Summary of Contents for Amperes Electronics EP1200
- Page 1 EP1200 Emergency Paging Panel amperes version 1/04 www.ampereselectronics.com...
-
Page 2: Summary Of Features
Extra feature available from EP1200 is the availability of a dry contact, which is activated whenever the unit is triggered. This allows connected to volume controller for overriding purpose. -
Page 3: Parts Identifications
Pressing the microphone switch shall have priority over other inputs such as Siren, External Message input as well as normal paging or BGM feeds. This shall also activate a dry contact, which can be used to activate ALL CALL at speaker zone selector and 24V DC E/M overriding signal. PAGE 3 amperes electronics... - Page 4 Triggering the panel shall bypass the signal to allow higher priority audio to the PA system. 14. AUDIO OUTPUT JACK Connect the balanced output signal from EP1200 to power amplifier signal input. PAGE 4 amperes electronics...
-
Page 5: Schematic Diagram
SIG IN SIG IN SIG IN SIG IN SIG IN SIG IN SIG IN SIG IN MUSIC SOURCE audio out - balanced EP1200 EMERGENCY 24V DC BACK UP PANEL TEST FIRE SIREN ACTIVATE 1200 amperes POWER audio out - balanced... -
Page 6: Connecting The Unit
INPUT LEVEL MESSAGE SIREN DRY CONTACT TO POWER (NORMALLY OPEN) AMPLIFIER INPUT CONNECT TO ZONE (BALANCED LINE) SELECTORS FOR E/M OVERRIDING SIGNAL ACTIVATION EXTERNAL SIREN ACTIVATION CONTACT (VOLTAGE FREE) ie. FIRE CONTROL CENTER / SMOKE DETECTORS, PAGE 6 amperes electronics... -
Page 7: Technical Specifications
SIREN Paging MIc DC 24V RELAY RELAY REMOTE SELECT ZS5121 Zone Selector TRIG CONT Connect this to allow EP1200 to trigger internal relay of Zone Selector 24V E/M Fr. Zone Selector 100V Overriding Line Output Signal To Speakers Volume Controller... -
Page 8: Warranty Conditions
Only Amperes Electronics Service Centres are allowed to make warranty repairs : a list of Amperes Electronics Service Centres may be asked for by the purchaser or send directly to Amperes Electronics Sdn Bhd at 70 Jalan Industri PBP 3, Tmn Perindustrian Pusat Bandar Puchong, 47100, Puchong, Selangor, Malaysia or its authorized master distributor, Amperes Global Marketing.
