Summary of Contents for Mountz RETW
- Page 1 R E T W R E T W Electronic Click Wrench Operating Instructions Mountz, Inc ISO 9001 (2000) company Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733 www.etorque.com...
- Page 2 RETW Operation instructions Page 1 1” Thick Wall Chrome Plated Tubing Impact Resistant Nylon 6 housing Heavy duty small Large Easy-to- ARC ratchet read LCD display Audible buzzer for RS-232 Output when pre-set torque Computer/Printer/Data Logger is achieved 3 units of measurement...
- Page 3 RETW Operation instructions Page 2 Press & hold to decrease View/Change the Pre-set Torque Value: pre-set torque. 1. Press either target key once to see the current target value without making any changes. The target will show for 3 seconds.
- Page 4 RETW Operation instructions Page 3 Press & hold to Power Clear Changing Tolerance Settings: button with the wrench on 1. The default setting is +/- 2% of pre-set torque. The operator can adjust the the setting from 1 - 10% or turn it off.
- Page 5 RETW Operation instructions Page 4 Press the Power button to turn Manual Off: off wrench. 1. To manually turn off the wrench, hold the Power button for 3 seconds. Accessories Item # 260114 Model: RS-232 and Rechargeable Battery Adapter Kit...
- Page 6 RETW Operation instructions Page 5 Recharging Batteries (internal NimH batteries): 1. Plug the RS232/Power cable in the back of the wrench. 2. Plug the RS232 adapter into the other end of the Data/Power cable. 3. Plug the transformer into the back of the Rs232/Power adapter.
- Page 7 Mexico Service Center Mountz Mexico SA de CV Chihuahua For calibration, re-adjustment or repairs, please send the tool to Av. Cristobal Colon #15343 one of our 3 service locations.
