WATER WOLF UWC1.1 User Manual

9
MEMORY CARD/SD-CARD
The camera is compatible with Micro SD and Micro SDHD cards, from 2 GB to
32 GB.
Only insert and take out the Micro SD-card (See chapter 3.
Record – How to get started), when the camera is turned off.
Follow the guidelines of the Micro SD-manufacturers in terms of temperatures
and handling.
10
TRANSFERRING FILES TO YOUR COMPUTER
1. Turn off the camera and take out the Micro SD-card. Alternatively, the
camera can be connected to the computer via the USB cable, and the camera
turned on.
2. Insert the Micro SD-card into your computer's card slot.
3.
4. Double click on the 'external harddisc' icon.
5. Double click 'DCIM'.
6. Double click '100MEDIA'. Now all your recorded video is shown.
7.
If you have more than one camera, please create separate folders
for each camera. Otherwise, you might end up overwriting existing
11
TRANSFERRING FILES TO YOUR MAC
1. Turn off the camera and take out the Micro SD-card. Alternatively, the
camera can be connected to your MAC via the USB cable, and the camera
turned on.
2. Insert the Micro SD-card into your MAC's card slot.
3. The card is recognized by your MAC as an external disc. Double click
the icon (external disc/storage unit). Now all recordings are shown.
4.
'Paper/trash bin'. Otherwise, they will continue to take up space on the SD-card.
If you have more than one camera, please create separate folders
for each camera. Otherwise, you might end up overwriting existing
12
PLAYING AND EDITING FILES ON YOUR PC AND MAC
Media Player, Media Player Classic, VLC Player, Quicktime Player or similar.
VSDC etc.
7, VLC Player, Quicktime Player or similar.
can take some time.
We recommend that you use VLC Player:
www.videolan.org/vlc/
13
MAINTENANCE AND CARE
The camera is rinsed in lukewarm water with the cap mounted. Subsequently it
Don't use rubbing alcohol or other chemical products
because it might damage the camera lens!
14
SOFTWARE UPDATES
Please visit www.waterwolfhd.com for updates and follow the instructions.
15
CAMERA SPECIFICATIONS
Sensor 1/4" 1 megapixel CMOS-sensor
Video Format 1280x720p HD, 30 FPS, H.264 MOV
Storage space Approx. 60 minutes of recording = 4GB
Battery capacity 3,7 V/1200 mAh
Energy use 1,2 V
Power supply DC5V1A or larger
Continual Approx. 4 hours on fully charged battery
recording
Battery charge Approx. 4 hours
time
Micro USB 2.0 High Speed
USB interface
Micro SD-card or SD-HD card
Storage type
Supports 2GB – 32GB TF/Micro SD-Cards
Memory card
65 grams / 2,3 ounces
Weight
Dimensions 115 x 34 x 31mm (L x H x B)
Operative Microsoft Windows Win 7/ Win8 or later.
Mac OS X 10.4 or later.
system
Waterproof down to 120 meters
Waterproofness
om your
16
FILMING UNDER WATER / VLC PLAYER
visibility must be 1 meter or more. Oftentimes, algae and other water sedi-
ments – especially in ponds and lakes, will cause diminished water clarity.
The deeper the camera is probing, the less colour will show up in the footage.
Furthermore, algae and sediments will tend to make the recordings greenish.
To enhance details on your recordings – if they display unnatural colours or
they're diffuse - watch them in Sepia* mode.
Open the VLC Player menu 'Adjustments and effects' and choose 'Sepia' in the
'Colour' menu. This can be done while you playback your recorded video.
In the VLC Player it is also possible to see the strikes frame by frame. Pause
the video by clicking the 'space' button and move on to the next frame by click-
Please visit https://wiki.videolan.org/Hotkeys_table/ to see all the keyboard
shortcuts and to learn more about the interface.
*Sepia is a VLC Player function that enhances contrasts and clarity in your
footage.
And this
Waterproof to 120 m / 390 feet
4 hours recording time
Extremely light sensitive
HD video
. To
USER MANUAL
WATER WOLF UWC1.1
