- Page 1 INPUT MODULE MANUAL PART NUMBER: 400-0113-001 PRODUCT REVISION: 0 ISV30000 1-IN, 1-OUT INTERA COMPOSITE VIDEO + AUDIO INPUT MODULE USER’S GUIDE...
-
Page 2: Table Of Contents
APPLICATION DIAGRAM........6 INSTALLING YOUR INPUT MODULE ....6 OPERATION............8 ACCESSORIES ............8 FREQUENTLY ASKED QUESTIONS ....9 TROUBLESHOOTING GUIDE......9 ALTINEX POLICY..........10 LIMITED WARRANTY ........10 RETURN POLICY..........10 CONTACT INFORMATION ......10... -
Page 3: Precautions / Safety Warnings
• interference when the equipment is operated Qualified ALTINEX service personnel, or their in a commercial environment. This equipment authorized representatives must perform all generates, uses, and can radiate radio service. frequency energy and, if not installed and used 1.2 INSTALLATION... -
Page 4: About Your Input Module
INPUT MODULE ABOUT YOUR INPUT MODULE MECHANICAL ISV3000 Depth (inches) 4.1 in. (105mm) The ISV3000 is a 1-in 1-out composite video input Width (inches) 1.5 in (39mm) module with stereo audio input designed for Height (inches) 2.1 in. (54mm) installation into a wall. The ISV3000 provides Weight (pounds) 1 lb. -
Page 5: Product Description
INPUT MODULE PRODUCT DESCRIPTION... -
Page 6: Video Input
ISV3000. The ISV3000 allows a connection to Table 5. 5-pin Male terminal block for audio output different types of projectors or monitors using ALTINEX cables. 4.3 POWER INPUT CONNECTOR The ISV3000 Input Module has a 2-pin terminal OUTPUT SIGNAL ON 2-PIN PIN No. -
Page 7: Installing Your Input Module
INPUT MODULE INSTALLING YOUR INPUT MODULE Step 1. Video Signal Cable Preparation Trim the coaxial cables as shown: Figure 2: The installed video cable is shown on the right side. Figure 1: Cable Preparation Step 3. Audio and Power Signal Cable Preparation Note that the coaxial cable’s braided shield is twisted into a single conductor with multiple... - Page 8 INPUT MODULE cable clamp and the terminals such that there is no Step 5. Installation Test tension in the cables. Tighten the cable clamp to To perform this test, a 9VDC 500mA power supply provide strain relief. is needed, as well as a video and audio source such as a computer with a sound card.
-
Page 9: Operation
INPUT MODULE Apply 9VDC power to the ISV3000. The LED ACCESSORIES should turn red, indicating power but no incoming Model No. Description video signal. WALL PLATES FOR INTERA SYSTEM Connect an active video source to the front of the IS10001-W/I 1-Gang Wall Plate ISV3000. -
Page 10: Frequently Asked Questions
1.5V. 6 feet, VGA Male to Male CB3706MR • Please use the ALTINEX provided external AC 15 feet, VGA Male to Male CB3715MR adapter, which supplies 9V DC at 500mA. VGA + AUDIO INPUT CABLES •... -
Page 11: Altinex Policy
11.2 RETURN POLICY It is very important to ALTINEX that you receive the products that you have ordered and that this product meets your expectations. In the unlikely event, that an ALTINEX product needs to be...
