Foxcon Terrier T200 LSA Flight Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Terrier T200 LSA Flight Manual Rev No.: 1.0 15 April 2008
FOXCON
Aviation & Research Pty Ltd
291 Gormley's Road Seaforth Mackay QLD 4741
Ph/Fax: 07 4959 0252 Mobile: 0418 747 751
Aviation@Foxcon.com
Flight Manual
Terrier T200 LSA
Aircraft Registration
Number:
Aircraft Serial Number:
Power plant:
Power plant Serial No:
Propeller:
Date of First Flight:
Current Owner:
Address:
Empty Weight
323kg
NOTE: Please keep all the above information current, and notify Foxcon Aviation &
Research Pty Ltd of any changes in ownership, address, or aircraft equipment and/or
You are reminded that as part of the LSA certification, any modifications to the aircraft,
including any change in the instrument or engine package supplied from the factory,
has to be approved by Foxcon Aviation & Research Pty Ltd.
www.Foxcon.com
21-5161
#040701
Subaru EA-81
544848
Bolly BOS3
05.03.08
Moment
698.26
modifications.
Date Weighed
25.02.08
Page 1 of 31
