1byone 203NA-0001 User Manual

www.1byone.com
VHF & UHF COMBO TV ANTENNA
What's in the box?
Reflector x2 Clamp,Screw & Wingnut x2
User Manual x1 Folding Element Carrier x1
Antenna Specification
No. of Frequency
Elements Range
174-230MHz
4
470-862MHz

How to install?

D
Plastic
Jointing Part
E
VHF Dipole
VHF In
F
A. Unfold the VHF elements on the upper reflector (at the top side) until they're locked tight in the plastic support.
B. Joint the two reflectors with the metal clamps, screws & wingnuts.
C. Unfold the element carrier and then tighten the wingnut in the middle.
D. Attach the element carrier to the reflector by using the plastic jointing parts.
E. Use the coaxial cable to connect the F connector from the UHF dipole to the F connector marked "VHF IN" in the
middle of element carrier. Tigten the connectors and use the plastic covers to protect the connectors.
F. Mount the antenna to a pole as high as possible. Connect the coaxial cable from TV to the F connector marked "TO TV"
in the middle of element carrier. Turn the antenna towards the TV tower for best reception..
Bracket x1
Plastic Jointing Part x2
Antenna Beam Width
Gain H/V
10-14dB H60°
D
E
F
SKU: 203NA-0001
Weather-proof F Connector Cover x1
Front-Back
Impedance
Ratio
15-20dB 75Ω
A
B
C
1Byone Products Inc.
16" Coaxial Cable x1
Antenna
Length
800mm
Upper Reflector
Clamps , Screws & Wingnut
Element Carrier
