- Page 1 IP Camera Installation and Setup Guide XL PLUS NVR MODELS Watcherproducts.com ♦ Watcher Products ♦ 877-289-2824...
- Page 2 This guide will help to layout and install IP cameras to a new XL PLUS NVR System or to simply add more cameras to an already existing system. Connecting a camera for the first time should be done with a short cable and with the camera unmounted where it is easy to diagnose any issues.
- Page 3 Initial Installation By now the XL PLUS System should be running with just your monitor, keyboard, mouse, and possibly an internet connection. All connections should use CAT5e or CAT6 cabling. The following steps will get us going. 1. Connect a PoE Switch to a Network Adapter on the XL PLUS 2.
- Page 4 In the main screen under the device list you should see this running man ( ) when motion is detected and ( ) when it is recording on schedule. If it is not recording there will be no icon next to the camera name. Watcherproducts.com ♦ Watcher Products ♦ 877-289-2824...
