Table of Contents
Summary of Contents for FISCHER EU05
-
Page 1: Operating Manual
Operating manual EU05 Transmitter PC Interface... - Page 2 Great care was taken when compiling the texts and illustrations; nevertheless, errors cannot be ruled out. The company FISCHER Mess- und Regeltechnik GmbH will not accept any legal responsibility or liability for this.
-
Page 3: Table Of Contents
FISCHER Mess- und Regeltechnik GmbH Table of Content Table of Content 1 Safety guidelines............................ 4 1.1 General.............................. 4 1.2 Personnel Qualification ........................... 4 1.3 Risks due to Non-Observance of Safety Instructions................ 4 1.4 Safety Instructions for the Operating Company and the Operator ............ 4 1.5 Unauthorised Modification........................ 4... -
Page 4: Safety Guidelines
1 | Safety guidelines FISCHER Mess- und Regeltechnik GmbH 1 Safety guidelines 1.1 General This operating manual contains instructions fundamental to the installation, op- WARNING eration and maintenance of the device that must be observed unconditionally. It must be read by the assembler, operator and the specialized personnel in charge of the instrument before it is installed and put into operation. -
Page 5: Safe Working Practices For Maintenance And Installation Work
FISCHER Mess- und Regeltechnik GmbH Safety guidelines | 1 1.7 Safe working practices for maintenance and installation work The safety instructions given in this operating manual, any nationally applicable regulations on accident prevention and any of the operating company's internal work, operating and safety guidelines must be observed. -
Page 6: Product And Functional Description
2 | Product and functional description FISCHER Mess- und Regeltechnik GmbH 2 Product and functional description 2.1 Delivery scope ▪ Transmitter PC Interface EU05 ▪ Programming cable ▪ USB cable ▪ Plug power supply unit ▪ CD ROM with PC software –... -
Page 7: Use As Intended
GmbH and a conventional PC. It is designed for use in industrial environ- ments. The following units from the company FISCHER Mess- und Regeltechnik GmbH can be connected to the EU05. The list is sorted according to unit type and required PC software. Units with LED displays and FernPara software... -
Page 8: Commissioning
Error Ready Charge Transmit Receive Programming cable USB cable EU05 System power cable In the following, the term 'transmitter' is used for all FISCHER units that can be connected to the EU05 for the intended purpose. 8 / 16 BA_EN_EU05_ST4-A... -
Page 9: Operation
Charge battery NOTICE If the EU05 is supplied via a power supply unit with a plug, the battery is charged. This is shown on the status LED 'Charge'. The charging process is also started, if the unit is not connected to other units. -
Page 10: Servicing
4 | Servicing FISCHER Mess- und Regeltechnik GmbH 4 Servicing 4.1 Maintenance The instrument is maintenance-free. We recommend the following regular in- spection to guarantee reliable operation and a long service life: ▪ Check the function in combination with downstream components. -
Page 11: Technical Data
FISCHER Mess- und Regeltechnik GmbH Technical data | 5 5 Technical data 5.1 Auxiliary energy The following data refers to the power supply via a power supply unit. However, power can be supplied via an USB interface. Rated Voltage 24 V AC/DC Admissible operating voltage U 12 …... -
Page 12: Construction Design
5 | Technical data FISCHER Mess- und Regeltechnik GmbH 5.4 Construction design Installation position User-defined Dimensions (W x L x H) 101 x 195 x 44 mm Weight approx. 450g Materials Housing 5.4.1 Dimensional drawings All dimensions in mm unless otherwise stated Type plate Illustration 2: Dimensional picture... -
Page 13: Order Codes
FISCHER Mess- und Regeltechnik GmbH Order Codes | 6 6 Order Codes Code no. Type ←code Without battery With battery 6.1 Accessories Order no. Description 06405132 Plug power supply unit 06411148 Programming cable (coupling / connector) 5-pin M12 04491089 USB 2.0 cable... -
Page 14: Attachments
7 | Attachments FISCHER Mess- und Regeltechnik GmbH 7 Attachments 7.1 EC Declarations of conformity EC Declaration of Conformity (Translation) For the product described as follows Transmitter PC Interface Product designation EUOS Type designation it is hereby declared that it corresponds with the basic requirements... - Page 15 FISCHER Mess- und Regeltechnik GmbH Attachments | 7 BA_EN_EU05_ST4-A 15 / 16...
- Page 16 7 | Attachments FISCHER Mess- und Regeltechnik GmbH 16 / 16 BA_EN_EU05_ST4-A...
