Summary of Contents for DnC Tech DMR-300

Page 2: Table Of Contents
Adding MMC / SD card Connection to computer Connection to computer Basic operation Basic operation- Installing Manager software Playing songs on “DMR-300” Deleting Manager software Selecting the track and volume control Connecting to computer Remote control Downloading files to DMR-300 Hold function/ Local repeat...
Page 3: Warning
WARNING DANGEROUS VOLTAGE Uninsulated Dangerous Voltage, that may be of sufficient magnitude to constitute a risk of electric shock to person is present within this product’ s enclosure ATTENTION The owner’ s manual contains important operating and maintenance instructions. For your safety, it is necessary to refer to the manual. To reduce the risk of fire or electric shock, do not expose4 this appliance to rain or moisture.
Page 4 WARNING Do not operate it during the driving, bicycling or operating other machine. Do not insert a metal with batteries. (risk of blaze) It is recommended that you follow the listed guide line to prevent damage of hearing. Establish a safe sound level. ? Slowly increase the level of volume until you can hear comfortably.
Page 5 Components Software Remote Necklace Ear phone installation CD control 2 AA type USB cable Line in cable Carrying batteries 제 품 설 명 편...
Page 6: Using Buttons And Controls
Using buttons and controls < Front > MENU Local Repeat Record HOLD Switch Earphone jack VOLUME Line-IN FORWARD REVERSE POWER ON/OFF Neck strap holder PLAY/PAUSE/STOP Power On / Play / Pause / Stop / Play the next track Power Off / Fast forward in the current track Volume Play the previous track...
Page 7 < Rear > MMC & SD card slot / USB jack Remaining battery capacity MMC / SD card icon This icon will blink while the song in MMC or SD card is played. Hold icon Play icon Pause icon Music recording icon Voice recording icon Local repeat icon Play mode icon...
Page 8 Inserting Battery The bars inside a battery icon displays the remaining battery capacity. The icon will blink when the batteries have almost run out. This unit will be automatically powered off in 30 minutes from this time. ① Slide open the cover as shown in the figure.
Page 9: Adding Mmc / Sd Card
Adding MMC / SD card If you need additional memory, you can purchase the MMC (the Multi Media Card) or SD card(Secure Digital memory card) as shown in the figure. Eject MMC / SD card, ① Align the MMC or SD card with the slot as shown in the figure and insert it ①...
Page 10: Playing Songs On "Dmr-300
Playing songs on “DMR-300” < Playing / turn on > < Pause > ① Insert the batteries and connect ① Press to pause while playing. the earphones to the player. ② When paused, press to play. ② Press to turn on.
Page 11: Selecting The Track And Volume Control
Selecting the track / Volume control Press to skip to the next track. Press +/- button to adjust the volume Press and hold to fast forward while playing. the current track. Press +/- button to adjust step by step. Volume range from 0 to 30. Press and hold +/- button to adjust continuously.
Page 12: Remote Control
Using the Remote Control ① Press and hold › to turn on Play / Paused Rewind the player. ② Press › to play. Stop Forward ③ Press › to pause. Menu Press › rapidly twice to Volume › move the next track. HOLD Press ›...
Page 13: Hold Function/ Local Repeat
Hold function / Local Repeat Local Repeat mode Hold mode Slide in direction to lock all To repeat a part of the current track, controls. ① Press to start the local recording. Under Hold mode, no button will ② Press to finish the local recording.
Page 14: Using Mode Options And Settings
Using mode options and settings Use the mode button to select the following mode options. The player displays a mode in the order of ‘ EQ’→’ REPEAT’→memory information→’ Record Input’→’ Record Bitrate’ as you press EQ (Equalizer) LIVE/JAZZ/ROCK/FLAT REPEAT REPEAT ONE / REPEAT ALL / RANDOM (file order) ERASE...
Page 15: Setting Up Eq
Setting up EQ(Equalizer) ① Press to set up EQ. ② Press to select the LIVE Preset for live music following menus; FLAT, LIVE, JAZZ, ROCK. JAZZ Preset for jazz music ③ Press to play the track. ROCK Preset for rock music FLAT Normal balance 응...
Page 16: Repeating Tracks
Repeating tracks Press twice to set up REPEAT. NORMAL REPEAT Press to select REPEAT menu. - Play all the tracks in order one The mode will be scrolled in the order of time. ‘ NORMAL REPEAT’ →’ REPEAT ONE’ REPEAT ONE →‘...
Page 17: Memory Information
Memory information Press three times to display the memory information. Press to indicate memory status in the order of ‘INTERNAL MEMORY TOTAL’→’ INTERNAL MEMORY REMAIN __MB’ →‘ EXTERNAL MEMORY TOTAL’ →’ EXTERNAL MEMORY REMAIN __MB’ , as you press. 응 용 편...
Page 18 Record Input Press four times to set up Record Input. Press to select ‘Internal Mic” or “Line In” Line In Headphone 응 용 편...
Page 19: Record Bitrate
Record bitrate Press five times to set up RECORD BITRATE. Press to select RECORD BITRATE menu. The mode will be scrolled in the order of ‘8kbps’→’ 16kbps’ →’ 32kbps’ → ’ 64kbps’ →’ 128Kbps’ as you press. 응 용 편...
Page 20: Delete
Delete ① Press six times to delete a track. ② Press to search the track. ③ Press to select the track. ④ When ‘ Confirm:Yes” is displayed, press to delete the track. If you do not need to delete the track, press to display ‘...
Page 21: Encoding Function
Encoding function First, set up Record Input mode on Line In. ① Turn on the player or stop the Playing. ② Plug in the Line-in cable into the Line in jack of the player and Line out jack of other device. ③...
Page 22: Recording The Voice
Recording Voice First, set up Record Input mode on the Internal Mic. ① Turn on the player or stop the Playing. ② Press to record the voice. ③ Press to stop the recording. Note When memory is full, ‘ FULL’ is displayed.
Page 23: Installing Manager Software
Installing Manager software ① Insert the installation CD into your ③ Click [Next]in the Set Up window CD-ROM drive. to start the installation of DMR-300. ② The installation CD will auto-run when loaded into a PC. Click Note : Do not connect the player to PC before this installation.
Page 24 ④ Enter user information. ⑥ Installation of management software is displayed. ⑦ Click “Finish” button to complete ⑤ Click [NEXT] button to install into the installation. the recommended folder. C:/ Program files/ DMR-300 Manager) Click Browse to choose another folder. 소프트웨어 사용하기...
Page 25: Deleting Manager Software
Deleting Manager software To delete DMR-300 Manager software, Select DMR-300 Manager. Start → Settings → Control Panel Click Add/Remove. Click Add/Remove Programs. 소프트웨어 사용하기...
Page 26: Connecting To Computer
Connects to Computer 1. Plug the USB cable into the 2. Slide the cover of MEMORY / USB port of computer. USB in the direction of the arrow. 3. “USB CONNECTED” will be displayed on the LCD. 소프트웨어 사용하기...
Page 27: Downloading Files To Dmr-300
Downloading files to “DMR-300”(1) ② Selects files to download to the ① Double click the icon of the player. Manager software on the desk. ③ Click Download button. Or, click ‘ File(F)’ and ‘ Download to MP3 Player (D)’ .
Page 28 Downloading files to “DMR-300”(2) Note 3. Downloading is displayed. ? Be sure the display “USB CONNECTED” is on the LCD to download. ? MP3 file per minute is about 1MB memory. ? Do not unplug USB cable or eject MMC/SD card to prevent damage.
Page 29: Uploading Files
Uploading files to PC 1. Select the file to uploading. 3. A selected file is transferred to PC. 2. Click ( ) upload button. Note ? You can upload general data files (such as MS word files, MS excel files etc.) to PC.
Page 30: Deleting Files
Deleting files 1. Select the file to delete. 3. Click [Confirm]. 2. Click [File (F)] → [File Delete] 3. Click [Confirm]. or, Click ( ) or, Click Right-click File Delete 소프트웨어 사용하기...
Page 31: Formatting The Memory
1. Click [Memory] → [internal/External memory format] Or, Select ( Note 2. Click [confirm] ? This player has to be connected to PC before format. . ? In case the DMR-300 Manager is disconnected to the player, Click 소프트웨어 사용하기...
Page 32: System Requirements
System Requirements PC / AT and compatibles ® MMX Pentium ???MHz and above ® Hard disk space 200?MB and above CD-Rom drive Default built-in USB port Operating system WIN95 OSR 2.1 / WIN 98 / ME / 2000 ? note While up-loading the voice file or data to PC, hard disk space for the file is required.
Page 33: Trouble Shooting
“CONNECTED”on LCD. Error appears It is a temporary memory error by static electricity. Format your memory. You can not install DMR-300 Manager software. Make sure you have OS. The available OS is Win95 OSR 2.1 and over / Win98 / 98SE/ME/2000.
Page 34 Frequently asked question < Not working > No battery, the power is almost out or the inserted batteries are in the wrong polarity. Check batteries in the player. Replace or reinsert the batteries. < Not working > Sound is too low. Press (+) to increase volume.
Page 35: Specification
Specification Frequency range 20㎐ ~ 20㎑ DMR-300N3 : 32MB DMR-300N6 : 64MB Memory capacity DMR-300N9 : 6MB DMR-300N13:128MB Battery AAA alkaline battery. Output level 5㎽ + 5㎽(1㎑, 0㏈/16Ω ) Equalizer LIVE/JAZZ/ROCK/FLAT Earphone jack 3.5㎜ Dimensions 2.83” X 1.96” X 0.70” 2 alkaline batteries 13 hrs weight...
Page 36 FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonabl e protection against harmful interference in a residential installation.
