Summary of Contents for DriSteem DK-12
- Page 1 Read and save these instructions! DRANE-KOOLER Water tempering device Installation, operation and maintenance manual...
- Page 2 Corporate headquarters European office 14949 Technology Drive • Eden Prairie, MN 55344 Bell Place, Bell Lane • Syresham, Brackley • NNN13 5HP, UK 952-949-2415 • 800-328-4447 • 952-229-3200 (fax) +44 1280 850122 • +44 1280 850124 (fax) sales@dristeem.com (e-mail) 106277.1443@compuserv.com (e-mail)
-
Page 3: Table Of Contents
DRANE-KOOLER table of contents. Product overview Operation Features summary ............. 1 Start-up and operation instructions ......8 Capacities and connection sizes ........ 2 Dimensions ............... 3 Maintenance Maintenance instructions .......... 9 Warranty ..............12 Troubleshooting guide ..........10 Replacement parts ............ 11 Installation Installation instructions .......... -
Page 5: Product Overview
Product overview DRANE-KOOLER features summary. Cool discharged hot water Reliable, non-electric valve DRANE-KOOLER is a water tempering device that The temperature-actuated valve is time-tested to be mixes cold water with hot water discharged from reliable and maintenance-free. And because it is non- various types of equipment, such as a humidifier, to electric, no wiring is required! reduce the discharged water temperature before it... -
Page 6: Capacities And Connection Sizes
Product overview Capacities and connection sizes. DRANE-KOOLER capacities* DRANE-KOOLER connections Maximum flow Maximum l n i " 1 rate temperature l t u " 2 U.S. °F °C " 8 Hot water 22.7 inflow Cold water 22.7 inflow** Tempered 45.4 water outflow * This table applies only if one humidifier is connected to one DRANE-KOOLER, with no more than 10' ( 3 m) of... -
Page 7: Dimensions
Product overview DRANE-KOOLER dimensions. Floor OM-1113 Dimensions l n i " 1 l n i " 1 l n i l n i l t u l t u l n i Product overview: Dimensions... -
Page 8: Installation
Installation Installation checklist. Step-by-step installation instructions q Hot water inlet connection instructions: q Verify that maximum flow of hot water into the DRANE-KOOLER does not exceed 6 U.S. • Hot water inlet connection is 1" (DN25) NPT. gallons per minute (gpm) (22.7 L/m). •... -
Page 9: Mounting
Installation Mounting options. Three mounting options Suspension mount* Use one of the mounting options shown on this page to ensure that the DRANE-KOOLER will be properly supported and not secured entirely by piping. Floor stand and suspension mount hanger assembly are ordered separately. -
Page 10: Piping
Installation DRANE-KOOLER piping. Cold water supply piping: 3/8" (DN10) NPT Water pressure must be between 25 psi and 80 psi (172 kPa and 552 kPa). Connect directly to the main water supply line. TO ENSURE ADEQUATE WATER PRESSURE TO THE DRANE-KOOLER, DO NOT CONNECT TO A water SUPPLY WATER LINE... -
Page 11: Piping
Installation DRANE-KOOLER piping. Two examples showing the DRANE-KOOLER mounted directly underneath an evaporative humidifier Pitch drain piping at least 1/8"/ft (1%) in direction of arrows. DRANE-KOOLER OM-1121 Pitch drain piping at least 1/8"/ft (1%) in direction of arrows. DRANE-KOOLER OM-1122 Installation: Piping... -
Page 12: Operation
Operation DRANE-KOOLER operation. How to operate Once properly installed, to operate simply open the cold water supply valve. Principle of operation Vacuum breaker Temperature- actuated valve Sensor Capillary tube OM-1114-2 Hot water discharged from a humidifier or other 2. Cold water enters through the temperature- appliance enters the DRANE-KOOLER through actuated valve. -
Page 13: Maintenance Maintenance Instructions
Maintenance DRANE-KOOLER maintenance. Step-by-step maintenance instructions q If severe mineral accumulation has occurred, q Shut off cold water supply. remove the thermal sensor from the q Disconnect service unions at: DRANE-KOOLER chamber and gently clean the sensor with an abrasive pad. Do not twist the •... -
Page 14: Troubleshooting Guide
Maintenance Troubleshooting guide. Problem Possible cause Problem number Action Mineral accumulation in • Remove the DRANE-KOOLER and Water leaving the dislodge mineral accumulation. mixing chamber DRANE-KOOLER is hotter than 140 °F • Remove thermal sensor from Mineral accumulation (60 °C) on thermal sensor DRANE-KOOLER and gently remove mineral accumulation with an abrasive pad. -
Page 15: Replacement Parts
Maintenance DRANE-KOOLER replacement parts. OM-1119 DRANE-KOOLER Model DK-12 replacement parts " 4 " 4 " 4 " 8 " 4 " 2 i l e Maintenance: Replacement parts... -
Page 16: Warranty
14949 Technology Drive • Eden Prairie, MN 55344 Phone: (952) 949-2415 • Fax: (952) 229-3200 E-mail: sales@dristeem.com • Web: www.dristeem.com European Office: Bell Place, Bell Lane • Syresham, Brackley • NN13 5HP, U.K. Phone: +44 1280 850122 • Fax: +44 1280 850124 E-mail: 106277.1443@compuserve.com...
