphill You should always drive uphill with great caution. Avoid sudden evasive maneuvers and never drive so fast that you are unable to control the wheelchair safely without risks. m WARNING! You should be extremely careful when driving uphill on an uneven surface (for example grass, gravel, sand, ice and snow).

  • Page 33: Adjustment

    User Manual LSR Adjustment Adjustment Foot plate For the best sitting comfort and to achieve the correct position for standing up, the distance between the foot plates and the seat must be adjusted to a suitable length. It is important that the seat cushion that the customer will then use is also used when adjusting the leg rests.

  • Page 34: Knee Supports

    User Manual LSR Adjustment Adjustment Knee supports Loosen the screws holding the knee support pads in place. Adjust the distance between the pads and their angle to the required position. Secure in the required position by tightening the screws again.

  • Page 35: Seat Depth

    User Manual LSR Adjustment Adjustment eat depth The seat depth can be adjusted in 8 fixed stages, from 41-55 cm. There are two measurements required to be able to adjust the seat depth correctly: • The length of the thigh - the length of the thigh in sitting position (from the backside to the front of the knee.

  • Page 36: Center Of Gravity

    User Manual LSR Adjustment Adjustment Center of gravity Once the seat depth has been adjusted, it may be necessary to adjust the center of gravity. This is done by moving the mounting for the rear wheels. 1. Remove the two screws and...

  • Page 37: The Height Of The Armrest

    User Manual LSR Adjustment Adjustment The height of the arm rest The height of the arm rest can be adjusted to provide the user with optimal comfort. Adjustment 1. Loosen the two screws holding the arm rest, see picture. 2. Refit the arm rest to the required hole configuration and secure using the two screws, see picture.

  • Page 38: Back Rest Angle

    User Manual LSR Adjustment Adjustment Back rest angle For optimal comfort, the back rest angle can be adjusted on an adjustment range of 24°. 1. Undo the two screws on the left or right side that fix the back rest angle.

  • Page 39: Equalization System

    User Manual LSR Adjustment Adjustment Equalization system When moving from a sitting to standing position, the selected back rest angle can cause an undesirable effect. For example, it is possible that a straighter back angle that works well in a sitting position may have a tendency to cause a position that is inclined too far forward in a standing position.
  • Page 40 User Manual LSR Adjustment Adjustment The upper and lower seat frame and the back rest frame are all fitted to the back joint attachment. The lower seat frame can be fitted in three different positions. See picture. Position 1: To get a constant angle on the back rest when raising, fit the screw to position 1.

  • Page 41: Anti-Tip Protection

    User Manual LSR Adjustment Adjustment Anti-tip protection The anti-tip protection is fitted to the rear of the wheelchair. Used correctly, it can prevent the wheelchair from tipping over. Using the anti-tip protection is recommended in all circumstances. However, it may sometimes be necessary to temporarily fold up the anti-tip protection;...

  • Page 42: Brakes

    User Manual LSR Adjustment Adjustment Brakes The brakes must be adjusted regu- larly. Adjustment is also required as soon as the rear wheel attachments have been moved. 1. Remove the two screws on the inside of the frame holding the brake mechanism on the left and right side of the chair.

  • Page 43: Transport & Storage

    LifeStand recommends that the wheelchair be equipped with a headrest and that this is used during transportation. During transportation it is essential that you are secured with a three-point safety belt that is attached to the floor and a side of the vehicle.

  • Page 44: Wheels

    User Manual LSR Transport 2. Transport wheelchair without user Wheels In order to reduce the total size of the wheelchair for transport or storage, the back rest and wheels can easily be folded down or removed. Removal Press on the button in the center of the wheel and pull the wheel fully out.

  • Page 45: Back Rest

    User Manual LSR Transport Back rest In order to reduce the total size of the wheelchair for transport or stor- age, the back rest can easily be folded down. Folding down the back rest Undo the two locking pins for the...

  • Page 46: Lifting Points

    User Manual LSR Transport 3. Lifting points If two attendants need to lift the wheelchair, please follow the instructions below. Make sure the wheelchair is in seated position, not in relaxed or standing position. The two attendants has to be positioned on right and left hand side of the wheelchair.

  • Page 47: Maintenance And Repairs

    User Manual LSR Maintenance and repairs Maintenance and repairs General To ensure that your wheelchair works well, it is important for it to be used correctly and regularly maintained. A well maintained wheelchair lasts longer and has a lower risk of faults.

  • Page 48: Batteries/Storage

    User Manual LSR Maintenance and repairs Maintenance and repairs Batteries/storage • Please note that a battery discharges itself and that a discharged battery can burst when it is cold. If the wheelchair is to be stored unused for an extended period of time, the batteries must always be charged once a month to avoid damaging them.

  • Page 49: Charging Batteries

    User Manual LSR Maintenance and repairs Maintenance and repairs Charging batteries If the battery level falls too low, the control panel will emit an acoustic signal that indicates that the batteries need charging. In that case, the battery has enough power for a further 10 cycles.

  • Page 50: Cleaning

    User Manual LSR Maintenance and repairs Maintenance and repairs Cleaning Regular care and maintenance will prevent unnecessary wear and damage to your wheelchair. Below is some general advice. For severe soiling of the upholstery or damage to the surface finish, contact Permobil for information.

  • Page 51: Wheels

    User Manual LSR Maintenance and repairs Maintenance and repairs Wheels Check at regular intervals that the wheel- chair's tires have the correct tire pres- sure. The correct tire pressure provides the best movement and comfort, and a lower risk of puncture.Therefore check regularly that the tires have a pressure of 750 kPa.

  • Page 52: Reuse

    User Manual LSR Reuse Reuse If the wheelchair is transferred to someone else. The other user must firstly undertake the following steps: Clean according to our cleaning instructions. An authorised specialist dealer or manufacturer must carry out maintenance and maintenance requests if required.

  • Page 53: Serial Number Labels

    User Manual LSR Serial number label Serial number label Max. user weight Year of production Code for Seat width funding. Model name Month of production Serial Number Serial number label...

  • Page 54: Emergency Operation Of Seat Functions

    User Manual LSR CB02 Power Module Power Module The power module contains the control electronics of the standing-sitting function and the battery. The front has several connections and an On/Off switch. During long time storage, always put the On/Off switch to “Off”.

  • Page 55: Technical Specifications

    User Manual LSR Technical specifications Technical specifications General Name ................LSR Dimensions and weight Max. User Weight ............120 Kg. Seat width ................ 36/40/44/48 cm. Seat depth ............... 41/43/45/47/49/51/53/55 cm. Seat angle ..............6° Safe slope ..............8,5° Total Width ............... 58 - 70 cm Total Length ..............
