VTech VM306 User Manual

What's in the box
User's manual
(Canada version)
VM306
Accessory baby unit
for use with VTech model
VM341-216 / VM346 / VM346-2
Connect the baby unit
NOTES
• Use only the power adapter supplied with this
product.
• Make sure the electrical outlet is not controlled
by a wall switch.
• The power adapter is intended to be correctly
Congratulations
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place
on purchasing your new VTech product.
if they are plugged into a ceiling, under-the-table
Before using this product, please read or cabinet outlet.
• Make sure the baby unit and the power adapter
Important safety instructions.
cord are out of reach of children.
This manual has instructions on how to set
up and pair your new baby unit. For complete
instructions on using the baby unit, see the
user's manual that comes with your video and
audio monitor.
For support, shopping, and everything new at
VTech, visit our website at
www.vtechcanada.com.
1 Infrared LEDs
Overview
Light sensor
2
3 Camera
4 ON/OFF light
• On when the baby unit is turned on
and is paired to the parent unit.
• Flashes when the baby unit is not
being viewed; or when the link to the
parent unit is lost.
/ VOL /
5
• Press to adjust the baby unit
speaker volume. It determines the
lullaby volume and talkback volume
transmitted from the parent unit.
6 Play/Stop
• Press to play or stop lullaby on the
baby unit.
7 Microphone
8 Skip
• Press to play the next lullaby.
9 ON/OFF switch
• Slide to turn on or off the baby unit.
10 Speaker
11 Temperature sensor
12 PAIR
• Press and hold to pair to the parent
unit.
13 Threaded socket
• For wall mount installation use.
14 Power jack
Positioning the baby monitor
Before use
CAUTION
Pair new baby unit • Keep the baby units out of the reach of your baby.
Never place or mount the baby units inside the
Each newly purchased baby unit (VM306) baby's crib or playpen.
must be paired to your video and audio
NOTE
monitor system (VM341-216 / VM346 /
• To avoid interference from other electronic
VM346-2).
devices, place your baby monitor far away from
devices such as wireless routers, microwaves, cell
NOTES
phones and computers.
• You can pair a maximum of four baby units to
your parent unit. Each new baby unit must be
1. Place the baby units more than 1 meter
paired to the parent unit before use.
(3 feet) away from your baby.
• Make sure you power on the parent unit before
pairing. >
1m (3ft)
1. Press MENU when the parent unit is idle.
2. Press or to choose Pair/Unpair CAM,
then press SELECT.
3. Press SELECT again to choose Pair CAM.
4. Press or to choose an empty baby unit
slot, then press SELECT.
The parent unit screen displays Press
5.
2. Adjust the angle of the baby unit camera to
and hold the pair button at the CAM
aim at your baby.
for 5 seconds until the power indicator
flashes.. Immediately press and hold
PAIR on the bottom of the baby unit with
a narrow pointed object such as a pencil.
The LED light flashes quickly.
When pairing is successful, the screen
displays the view of newly paired baby unit in
SINGLE-CAM mode. The LED light on the
3. Place the parent unit more than 1 meter
new baby unit remains on.
(3 feet) away from the baby units.
NOTES
• If pairing fails, the screen displays Pairing failed. > 1m (3ft) >
1m (3ft)
Try the pairing process again.
• Only one baby unit can be paired at a time.
< 1m (3ft)
<
1m (3ft)
CAUTION
• The default volume of your parent unit is level 4.
If you experience high-pitched screeching noise
from your baby monitor while positioning:
- Make sure your baby units and parent unit are
more than 1 meter (3 feet) apart, OR
- Turn down the volume of your parent unit.
Mount the baby monitor (optional)
-OR-
Insert the screws into the holes and tighten
NOTE the screws until only 1/4 inch of the screws
are exposed.
• Check for reception strength and camera angle
before drilling the holes.
Place the baby unit on the wall mount
bracket. Tighten the screw into the threaded
1. Place the wall mount bracket on a wall and
socket at the bottom to secure the baby unit.
then use a pencil to mark the top and the
Align the holes on the wall mount bracket
bottom holes as shown. Remove the wall
with the screws on the wall, and slide the wall
mount bracket and drill two holes in the wall
mount bracket down until it locks into place.
(7/32 inch drill bit).
4. The default angle of the wall mount bracket
2. If you drill the holes into a stud, go to step 3.
is 90 degrees. You can maximize your
-OR-
baby unit's viewing angles by tilting the
If you drill the holes into an object other than
wall mount bracket.
a stud, insert the wall anchors into the holes.
Hold the baby unit, and then rotate the
Tap gently on the ends with a hammer until
knob in anticlockwise direction. This will
the wall anchors are flush with the wall.
loosen the joint of the wall mount bracket.
Tilt your baby unit up or down to adjust to
your preferred angle. Then, rotate the knob
in clockwise direction to tighten the joint
and secure the angle.
3. Align the wall mount bracket and screws
with the holes in the wall as shown. Tighten
the screw in the middle hole first, so that
the wall mount bracket position is fixed. You
can tighten the other screw in the top hole.
Operating range
Place the baby unit on the wall mount
bracket. Tighten the screw into the threaded
The operating range of the baby monitor is up to
socket at the bottom to secure the baby unit.
300 meters (1,000 feet) outdoors or 50 meters
(160 feet) indoors. The actual operating range
may vary depending on the environmental
conditions and other interferences such as
walls, doors and other obstructions.
Unpair a baby unit
NOTE
Make sure you power on the baby unit and the
parent unit before unpairing the baby unit.
1. Press MENU when the parent unit is idle.
2. Press or to choose Pair/Unpair CAM,
then press SELECT.
3. Press or to choose Unpair CAM, then
press SELECT.
4. Press or to choose a desired baby
unit, then press SELECT.
5. The screen displays To unpair CAM X,
press the [ZOOM] key at the Parent
Unit.. Press on the parent unit.
6. The screen displays Then, press the
[MENU/SELECT] key to confirm.. Press
SELECT to continue.
7. When unpairing is successful, the screen
displays CAM X is unpaired and returns
to previous menu. If there is no paired
baby unit, the screen displays No CAM is
paired..The LED light on the selected baby
unit flashes slowly.
General product care
To keep this product working well and looking good,
follow these guidelines:
• Avoid putting it near heating appliances and
devices that generate electrical noise (for
example, motors or fluorescent lamps).
• DO NOT expose it to direct sunlight or moisture.
• Avoid dropping the product or treating it roughly.
• Clean with a soft cloth.
• DO NOT immerse the baby unit in water and do
not clean them under the tap.
• DO NOT use cleaning spray or liquid cleaners.
• Make sure the baby unit is dry before you connect
them to the mains again.
