Summary of Contents for Quick-Garden Benington
- Page 1 PRODUCT NAME BENINGTON REFERENCE NUMBER...
- Page 3 IMPORTANT (Read carefully before starting)! - The following instructions include both pictures (indicating every part by the digits – see part list above) and illustrations. Please keep in mind that the illustrations are just a general guide to assembling all our products (For example: The illustration on how to assemble a roof applies to all our roofs).
- Page 4 Before starting to assemble your structure, we strongly recommend that you watch our video guide on our website www.quick-garden.co.uk (under the category “Assembly”). During the installation process constantly check that everything is level and parallel. For all parts that need to be assembled using screws, it is advisable to pre-drill holes to avoid the risk of splitting the wood during screwing.
- Page 5 The actual plan of the bearers: 4.4. Assembling the walls: place the wall-boards on the bearers as shown in a sample below:...
- Page 6 The wall-boards must be placed so that the ends interlock. Now screw the first row of wall-boards into the bearers. All the following rows of placed wall-boards should interlock not only at the ends, but along their length as well. Please screw each new row of wall-boards into the former row to ensure a solid structure.
- Page 9 4.5. Roof frame triangles: After the walls are assembled, mount the roof frame triangles. These should be mounted as whole structures. 4.6. Rafters: The rafters must be mounted horizontally and inserted in the mounting-spaces found on the roof frame triangles. The rafters share a common mounting-space in the middle one of the three triangles.
- Page 10 4.8. Wind-boards: Place the wind-boards on top of each other to make a 90 degree angle. Now attach these ones on a roof frame triangle and fix with screws.
- Page 11 4.9. Double door: Assemble the door frame fixing it with screws: Screw the support trims in to the door frame: Then insert door frame in to its space from the outside of the structure and attach the rest of the support trims from inside the structure.
- Page 12 Notice: - Keep in mind that the support trims must be screwed to the door frames, not to the wall-boards! - Do not worry about the space between the wall and upper window frame. The wood will naturally contract so that the space should disappear within a month or so.
- Page 13 4.10. Single door: Assemble the door frame fixing it with screws: Screw the support trims in to the door frame and insert door frame in to its space from the outside of the structure. Then fix the rest of the support trims from inside the building:...
- Page 14 4.11. Windows: The windows must be installed in the same way as the door:...
- Page 15 4.12. Floor: Place the floor-boards across the bearers and screw them in at an angle. In this way you will have a screw-free clear floor. After the floor-boards are mounted, screw the floor-boards decorative trims in to the floor-boards. 4.13. Felt roof shingles: When the whole structure is assembled and has been treated, attach the felt roof shingles to the roof-boards as shown in the picture.
- Page 16 Our After Sales Service will replace defective or missing parts. Make sure you fill in the After-sales service form correctly. After-sale service line + 44 207 097 0013 clients@quick-garden.co.uk See the terms and conditions of Quick-Garden at www.quick-garden.co.uk/general-conditions Assembly notice – keep for later reference. We hope you enjoy your purchase.
