- Page 1 Operation and Installation Guide HDS2800 Series Encoder Modulator High Definition (HD) Digital COFDM MPEG2 and H.264 Modulator with IP Multicast. 19” Rack Mount Revision Firmware version Released File HDS2800 Rev 4.0.Docx...
-
Page 2: Table Of Contents
4.4 IP Output Setting ......................... 14 4.5 Modulator setting ......................... 15 4.6 Utilities - Save/Restore ........................ 16 4.7 Reboot ............................18 4.8 Firmware ............................18 TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 2 of 18... -
Page 3: Key Features
• The HDS2800 has an excellent cost per HD digital channel. TeleDelta is an Australian owned company, with local engineering and support facilities in Australia and New Zealand for more information please visit our website www.teldelta.com TeleDelta is proudly an Australian owned company. -
Page 4: Hds2800 Rack And Wall Frames
Enter button: for confirm Menu button: for back step Lock button: press to lock / unlock Data port – IP multicast output Alarm indicator TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 4 of 18... -
Page 5: Installation
Exercise caution when operating any electrical device, do not operate any device unless you are qualified to do so. Do not stick your fingers into a light bulb socket. TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com... -
Page 6: Operation From The Front Panel
This version of the manual is intended for setup and maintenance of the unit using the NMS web interface. For front panel (LCD) operation please refer to the LCD supplement – available on request TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com... -
Page 7: Programming Via Inbuilt Web Server / Nms Operation
After login, the Welcome system status screen will display As at May 2102 Google Chrome 18.0.1025.168 m, and IE9.0.6 are known to work. Goodness knows what the future will hold… TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com... -
Page 8: Input Configuration Setting
For RCA modules the interface defaults to VGA, this must be changed to RCA. The aspect ratio for RCA input modules must also be changed to 16:9. Repeat the setup as required for all inputs fitted (1-4). TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com... -
Page 9: Www.teledelta.com
HDS2800 Operation and Installation TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 9 of 18... -
Page 10: Asi Input Setting
Selects all the output programs with one-click. Parse Timeout Default Time limitation to parse the input stream (before TimeOut) Table is blank – see details below PID Pass Default TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 10 of 18... -
Page 11: Www.teledelta.com
EPG & NIT tables,) from here you can pass them through the multiplexing module without changing anything. Click “Add” to add more boxes for the Input & Output PIDs, then click “Apply” to confirm. TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com... -
Page 12: Nit Table Setting
Update NIT: click to update the NIT tables in system, always do this after an update to the table • Clear NIT: click to remove all the tables that have been inserted before. TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 12 of 18... -
Page 13: Add, Set, Edit The Nit Table
Inherited LCN: logical channel User set Enter the logical channel number. The LCN can be added more than one by re-clicking “Add” number option TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 13 of 18... -
Page 14: Ip Output Setting
Note: In this example if using VLC, set the VLC network stream to udp://@224.2.2.2:1234 and connect the stream from the DATA port – ensure your computers firewall is either disabled or accepting of the above port address TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com... -
Page 15: Modulator Setting
Use 2/3 RF Frequency User set Range is 30~1000MHz RF output level User set Range is -30~-10dBm Set RF Frequency to 550.500MHz for Australian compatibility. TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 15 of 18... -
Page 16: Utilities - Save/Restore
Cancels current settings and restores the last saved settings Factory Default Configuration Resets all settings to factory defaults. Backup Configuration Saves the current setup to a re-loadable file *Continued Below: TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 16 of 18... - Page 17 Firmware Update Update of existing firmware User Access Adjustment of login, password and security details Backup Configuration Saves the current setup to a re-loadable file TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 17 of 18...
-
Page 18: Reboot
Click to initiate a re-boot of the unit and the re-load of the most recently saved settings (see above) 4.8 Firmware This function is used to upgrade the device’s latest software program. Follow the instructions provided with the software updates. TeleDelta is proudly an Australian owned company. File: hds2800 rev 4 www.teledelta.com Page 18 of 18...
