FACTORY ID: 001
CONSUMER: READ AND SAVE THESE INSTRUCTIONS
GENERAL HAZARD WARNING:
DANGER
READ AND UNDERSTAND ALL OF THE INSTRUCTIONS IN THIS MANUAL
BEFORE ASSEMBLING, STARTING, OR SERVICING THE HEATER. Be sure to comply with the
instructions and warnings provided with this heater. Failure to comply can result in fire or explosion
that can cause property loss, bodily injury, or loss of life. Only persons who can follow and
understand these instructions should operate or service this heater.
NOT FOR USE IN RESIDENTIAL LIVING AREAS OR IN ENCLOSED SPACES
DANGER
WITHOUT ADEQUATE VENTILATION. INDOOR USE PERMITTED ONLY FOR
THE TEMPORARY HEATING OF BUILDINGS OR STRUCTURES UNDER CONSTRUCTION,
ALTERATION OR REPAIR. This is an unvented portable heater that uses air (Oxygen) from within
the area in which it is used. Failure to provide adequate combustion and ventilation air will result in
asphyxiation, carbon monoxide poisoning, bodily injury or death. Refer to "Ventilation" on Page 7.
This appliance shall be installed in accordance with the rules in force,
WARNING
and used only in sufficiently ventilated space. Consult instructions before
installation and use of this appliance.
Model Numbers
FF 45 / FF 70 / FF 125 /
FF 175 / FF 215
© 2017 Lavorwash Australia Pty Ltd
7/76 Rushdale Street, Knoxfield, Vic. 3180
User's Manual &
Operating Instructions
LWKA-400
Advertisement
Table of Contents
Related Manuals for LavorPro FF 45
Summary of Contents for LavorPro FF 45
- Page 1 User’s Manual & Operating Instructions Model Numbers FF 45 / FF 70 / FF 125 / FF 175 / FF 215 FACTORY ID: 001 CONSUMER: READ AND SAVE THESE INSTRUCTIONS GENERAL HAZARD WARNING: DANGER READ AND UNDERSTAND ALL OF THE INSTRUCTIONS IN THIS MANUAL BEFORE ASSEMBLING, STARTING, OR SERVICING THE HEATER.
-
Page 2: Table Of Contents
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Table Of Contents Safety Information..........1-2 Maintenance............9-11 Features and Specifications.........3 Wiring Diagram...........11 FF 45 and FF 70 Assembly........4 Troubleshooting Guide........12 125/ 175 / FF 215 Assembly......5-6 Exploded View...........13 Operation............7-6 Parts List............14 Ventilation.............7 Safety Information FIRE, BURN, INHALATION AND EXPLOSION HAZARD. -
Page 3: Safety Information
COMBUSTIBLES AWAY FROM HEATER. serviced and check for proper ventilation. Some people are more affected by carbon monoxide Minimum Clearance From Combustibles than others. These include: pregnant women, FF 45 FF 70 FF 125 FF 175 FF 215 those with heart or lung problems, anemia or those 1.2 m... - Page 4 230VAC / 50Hz 230VAC / 50Hz 230VAC / 50Hz 230VAC / 50Hz 230VAC / 50Hz Phase Single Single Single Single Single Specifications subject to change without notice. Features Models: FF 45 / FF 70 Upper Shell Hot Air Outlet Extension Handle Cord Wrap Lower Shell Fan Guard Side Cover...
-
Page 5: Insert Screws And Tighten Firmly
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Assembly Instructions Models: FF 45 / FF 70 Note: Save the box and packaging materials - Remove the heater and all packaging materials from the shipping carton for future storage. - Page 6 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Assembly Instructions Models: FF 125 / FF 175 / FF 215 Remove the heater and all packaging Tools Needed: materials from the shipping carton. - Phillips Head Screw Driver - 8 mm open end wrench Tip: Be sure to remove the axle from the - 19 mm open end wrench...
-
Page 7: Figure 5
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Assembly Instructions Models: FF 125 / FF 175 / FF 215 1. Insert axle through holes in wheel support. 10. Secure the rear handle with (2) short screws (30 mm) and (2) nuts and tighten firmly 2. -
Page 8: Operation
NEVER FILL THE FUEL TANK CAUTION INDOORS. ALWAYS FILL THE TANK OUTDOORS. BE SURE THAT Minimum Ventilation Opening Needed THE HEATER IS ON LEVEL GROUND WHEN FF 45 FF 70 FF 125 FF 175 FF 215 FUELING, AND NEVER OVERFILL THE TANK. - Page 9 NOTE: If if the heater still does not ignite, refer to “Troubleshooting Guide” on page 12. “Troubleshooting Guide” on page 12. NOTE: The FF 45 and FF 70 do not have a room temperature display feature. The room temperature display will indicate the TIP: If the heater does not ignite;...
-
Page 10: Maintenance
Long Term Storage: Service: Never service heater while it is WARNING Models FF 45 / FF 70: plugged in or hot! 1. Use an approved siphon to drain fuel through the fuel cap opening. DO NOT TAMPER WITH THE UNIT. HAVE... -
Page 11: Figure 15
Photocell NOTE: To remove the filter from models Photocell lens FF 45 / FF 70 turn filter 90º clockwise. To remove the filter from models 125 / 175 / FF 215 turn filter 90º counter-clockwise. See Figure 15. -
Page 12: Wiring Diagram
Models 125 / 175 / FF 215 have a GREEN digital display. WHITE EARTH EARTH WHITE Figure 20: FF 45 Figure 21: FF 70 / FF 125 / FF 175 / FF 215 © 2017, Lavorwash Kerosene Forced Air Heater User’s Manual... -
Page 13: Troubleshooting Guide
NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE Troubleshooting Guide Problem Possible Cause Solution Heater Ignites, but main PCB shuts 1. Incorrect pump pressure. 1. Adjust pump pressure. off after a short period of time. 2. -
Page 14: Exploded View
WHILE CONNECTED TO A POWER SOURCE Exploded View 48** 49** 55** 5 35 52** 51** *FF 45 / FF 70 Only 53** **FF 125 / FF 175 / FF 215 Only © 2017, Lavorwash Kerosene Forced Air Heater User’s Manual... -
Page 15: Parts List
ALWAYS contact the manufacturer of this heater before replacing any parts WARNING other than those specified or recommended in the servicing instructions. Item Part Number for Models: Description FF 45 FF 70 FF 125 FF 175 FF 215 Fuel Tank Assembly... - Page 16 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________...
