- Page 1 USER MANUAL Digital Wireless Belt Station U9110-BSW (P/N: 40992G-19) 19549P-83 (03-17) ©2016 DAVID CLARK COMPANY INCORPORATED...
-
Page 3: Cautions And Warnings
APPEARS DAMAGED. Upon unpacking your David Clark product, inspect the contents for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify your David Clark product supplier. ELECTRICAL HAZARD - Disconnect electrical power when making any internal adjustments or repairs. - Page 4 Overview The U9110-BSW (40992G-19) Digital Wireless Belt Station is a portable wireless communication device that when used in conjunction with a U9120-W4 (44002G-01) Digital Wireless Gateway becomes part of a wireless intercom system. Up to four belt stations can be connected to one gateway.
-
Page 5: Status Indications
1. Ensure units are within 1 to 3 ft (0.3 to 0.9m) of each other. 2. Ensure the U9110-BSW is not already connected (see Status Indication). 3. Simultaneously (within 1-2 sec) press and release the PTT button on the U9110-BSW and the gateway to link with. -
Page 6: Operation
30 minutes. Headset In order for the U9110-BSW to be used, a David Clark H9100-series headset must be connected. To connect the headset, align red keyways and push. Pull back gently on the connector (behind the quick-release collar) to ensure it is properly locked. To disconnect, pull back on the quick- release collar. - Page 7 Interface to review programming options). Selections The U9110-BSW has the capability of switching between four “selections”. These selections are defined within the Digital Intercom System graphical user interface and can be configured to provide different communications paths between users and radios, as well as the behavior of auxiliary audio devices connected to the system.
- Page 8 At this point, approximately 1 hour of operation remains. Purging In some circumstances it may be desired to “purge” the U9110-BSW of its known gateway. Typically purging is not necessary unless there are multiple gateways in the same vicinity and you wish to link a belt station to a different gateway.
-
Page 9: Troubleshooting
Figure 3: Battery Insertion/Removal Troubleshooting Table 3: Troubleshooting Problem Solution Belt Station will not turn on Review Power-up/Power-down procedure Ensure a fresh battery is installed Cannot link a belt station Review Registration procedure Ensure units are within 1 to 3 ft. (0.3 to 0.9m) of each other while linking No sidetone Not connected to a Gateway... -
Page 10: Care And Maintenance
Care and Maintenance The U9110-BSW is not user serviceable. Do not attempt to open the enclosure. If this product requires service, please contact the David Clark Co. Inc. Customer Service department: • Phone: 800.298.6235 • E-Mail: serviceWWW@DavidClark.com • By Mail:... -
Page 11: Industry Canada Statement
Unauthorized Changes Changes or modifications not expressly approved by David Clark Company, Inc. could void the users’ authority to operate the equipment. Usage Restrictions Due to the UPCS frequencies used, this product is licensed for operation only in the United States of America and Canada, and those countries that have approved the DECT 6.0 Standard. -
Page 12: Sar Statement
European Union, Japan, Brazil and New Zealand): The highest SAR value for this product when tested for use on the body is 0.01W/kg (averaged over 1g). Specifications Refer to the U9110-BSW Data Sheet (19549P-51) for specifications. 10 of 10 19549P-83 (03-17)
