CoCo ICS-1000 Quick Installation Manual

Internet control station
Hide thumbs Also See for ICS-1000:

Advertisement

Quick Links

Download this manual
EN
Quick installation guide
Quick installation guide
Internet Control Station
ICS-1000
ICS-1000

Advertisement

loading
Need help?

Need help?

Do you have a question about the ICS-1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CoCo ICS-1000

Summary of Contents for CoCo ICS-1000

  • Page 1 Internet Control Station Quick installation guide Quick installation guide ICS-1000 ICS-1000...

  • Page 2: Package Contents

    PACKAGE CONTENTS First, please check if the package contains the following items: 1. Internet Control Station 2. RJ-45 cable 3. Power adapter 4. Quick installation guide www.coco-technology.com NOTE: Visit frequently to check if updates are available...
  • Page 3 4. Use the ‘COCO control’ app to register your smartphone/tablet with the Internet Control Station 5. Create at least 1 room in the ‘COCO control’ app and add a lamp or device to this room 6. Assign the transmission code for that lamp/device to the relevant COCO...
  • Page 4 1. CONNECT THE INTERNET CONTROL STATION TO YOUR MODEM/ROUTER 1. First, connect the Internet Control Station to the modem/router using the RJ-45 cable. 2. Then, connect the power adapter to the Internet Control Station and insert the plug of the power adapter into a wall socket.
  • Page 5 2. INSTALL THE ‘COCO CONTROL’ APP ON YOUR SMARTPHONE OR TABLET iPhone/iPad: In the App Store, search for “COCO control“ and download this free app. Android: In Google Play, search for “COCO control“ and download this free app.
  • Page 6 A new page will appear automatically. On this page you can configure various things. If you prefer to use the ‘COCO control’ app on your iPhone, iPad or Android smartphone/tablet, you don’t need to configure anything on this page.
  • Page 7 4. REGISTER YOUR SMARTPHONE/TABLET WITH THE INTERNET CONTROL STATION Step 1: Start the ‘COCO control’ app. Step 2: Click on “Settings“. Step 3: Click on “Edit comms and security details”...
  • Page 8 REGISTER YOUR SMARTPHONE/TABLET (continued) Step 4: Enter the e-mail address and Step 5: Click on “Settings“. Step 6: Click on “Set up internet the PIN code of the account control“. that you have created on www.coco-technology.com...
  • Page 9 Step 7: Enter the MAC address Step 8: A new 4-digit code will Step 9: Enter this 4-digit code at the (located on the bottom of your appear on the display of your bottom of the screen. Internet Control Station) and click on Internet Control Station.
  • Page 10 REGISTER YOUR SMARTPHONE/TABLET (continued) Step 10: If both codes are correct, Step 11: Click on “Room 1“. Step 12: Then click on a device, for this screen will appear. example “Device 1“. Then click on “Home“.
  • Page 11 Step 13: Click on “On“. Step 14: A question will appear on Step 15: “Registered OK“ will the display of your Internet Control appear on the display of your Station. Press the green button in the Internet Control Station. bottom right corner.
  • Page 12 5. CREATE A ROOM AND A DEVICE Step 1: Select “Room 1”. Step 2: Rename “Room 1” Step 3: Select “Living room”. (for example: “Living room“) and click OK.
  • Page 13 Step 4: Select “Device 1”. Step 5: Rename “Device 1” Step 6: Select the correct receiver (for example: “Sofa lights“) type (for example: “Dimmer”) and click OK. and click on “Save settings“.
  • Page 14 6. ASSIGN TRANSMISSION CODE TO RECEIVER Refer to the manual of the specific COCO receiver to activate the 1 sec. ‘learn mode’ of the receiver (in most cases, you can press a little button on the receiver for 1 second).

  • Page 15: Wireless Control

    WIRELESS CONTROL If you have performed all previous steps, you can now control a lamp or device wirelessly with the Internet Control Station. Select a lamp or device in a room that you have configured, for example “Sofa lights“ in “Living room”.
  • Page 16 WIRELESS CONTROL (continued) If you want to set a different dim If you set the receiver type to “On/off For electric shades/screens, value, select “More“. switch“, these commands will appear. these commands will appear.
  • Page 17 AUTOMATION: SEQUENCES In the “Automation” screen you can create sequences (and timers). A sequence is a collection of up to 10 commands, that are executed sequentially. With just 1 touch of a button, you can simultaneously dim 2 lamps near the sofa 25%, switch on ceiling spots, close electric screens, etc.
  • Page 18 AUTOMATION: SEQUENCES (continued) First click on “Learn a new sequence“. Enter a name for the new sequence, Follow the instructions on the screen. for example “Watch movie”. After you click on “OK”, every command you choose will be added to the sequence.
  • Page 19 1. First select a room, 2. Then select a device, 3. Select a command, for example: “Living room”. for example: “Sofa lights“. for example “dim 25%”.
  • Page 20 AUTOMATION: SEQUENCES (continued) 4. Read the message. To add a second 5. If needed, go to “Home” 6. In the room you have selected, step to the sequence, click “OK“. and select a (different) room. click on a device. For example: “Ceiling spots”.
  • Page 21 7. Select a command, 8. Repeat steps 4 to 7 to add more 9. When you have added all steps, for example: “On”. steps (max. 10 steps per sequence). click on “Automation“ to return to Then click on “OK“. that screen.
  • Page 22 AUTOMATION: SEQUENCES (continued) You can add up to 10 sequences to “My Sequences”. You can activate these sequences by clicking on the name of the sequence. Each sequence is performed as a series of steps. By default, there is no delay between these steps.
  • Page 23 AUTOMATION: TIMERS 1. In the “Automation” screen, 2. In the “Timers” screen, you can 3. Select the sequence that you want click on “Make a new timer“. configure all timer settings for a program, for example: “Watch movie“. sequence. Click on the first blue arrow.
  • Page 24 AUTOMATION: TIMERS (continued) 4. Then click on the second blue 5. Select a time and click on 6. Click on the third blue arrow to set arrow to set the start time. “Confirm”. Besides a fixed time, you the repetition. can also set a time based on “Dawn”...
  • Page 25 7. In this screen, you can choose if the 8. Select the days on which the 9. Depending on the first three timer should be performed only once or sequence should be performed. settings, you can also set a start repeatingly.
  • Page 26 AUTOMATION: TIMERS (continued) 10..and/or end date. 11. If you do not want to set an end 12. If all settings are correct, click on date, click on “Continue until I cancel “Save this timer“. manually“.
  • Page 27 QUICKTIMERS A “QuickTimer“ can be used to automatically perform a command for a specific lamp or device at a specific date and time. For example, you can program a QuickTimer today, to switch on a lamp at 7 AM tomorrow morning.
  • Page 28 QUICKTIMERS (continued) Learning QuickTimer 2. First click on “QuickTimer“, 3. Select the device that you want to 4. Choose a command, for example: then click on “Set QuickTimer now“. program. “On“.
  • Page 29 SETTINGS In the bottom right corner, you can find the “Settings“ icon. When you click on this icon, a screen will appear. Via this screen, you can: • Quickly edit rooms and devices • Configure your account, location and time zone •...
  • Page 30 SETTINGS: ROOMS AND DEVICES Click on the red bar to change the This screen will appear when you This screen will appear when you name of the room or click on 1 of the want to change the name of the want to change the name and/or type blue arrows to change the name and/ room.
  • Page 31 SETTINGS: COMMS AND SECURITY Click on “Edit comms and security Example of the screen to set your Enter your e-mail address details“ location. and/or PIN code here. Edit your location and/or time zone here.
  • Page 32 SETTINGS: ECOMETER First click on “Settings”, then select In this screen you can enter the kWh To monitor the current “Edit comms and security details“ and cost (in Euro cent) for the EcoMeter. electricity usage, click click on “Electricity cost“. Then click on “OK”.
  • Page 33 SETTINGS: SETUP INTERNET CONNECTION Click on “Set up internet control“. Enter the MAC address that you can If the MAC code and PIN code are find on the bottom of your correct, this screen will appear. Internet Control Station. Then enter your PIN code.
  • Page 34 SETTINGS: DOWNLOAD/UPLOAD BACKUP We advise you to create an online backup of your configuration, in order to restore it if needed. The following pictures explain how to create a backup, by uploading your database to the web. At any moment, you can download this database using the button “Download database from Web”.
  • Page 35 SETTINGS: RESET DATABASE If you want to erase the database, click In this screen, you can confirm that on “Settings” first, then click on “Reset you want to reset the database by ICS-1000 database”. clicking on “OK”.
  • Page 36 WIFI/3G To erase all settings, Here, you can erase all settings by Go to “Home“ and click on the COCO go to “Home” first, then click on the clicking on the “Reset” button. logo. A screen will appear in which “info“...

  • Page 37: Wireless Signal

    UPDATES & SUPPORT Frequently check www.coco-technology.com for hardware and software updates. If you prefer to be informed automatically, sign up for our newsletter. You can enter your e-mail address at the bottom of our website (www.coco-technology.com).
  • Page 38 LIFE-SUPPORT CLEANING Never use COCO products for life-support systems or Use a dry cloth to clean this product. Do not use harsh other applications in which equipment malfunctions chemicals, cleaning solvents, or strong detergents.

  • Page 39: Warranty And Copyright

    • For warranty issues, go back to the store where you have purchased this product. The defective product must be accompanied by the original purchase receipt. Copyright Without prior written permission, reproducing or copying is prohibited. Information in this document is subject to change without prior notice. Check www.coco-technology.com for updates.

  • Page 40: Declaration Of Conformity

    DECLARATION OF CONFORMITY COCO International BV declares that the COCO product: model ICS-1000 INTERNET CONTROL STATION (item number 71080) is in compliance with the essential requirements and other relevant provisions of the following directives: EMC Directive (2004/108/EC), Low Voltage Directive (2006/95/EC), R&TTE Directive (1999/5/EC).
  • Page 41 PACKAGE CONTENTS CHECKLIST COMPLETE INSTALLATION CONNECT THE INTERNET CONTROL STATION TO YOUR MODEM/ROUTER INSTALL THE ‘COCO CONTROL’ APP ON YOUR SMARTPHONE OR TABLET CREATE AN ACCOUNT REGISTER YOUR SMARTPHONE/TABLET WITH THE INTERNET CONTROL STATION CREATE A ROOM AND A DEVICE...
