Canoga Perkins L357 User Manual

Edgeaccess universal chassis system, gigabit ethernet service unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

L357 Gigabit Ethernet
Service Unit
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L357 and is the answer not in the manual?

Questions and answers

Summary of Contents for Canoga Perkins L357

  • Page 1 L357 Gigabit Ethernet Service Unit User Manual...
  • Page 3 This device contains static sensitive components. It should be handled only with proper Electrostatic Discharge (ESD) grounding procedures. NOTE! Cet équipement contient des composants sensibles aux décharges électro-statiques. Il doit absolument être manipulé en respectant les règles de mise à la terre afin de prévenir de telles décharges. L357 Gigabit Ethernet Service Unit...
  • Page 4 Perkins and any unauthorized use or disclosure of such drawings, specifications and information is prohibited. Canoga Perkins reserves the right to change or update the contents of this manual and to change the specifications of its products at any time without prior notification. Every effort has been made to keep the information in this document current and accurate as of the date of publication or revision.

  • Page 5: Table Of Contents

    L357 Series ..........................1-1 L357 Hosts..........................1-2 Chapter 2 Set-up and Installation................2-1 Set Up and Install the L357 ....................2-1 Install the Cables........................2-3 Measure Fiber Link Attenuation and Transmit Power ............2-3 Chapter 3 User Operation ..................3-1 L357 Functions and Power Up ....................
  • Page 6 5.2.2 New Installation ........................5-4 5.2.3 Switch 1 and 2 Settings Ignored.....................5-4 5.2.4 Problems With Fiber Optics....................5-4 Chapter 6 Specifications..................6-1 L357 Specifications.........................6-1 L357 Models ...........................6-1 Appendix A Warranty....................A-1 Appendix B Acronym and Abbreviation List ............B-1 L357 Gigabit Ethernet Service Unit...
  • Page 7 Figure 11. System Configuration Menu .................... 4-5 Figure 12. Hardware Configuration Screen..................4-6 Figure 13. Remote Hardware Configuration Screen................4-6 Figure 14. Functional Configuration Screen (UTP to Fiber L357) ........... 4-7 Figure 15. Remote Configuration Menu.................... 4-8 Figure 16. Remote Functional Configuration Screen ................ 4-8 Figure 17.
  • Page 8 List of Tables Table 1. Switch 1 and 2 UTP Speed Settings..................2-2 Table 2. Switch 3 Through 8 Functions .....................2-2 Table 3. L357 LEDs ...........................3-1 Table 4. System Configuration Option Definitions................4-5 Table 5. Functional Configuration Option Definitions ..............4-8 Table 6. Alarm Output Definitions....................4-11 Table 7.

  • Page 9: Chapter 1 Overview

    In addition, the L357 offers Quality of Service (QoS) implementation, Ethernet Jumbo Frame support, and Layer 2 statistics, as well as standard Canoga Perkins features, such as local and remote loopback, remote software upgrade, and remote control and monitoring through the Side-Band Management Channel (SBMC).

  • Page 10: L357 Hosts

    • To use a standalone enclosure, directly insert one L357. The L357 is hot swappable; it can be inserted or removed at any time without disrupting the data transfer of other modules in the chassis. L357 Gigabit Ethernet Service Unit...

  • Page 11: Chapter 2 Set-Up And Installation

    This section describes how to set up and install the L357. Set Up and Install the L357 Before setting up the L357, make sure the chassis is installed and its Users Manual is available for reference. If the system includes an optional DMM and CIM(s), make sure these are available: •...

  • Page 12: Table 1. Switch 1 And 2 Utp Speed Settings

    Insert the L357 into an unused slot in the BAM. Slide the L357 into the rails and push it firmly into the connector, then tighten the captive screw. If you encounter resistance, pull it out and check that no connector pins are bent.

  • Page 13: Install The Cables

    EdgeAccess Universal Chassis System Install the Cables The L357 uses both electrical and fiber optic cables. Electrical UTP cables connect to the User Port. Fiber optic cables connect to the Extension port. Dirty optical connectors are a common source of link loss or attenuation problems, especially for single mode fiber (SMF).
  • Page 14 EdgeAccess Universal Chassis System L357 Gigabit Ethernet Service Unit...

  • Page 15: Chapter 3 User Operation

    In the UCS 1000 and 1001, a BAM holds up to two L357s. On the BAM, the STA LED lights green if either L357 is operating normally. If both L357s are in error conditions, the BAM STA LED lights amber.
  • Page 16 Link Established Green blinking Receiving activity Amber System self-test Tx (Extension Port) No transmission activity Green blinking Transmission activity Amber Port in standby mode or system self-test Transmission disabled due to LLE, LLF, or user setting L357 Gigabit Ethernet Service Unit...

  • Page 17: Alarms

    3.3.1 Link Loss Forwarding When Link Loss Forwarding (LLF) is enabled, a fault on one side of the L357 propagates to the other side to notify that device and stops signal transmission (brings down the link). See Figure 3. Set the LLF propagation to User to Extension, Extension to User, or both directions.

  • Page 18: Link Loss Echo

    Link Loss Echo (LLE) propagates a link loss to the device connected to an optical Extension or User Port on the L357. See Figure 4. If a link loss is detected on the Extension Port Rx, the Extension Port Tx is disabled, echoing the fault back to the source. LLE configures the L357 to not send data until it receives data.

  • Page 19: Figure 6. Local-Remote Loopback Mode

    Diagnostics screen, set the Loopback State for the Remote module to Remote. Figure 8. Remote-Remote Loopback Mode For loopback, the L357 uses a unique MAC address that is listed on the Diagnostics screen as Loop Test MAC Address; for details about using the software and accessing the Diagnostics screen, see Chapter 4.
  • Page 20 EdgeAccess Universal Chassis System L357 Gigabit Ethernet Service Unit...

  • Page 21: Chapter 4 Management - Vt-100

    Management - VT-100 If the L357 is installed in a BAM, the system includes a DMM and a CIM, or the L357 is in a Model 1020 enclosure, you can manage the system through VT100 Terminal Emulation, which is accessible by a Telnet session, HyperTerminal or similar terminal emulation software, a standard SNMP network manager, and CanogaView.

  • Page 22: Management User Interface

    EdgeAccess Universal Chassis System Management User Interface The Management User Interface for the L357 provides screens for setup, monitoring, and diagnostics. You can access the screens directly by connecting to the serial port of the BAM, the Model 1020, the DMM in the chassis, or by establishing a Telnet session with the DMM.

  • Page 23: User Interface Organization

    10. Connected Sessions (for standalone enclosure, only) Some screen descriptions include detail about SPFs for reference; the information appears on-screen only when the L357 includes one or two SPFs. This chapter describes each of these screen in detail. 4.3.3 Login Menu The first screen is the Login Menu.

  • Page 24: Dmm Main Menu

    The Main Menu appears after you log in and provides access to all functions for the L357: setup, diagnostics, and reports. See Figure 10; options 9, 10, and 11 are available only when the L357 is in a standalone enclosure.

  • Page 25: System Configuration Menu

    EdgeAccess Universal Chassis System System Configuration Menu The System Configuration menu provides access to most configuration options for the L357. To access the System Configuration menu, see Figure 11 and Table 4 and follow these steps: 1. From the Main Menu, type , "System Configuration,"...

  • Page 26: Hardware Configuration Screen

    User Port Serial Number 20030590296 Ext Port Model Number 9400-528 Ext Port Description 1000M LX 1310/SM/7dB/SC Ext Port Hardware Rev. Ext Port Serial Number 20030590297 Power Supply AC 120/240 Figure 13. Remote Hardware Configuration Screen L357 Gigabit Ethernet Service Unit...

  • Page 27: Functional Configuration Screen

    You can only view the options for the Remote module, but you can set options for the Local L357 to work with the Remote module. For details about how RMTF, LLE, and LLF interact, see " Section 3.3" on page 3-3. Two reported hardware switch functions depend on the type of module: •...

  • Page 28: Figure 15. Remote Configuration Menu

    EdgeAccess Universal Chassis System Table 5. Functional Configuration Option Definitions Menu Item Description 1) Configuration Software: set the L357 to follow settings in software and ignore hardware Option Control switches Hardware: set the L357 to follow hardware switches 2) User Port Set the User and Ext Ports to specific data rate, 10M, 100M, or 1000M;...

  • Page 29: Figure 17. Remote Vlan Configuration Screen

    5) Incoming P-Bit 4 translated to 6) Incoming P-Bit 5 translated to 7) Incoming P-Bit 6 translated to 8) Incoming P-Bit 7 translated to 9) P-Bit Translation Enabled? Figure 19. Remote P-Bit Translation Table Screen L357 Gigabit Ethernet Service Unit...

  • Page 30: Trap Configuration

    , "Alarm Output Configuration," and press <Enter>. The Alarm Output Configuration screen appears. 2. Type the number for the alarm you want to set and press <Enter>. 3. Press <Space> to cycle to Major, Minor, or Off, and press <Enter>. 4-10 L357 Gigabit Ethernet Service Unit...

  • Page 31: Ip/Snmp Agent Configuration

    4.5.5 IP/SNMP Agent Configuration If the L357 is in a Model 1020, use the SNMP Configuration screen to view and set up the SNMP parameters on the L357. See Figure 22 and Table 7. To view SNMP parameters, follow these steps: 1.

  • Page 32: Figure 22. Ip/Snmp Agent Configuration Screen

    Set the port that will receive management packets; can be Ext. only, Port User only, Both ports, or No Management 9) Management VLAN Enable or disable the Management VLAN 10) Management VLAN Set the number for the VLAN; range is 0-4095 Number 4-12 L357 Gigabit Ethernet Service Unit...

  • Page 33: Figure 23. Host Access Table Screen

    The SNMP agent allows access to up to 24 Host IP addresses listed in the Host Table. Set up the Host information for the L357 on the Host Table screen. See Figure 23. To access the Host Table, follow these steps: 1.

  • Page 34: Security Configuration

    7. Allow username in password Enable or disable the username appearing as or within the password 8. Password Expiration Time Set how often in days, 1 through 365, that the passwords must be reset; 0 = disabled 4-14 L357 Gigabit Ethernet Service Unit...

  • Page 35: User Accounts Screen

    UI indicates access through Telnet, Console, SSH, FTP, or SFTP, and requires additional parameter setup • SNMPv3 enhances security and requires additional parameter setup • Access level: Supervisor, Operator, or Observer • Description: optional; up to 17 characters 4-15 L357 Gigabit Ethernet Service Unit...

  • Page 36: System Information Screen

    2. At the System Information screen, type the number for an item and press <Enter>, then follow the prompts to type in your information. 3. To return to the System Configuration menu, press <Esc>. 4-16 L357 Gigabit Ethernet Service Unit...

  • Page 37: Diagnostics Screen And Loopback

    Use the Loopback Setup screen to view current loopback conditions and set up loopback conditions for troubleshooting the L357. See Figure 29 and Table 9. For details about using loopback, see Chapter 3. To run a loopback test, follow these steps: 1.

  • Page 38: Link Status Screen

    Set to Yes or No; use to run loopback packets through a switch Loopback Point? Link Status Screen Use the Link Status screen to view the current link conditions on the L357. See Figure 31. To view link status, follow these steps: 1. From the Main Menu, type , "Link Status,"...

  • Page 39: System Alarms

    EdgeAccess Universal Chassis System System Alarms Use the System Alarms screen to view alarms and faults on the L357. See Figure 31. To view alarm status: 1. From the Main Menu, type , "System Alarms," and press <Enter>. The System Alarms screen appears.

  • Page 40: System Log

    3. To return to the Main Menu, press <Esc>. 4-20 L357 Gigabit Ethernet Service Unit...

  • Page 41: Utilities

    Restores all configurable settings to the defaults except for: 3) Reset Remote Configuration To date and time; password; BOOTP; Telnet timeout Default 4) Remote Craft Port Enable or disable the console port on the remote module 4-21 L357 Gigabit Ethernet Service Unit...

  • Page 42: Ping Generation

    2. At the PING menu prompt, set the PING parameters, and press <Enter>. "PING response received..." indicates a good connection; "TIMEOUT: Unable to reach [IP address]..." indicates a faulty connection. 3. To stop the PING , press <Esc>. 4-22 L357 Gigabit Ethernet Service Unit...

  • Page 43: Static Arp Table

    To use view an address, follow these steps: 1. From the Main Menu, type , "Utilities," and press <Enter>. 2. From the Utilities menu, type , "Dynamic ARP Table," and press <Enter>. 3. To return to the Utilities menu, press <Esc>. 4-23 L357 Gigabit Ethernet Service Unit...

  • Page 44: Software Upgrade

    If the firmware on the L357 is outdated, you need to upgrade it. If the L357 is in a chassis or 1030 enclosure within a domain with a DMM, go to the User Manual for the DMM and use that procedure to install the new software.

  • Page 45: Change Password

    4.13 Change Password If the L357 is in a standalone enclosure, you can update your password in order to maintain system security. You cannot change the password for any other users, especially those who are not logged in.
  • Page 46 EdgeAccess Universal Chassis System 4-26 L357 Gigabit Ethernet Service Unit...

  • Page 47: Chapter 5 Maintenance And Troubleshooting

    To ensure the proper performance levels, measure the fiber link loss, or link attenuation, for all fiber links. Each L357 is shipped with a document that lists the output power for each laser transmitter. To determine link attenuation, use either the L357 Tx source or a hand-held 1310/1550 nm laser source, a fiber optic test jumper cable (with known loss), and an optical power meter.

  • Page 48: Measure Transmitter Output Power

    5.1.3 Measure Transmitter Output Power To measure the output power, follow these steps: 1. Clean the connectors on the fiber optic test cable, then plug it in to the Tx connector on the L357. 2. Warm up each component for at least 30 minutes.

  • Page 49: Measure Fiber Link Attenuation

    Measure optical fiber links at the shortest wavelength of operation to determine the limiting factor in the loss budget. Each device that transmits to an L357 has a loss budget that is specified by the manufacturer and recorded on a data sheet provided with the equipment. That loss budget must be greater than the total of the measured loss of the fiber link and the attenuation of the L357s.

  • Page 50: New Installation

    5.2.3 Switch 1 and 2 Settings Ignored If the L357 was installed in a UCS 1000 or 1002 and set in the User Interface to software control, it ignores the hardware switch settings. To restore it to hardware control, access the Utilities screen and reset the configuration to default.

  • Page 51: Chapter 6 Specifications

    1000BASE LD 1310 nm SM 14 dB SC L357-1333 1000BASE XD 1310 nm SM 21 dB SC L357-1533 1000BASE ZX 1550 nm SM 21 dB SC L357-1543 1000BASE EX 155 0 nm SM 23 dB SC L357 Gigabit Ethernet Service Unit...
  • Page 52 1000BASE LD 1310 nm SM 14 dB SC L357-3333 1000BASE XD 1310 nm SM 21 dB SC L357-3533 1000BASE ZX 1550 nm SM 21 dB SC L357-3543 1000BASE EX 1550 nm SM 23 dB SC L357 Gigabit Ethernet Service Unit...
  • Page 53 1000 Mbps CWDM 1550 nm SM 22 dB SC L357-3075 1000 Mbps CWDM 1570 nm SM 22 dB SC L357-3076 1000 Mbps CWDM 1590 nm SM 22 dB SC L357-3077 1000 Mbps CWDM 1610 nm SM 22 dB SC L357 Gigabit Ethernet Service Unit...
  • Page 54 EdgeAccess Universal Chassis System L357 Gigabit Ethernet Service Unit...

  • Page 55: Appendix A Warranty

    Warranty Limited Lifetime Warranty Effective July 1, 2005 and After, Canoga Perkins warrants that, at the time of sale, and, for its lifetime, with certain exceptions noted below, every Canoga Perkins' labeled product purchased will be free from defects in material and workmanship for its lifetime, if properly installed and used in conformity to Canoga Perkins' published specifications.
  • Page 56 EdgeAccess Universal Chassis System Limitations Canoga Perkins may at its sole discretion modify its Limited Warranty at any time and from time to time. Other than those expressly stated herein, THERE ARE NO OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AND SPECIFICALLY EXCLUDED BUT NOT BY WAY OF LIMITATION, ARE THE IMPLIED WARRANTIES FOR FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY.

  • Page 57: Appendix B Acronym And Abbreviation List

    Megabits per second Modem Multimode Fiber Physical Layer RMTF Remote Fault Receive signal SBMC Side-Band Management Channel Single Mode Single Mode Fiber SNMP Simple Network Management Protocol TFTP Trivial File Transfer Protocol Terminal Transmit signal L357 Gigabit Ethernet Service Unit...
  • Page 58 CANOGA PERKINS CORPORATION 20600 Prairie Street Chatsworth, California 91311-6008 USA Phone: (818) 718-6300 FAX: (818) 718-6312 Web Site: www.canoga.com Email: fiber@canoga.com...
