Luda Elektronik TrailerCam 5D Quick Manual

TECHNICAL SPECIFICATION
Camera (including antenna)
Operating frequency 2400 – 2483.5 MHz
Operation temperature – 20°C to + 60°C
IP classifi cation camera IP66
Minimum illumination 0 Lux
Night vision range 5 m
Angle of view 120°
Power supply camera 12 V – 32 V
Power consumption camera 4.5 W
Size (W x H x D) 10 cm x 8 cm x 9 cm
Weight 397 g
Monitor (including antenna)
Operating frequency 2400 – 2483.5 MHz
Operation temperature – 10°C to + 60°C
Monitor brightness 400 cd/m
2
Monitor resolution 800 x 480
Power supply monitor 6 V–32 V
Power consumption monitor 5.3 W
Size (W x H x D) 15 cm x 9 cm x 5.5 cm
Weight 176 g
LUDA Elektronik AB, Aschebergsgatan 46, 411 33 Gothenburg/Sweden
EXTRA CAMERA
12V–32V
+
–
1
Choose channel
2
PAIR/CH >1s
Pair
PAIR <1s
3
PAIR
MIR
PAIR/CH >3s
CH 1 CH 2 CH 3 CH 4
Available at your local dealer
FAQ
1. Is the signal between the camera and the receiver encrypted?
Yes.
2. How many cameras does the system support?
4 cameras.
3. Why does the frame rate sometimes drop when I am driving?
When driving the signal reception might drop sometimes. This occurs as
the signal to the receiver is constantly transmitted from diff erent angles.
This is considered normal when transmitting wirelessly.
4. Is the camera water resistant?
The trailerCam 5D camera is IP66 classed. This means that the camera is
well protected from both dust and humidity. It can be placed outside
and can be cleaned using a pressure washer.
6. Can I hear sound from the camera?
No, the camera does not have a microphone.
7. I am using the camera for reversing, how do I mirror the image?
Please see the instructions in the "Operation" section.
8. What do I do if I have bad reception on the LCD-monitor?
Start by reading through the troubleshooting.
If troubleshooting doesn't help, visit www.ludamanuals.com or
www.ludaelektronik.com.
9. Will the camera break at very low temperatures?
No, at very low temperatures the picture might tone into red.
At extremely low temperatures the camera might turn off . However, when
the temperature gets higher again the camera will regain its functionality.
12. Further questions?
You are always welcome to visit our website www.ludaelektronik.com
or contact your local sales representative.
DA/DE/ES/FI/FR/IT/NO/NL/PL/SV www.ludamanuals.com
QUICK GUIDE
For more detailed information
www.ludamanuals.com
