KICKER AMP
INSTALLATION GUIDE
FOR USE WITH HARLEY DAVIDSON 1996-2013 FLHT
INCLUDED IN THIS FIT KIT:
> Step-by-step Installation Guide
> 5 1/4" OR 6 1/2" Kicker Speakers Pair
> Kicker Amp 100W/50W OR 200W
> Stainless Steel Mounting Bracket
> Custom Wiring Harness
&
SPEAKER
> All Necessary Hardware
- 8 - 32 x 1/2" Button Head Bolts
- 8 - 32 Nylock Nuts
- Black Heat Shrink
- Black Cable Tie
Advertisement
Table of Contents
Summary of Contents for KLOCK WERKS 4405
- Page 1 KICKER AMP & SPEAKER INSTALLATION GUIDE FOR USE WITH HARLEY DAVIDSON 1996-2013 FLHT INCLUDED IN THIS FIT KIT: > Step-by-step Installation Guide > All Necessary Hardware > 5 1/4” OR 6 1/2” Kicker Speakers Pair - 8 - 32 x 1/2” Button Head Bolts >...
- Page 2 KLOCK WERKS | FLHT KICKER AMP AND SPEAKER INSTALLATION GETTING STARTED IMPORTANT INSTALLATION NOTE: Over-tightening mounting fasteners may result 1. Protect all painted surfaces and passing lamps, if equipped, with a soft cloth in damage to your motorcycle. Please refer to 2. Remove seat and disconnect negative battery terminal (Picture 1) your service manual for proper procedures and torque specifications.
- Page 3 KLOCK WERKS | FLHT KICKER AMP AND SPEAKER INSTALLATION (CONTINUED) (amp installation continued from previous page) WIRE ROUTING 1. Take the electrical harness and plug it into the amplifier 2. Following the color code, route the left and right side speaker wires safely to their respective speakers (Pic 1) 3. Plug in the male ends into the stock harness, the terminals removed during speaker installation (Pic 1) 4. Plug the female ends onto the speaker terminals (Pic 1) 5. Locate the headlamp harness and remove the red cap over the Orange/White wire. a. If that wire is currently in use (e.g. accessory lighting) there is an additional piggy back connection on the Kicker harness to replace it 6. Plug the blue wire from the Kicker harness into the Orange/White wire, making sure it is fully engaged. (Pic 2) 7. Whether the extra blue wire lead is being used or not, heat shrink has been provided to put over it to reduce the risk of a short. (Pic 5) 8. Follow the proper procedure to remove the fuel tank.
