- Page 1 LS 1 Product Manual English...
-
Page 2: Intended Use
“Improper use” means using the products other than as described in these instructions or under operating conditions which di er from those described herein. Detailed product manual for Light Storm can be found on the movie solution page on www.aputure.com . -
Page 3: Item Checklist
Item check list Before starting, please check that all the following items have been included with the Light Storm . If anything is missing, contact your dealer LS 1 immediately. Controller box Buckle （*Color temperature wheel only for LS 1c） Light Hook Button battery... -
Page 4: Controller Box
Nomenclature 1. Light Cable box Cooling ns Tilt knob NO.:6T001000 Barn door frame LED beads Barn door Hook U-frame Supporting Clamp Light tube handle label 2. Controller box Antennas (*The signal strength is the best Eyelet bar when pulling the antennas as Socket the picture's show.) Power switch... -
Page 5: Display Window
4. Display window Groups indicator Channels indicator DMX indicator Brightness percent indicator Color temperature indicator (*only for LS 1c) Channel setting button DMX model setting button DMX channel setting button(+) Group setting button DMX channel setting button(-) Installations 1. Install the hook 2. - Page 6 3. Insert the connect cable dot to dot to power the light . *Tie the connect cable around the hook 4. Power the controller box 1) Powered by the adapter Locking spring AC 100V-240V Locking slot * Please pull the power adapter out by pushing the locking spring down on the controller box.
- Page 7 2) Powered by the battery V-Mount Battery Anton Bauer Battery * Battery output current ≥ 8A; * Please choose the model of the Light Storm by your battery need. 5. Clip the tracing paper by the clamps 6. Insert the button battery to power the controller.
- Page 8 Operations 1. Press power switch to turn on the Light Storm LS 1. *“Channel 1 ,Group A” is by default. *The brightness is 10% and the color temperature is 3200K (LS 1c) by default. 2. Manual controlled by the controller box 1) Brightness adjustment and display 2) Color temperature adjustment and display (*only for LS 1c)
- Page 9 *2) Group setting and display 2) The controller setting and display Press ( ) to set the channel 2 “ ” indicator lights The controller setting is nished. *The Light Storm has three channels (1/2/3) and four groups (A、B、C、D). 3) Brightness and color temperature adjustment Press ( ) of group C to adjust the brightness and ( ) of group C to adjust the...
- Page 10 4.The DMX control 1) Connect a standard DMX console OUTPUT DMX512 Only one Light Storm OUTPUT DMX512 One by one * See the interface de nition of the DMX as the picture shows: ground positive ground negative empty ground empty ground...
- Page 11 2) The DMX setting *1) Press DMX model setting button on the controller box to enter into the DMX model. *2) Press the DMX channel setting button (+/-) on the controller box to your needed DMX channel. 3) The standard DMX console control Control the Light Storm by the standard console within the same DMX channel setting as above.
-
Page 12: Specifications
Specifications LS 1c LS 1s Model Operation Current Power Supply DC 15V DC 15V Power Input 120W 120W Beam Angle 45° 25° Color Temperature 3200K-5500K 5500K ≥100,000 hours Average Life Span Cooling Mode Natural convection heat transfer Radio Frequency 2.4GHz Channels 1/2/3 Groups...
